- Page 1 M2-W6510-48V8C Switch Hardware Installation and Reference Guide Version V1.0 copyright © 2023 Micas...
-
Page 2: Copyright Statement
This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Micas Networks website. Micas Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors. - Page 3 Appendix A "Connector and Connection Media" Appendix B “Lightening Protection” Appendix C “Cabling Recommendations in Installation” Appendix D “Site Selection” Obtaining Technical Assistance Micas Networks Website: https://www.micasnetworks.com/ Technical Support Website: http://www.micasnetworks.com/support Case Portal: http://www.micasnetworks.com/case Community: http://www.micasnetworks.com/company/contact...
-
Page 4: Symbol Conventions
Symbol Conventions Means reader take note. Notes contain helpful suggestions or references. Means reader be careful. In this situation, you might do something that could result in equipment damage or loss of data. -
Page 5: Product Overview
M2-W6510-48V8C switch is data center oriented high density 10G/25G access switch, providing 25G/100G access, low latency, and complete data center features. M2-W6510-48V8C switch, with up to 48 25G ports and 8 100G ports, can be used to compose a high-performance and high-reliability data center network. -
Page 6: Product Appearance
442 mm x 560 mm x 43.1 mm, 1RU (L x W x H) M2-W6510-48V8C switch is a class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. -
Page 7: Front Panel
SFP28 port status indicator Power status indicator QSFP28 port Fan status indicator QSFP28 port status indicator SFP28 port Asset label The M2-W6510-48V8C supports 100G QSFP28 module and 25G SFP28 module. Back Panel Figure 1- 3 Back Panel of the W6510-48V8C - 5 -... -
Page 8: External Ports
To protect the data and avoid device damage, use qualified USB flash disks of good brands. At the same time, the local USB port is compatible with most of the USB controllers except some USB flash disks. The M2-W6510-48V8C switch supports debugging, configuration, maintenance, management and host software uploading of Console ports. - Page 9 Hardware Installation and Reference Guide Product Overview MGMT port: This is an out-band Ethernet port, which uses standard RJ45 connector. This interface is connected with Ethernet port of a PC to perform program downloading. SFP28 port: There are 48 25G SFP28 ports, which support optical modules and DAC copper cables (10GBASE-X compatible).
-
Page 10: Power Supply
-F as well. Heat Dissipation The working temperature of the M2-W6510-48V8C switch is 0°C to 45°C, or 32°F to 113°F, and the heat dissipation design needs to ensure the stability, safety and maintainability in such environment. The M2-W6510-48V8C switch adopts fan ventilation and forced convection to ensure the device can work normally in specified environment. -
Page 11: Preparation Before Installation
Product Overview 2 Preparation before Installation 2.1 Safety Precautions To avoid body injury and device damage, please carefully read the safety precautions before you install the M2-W6510-48V8C. The following safety precautions do not cover all possible dangers. 2.1.1 Installation Safety ... -
Page 12: Laser Safety
Do not let any clothes touch a circuit board. An antistatic wrist strap can only prevent human static electricity from damaging the circuit board, but cannot prevent any static electricity on clothes. 2.1.5 Laser Safety Among the modules supported by the M2-W6510-48V8C, there are a great number of optical modules that are Class I laser product. Precautions: ... -
Page 13: Ventilation Requirements
2.2.2 Ventilation Requirements For the M2-W6510-48V8C products, leave sufficient space in the front and at the back of the chassis (at least 20cm) for ventilation. After various cables are connected, bundle the cables or place them in the cable management bracket to avoid blocking air inlets. - Page 14 2.2.5 System Grounding Requirements A good grounding system is the basis for the stable and reliable operation of the M2-W6510-48V8C. It is the key to prevent lightning stroke and resist interference. Please carefully check the grounding conditions on the installation site according to the grounding requirements, and perform grounding properly as needed.
-
Page 15: Emi Consideration
Hardware Installation and Reference Guide Preparation before Installation 2.2.6 EMI Consideration Various interference sources, from either outside or inside the device or application system, affect the system in the conductive ways such as capacitive coupling, inductive coupling, and electromagnetic radiation. There are two types of electromagnetic interferences: radiated interference and conducted interference, depending on the type of the propagation path. -
Page 16: Unpacking And Checking
Hardware Installation and Reference Guide Preparation before Installation switch M2-W6510-48V8C is not shipped with a tool kit. You need to prepare a tool kit by yourself. 2.5 Unpacking and Checking Goods Checklist Chassis, Yellow/green grounding cables; Quick installation guide; Packing list, Pouched... -
Page 17: Product Installation
Preparation before Installation 3 Product Installation The M2-W6510-48V8C Ethernet switch must be used and fixed in the room. Make sure you have carefully read part 2 and be sure that the requirements set forth in part 2 have been met. -
Page 18: Cabinet Installation
Precautions Before mounting M2-W6510-48V8C into the cabinet, first verify that the front and back brackets of the cabinet are at the right locations. If the bracket is too far forward, the front panel of the equipment may be too close to the front door, so that the front door cannot be closed when the equipment is connected with network cables and pigtail fibers. -
Page 19: Mounting The Switch In A Four-Post Rack
Hardware Installation and Reference Guide Product Installation you should reserve space of at least 10mm between the front panel of the equipment and that of the cabinet after installation. Before mounting into a cabinet, you need to make sure the following conditions are met: ... -
Page 20: Installing And Removing A Fan Module
Hardware Installation and Reference Guide Product Installation Sliding the Switch into the Rack Slide the rack-mount guides onto the guide rails (noted by ① in Figure 3) , and then gently slide the switch all the way into the rack (noted by ②). Securing the Switch to the Rack Secure the switch to the rack posts using the quick-release thumb screws (see Figure 4). -
Page 21: Installing A Power Module
Hardware Installation and Reference Guide Product Installation Withdraw the fan module uprightly and slowly. Install a filler panel on the location where a fan module is removed to ensure normal ventilation and dissipation and avoid dust in the chassis. 3.6 Installing and Removing a Power Module Wear anti-static gloves before the following operations. -
Page 22: Installing Power Cord Retainer
Hardware Installation and Reference Guide Product Installation Insert the power module smoothly. Please pay attention to the direction of the power panel to avoid wrong insertion. If it is difficult or even impossible to insert the module, pull out the module, make sure the extension module and guide rail are well aligned, and then insert the module again. -
Page 23: Removing A Power Module
Hardware Installation and Reference Guide Product Installation Check whether the power cord container is correctly installed. If you can remove the strap without pressing buckle A, the strap may be installed incorrectly. Try the other side of the strap. Attach the power cord container to the installation hole of the power module. Plug the power cord into the connector. -
Page 24: Simple Connection Steps
3.7 Grounding A PGND is installed on the back of M2-W6510-48V8C. First connect the PGND to the grounding terminal of the cabinet and then connect the grounding terminal to the grounding bar of the equipment room. -
Page 25: Connecting The External Interface Cables
Hardware Installation and Reference Guide Product Installation Connect the RJ45 connector to the Console interface of the management engine module with shipped console cable, and connect the DB9 connector to the NM or control terminal. By default, the baud rate is 115200, data bit 8, parity check none, stop bit 1, and flow control none. 3.9 Connecting the External Interface Cables Precautions ... -
Page 26: Verifying The Power Supply
Hardware Installation and Reference Guide Product Installation After equipment is installed, verify if the front/back cabinet doors can be closed. Verify that the cabinet has been fastened completely, and does not move or tilt. Verify that the equipment has been installed in the cabinet, and all the cables have been fastened to the cabinet. ... -
Page 27: System Debugging
Hardware Installation and Reference Guide Product Installation 4 System Debugging 4.1 Establishing the Configuration Environment Establishing the Configuration Environment Connect the PC to the console port of the switch through the console cable, as shown in Figure 4-1. Figure 4- 1 Schematic diagram of the configuration environment Connecting the Console Cable Connect one end of the DB-9 jack of the console cable to the serial port of the PC. - Page 28 Hardware Installation and Reference Guide Product Installation Figure 4- 2 Enter the name of the new connection and click OK. A window appears as shown in Figure 4-3. In the column of Connect Using field, select the serial port you want to use. Figure 4- 3 After the serial port is selected, please click OK.
-
Page 29: Power-On Startup
Hardware Installation and Reference Guide System Debugging After the serial port parameters are set, click OK to enter hyper terminal window. 4.2 Power-on Startup Checking before Power-on Check if the switch is fully grounded. Check if the fan module and the power module are correctly installed. ... -
Page 30: Monitoring And Maintenance
5 Monitoring and Maintenance 5.1 Monitoring Indicator When the M2-W6510-48V8C is running, users can monitor the status of host and each module by inspecting corresponding indicators. When the Status indicator is red, it means the system has a fault, in which case you can determine and eliminate the fault by viewing with the management software. -
Page 31: Power Supply Maintenance
Replacing Lithium Battery The built-in lithium batteries can support the real time clock of the M2-W6510-48V8C switch without external power supply. Please contact the technical support representatives of Micas Networks for replacing lithium batteries. Technical staff of Micas Networks will replace the battery of the same model. -
Page 32: Troubleshooting
Check the indicators on the device and the modules Check the connection of the serial ports and its parameters Check the connection of the fibers or cables of various ports Contact Technical Support of Micas Networks for hardware problems - 30 -... -
Page 33: Common Troubleshooting Procedures
Check whether the configuration of the serial port on the hyper terminal is the same as that described in M2-W6510-48V8C Software Configuration Guide. If not, modify the serial port configuration parameters. If there is still no serial port printed information, please contact Micas Customer Service Department for technical support. - Page 34 Check whether the module is inserted correctly. If the newly inserted module still cannot be powered on even though the checking is ok, please contact Micas Customer Service Department for technical support. Fault 7: The link cannot be set up between fiber interfaces.
-
Page 35: Appendix A Connectors And Connection Media
Hardware Installation and Reference Guide Troubleshooting Appendix A Connectors and Connection Media 10GBASE-T/1000BASE-T/100BASE-TX Port 10GBASE-T/1000BASE-T/100BASE-TX is a port that supports self-adaptation of three rates, and automatic MDI/MDIX Crossover at these three rates. 10GBASE-T complies with IEEE 802.3an standard, and the supported cables and cabling distances are listed in the following table. -
Page 36: Fiber Connection
Hardware Installation and Reference Guide Troubleshooting In addition to the above cables, the 100BASE-TX can use up to 100m of 100-ohm CAT5. Figure A-2 shows the definition of pin signal concerning the 100BASE-TX: Figure A-2 Definition of pin signal concerning the 100BASE-TX Socket Plug Input Receive Data+... -
Page 37: Appendix B Lightning Protection
Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Appendix B Lightning Protection Installing AC Power Arrester (lightning protection cable row) The external lightning protection cable row should be used on the AC power port to prevent the switch from being struck by lightning when the AC power cable is introduced from the outdoor and directly connected to the power port of the switch. - Page 38 Hardware Installation and Reference Guide Appendix A Connectors and Connection Media If the ALARM LED on the power arrester is Red, you should check whether it is caused by poor grounding connection or by the reversed connection of the Null and Live lines: Use the multimeter to check the polarity of the power socket for the arrester when the LED is Red, if the N line is on the left and the L line is on the right (facing the socket), the arrester PE terminal is not grounded;...
- Page 39 Hardware Installation and Reference Guide Appendix B Lightning Protection The Ethernet port arrester is only for the 10M/100M copper Ethernet ports with the RJ-45 connector; The Ethernet port arrester is not provided, the user can purchase them to address their own pratical requirements. For the detailed information for the arrester installation, please refer to Ethenet Port Arrester Hardware Installation Guide, which contains the technical specification and the maintenance and installation of the arrester.
-
Page 40: Appendix C Cabling Recommendations In Installation
Hardware Installation and Reference Guide Appendix B Lightning Protection Appendix C Cabling Recommendations in Installation When the switches are installed in standard 19-inch cabinets, the cables are tied in the binding rack on the cabinet by the cable management bracket, and top cabling or bottom cabling is adopted according to the actual situation in the equipment room. - Page 41 Hardware Installation and Reference Guide Appendix B Lightning Protection Cables of different types (such as power cords, signal cables, and grounding cables) should be separated in cabling and bundling and no mixed bundling is allowed. When they are close, crossover cabling can be adopted. In the case of parallel cabling, power cords and signal cables should maintain a distance not less than 30 mm.
- Page 42 Hardware Installation and Reference Guide Appendix C Cabling Recommendations in Installation Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the cabinet or cabling slot. The proper position indicates a position that will not affect device running or cause device damage or cable damage during commissioning.
- Page 43 Hardware Installation and Reference Guide Appendix C Cabling Recommendations in Installation Figure D-4 Cable fastening The hard power cable should be fastened at the terminal connection area to prevent stress on terminal connection and cable. Do not use self-tapping screws to fasten terminals. ...
-
Page 44: Appendix D Site Selection
Hardware Installation and Reference Guide Appendix C Cabling Recommendations in Installation Appendix D Site Selection The machine room should be at least 5km away from the heavy pollution source such as the smelter, coal mine and thermal power plant, 3.7km away from the medium pollution source such as the chemical industry, rubber industry and electroplating industry, and 2km away from the light pollution source such as the food manufacturer and leather plant.
