Summary of Contents for Idis DR-6516P-A
- Page 1 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
-
Page 2: Network Video Recorder
Network Video Recorder Quick Guide DR-6508P DR-6516P(-A) DR-6532P(-A) Powered by... -
Page 3: Safety Precautions
Safety Precautions Important Safeguards 14. Damage requiring Service Unplug this equipment from the wall outlet and refer servicing to qualified 1. Read Instructions service personnel under the following conditions: All the safety and operating instructions should be read before the A. -
Page 4: Fcc Compliance Statement
© 2023 IDIS Co., Ltd. IDIS Co., Ltd. reserves all rights concerning this document. Use or duplication of this document in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this document are subject to change without prior notice for reasons such as functionality enhancements. - Page 5 SATA Cables Optical USB Mouse IR Remote Control (Optional) Assembly Screws for Adding Hard Disk Drives Rack-mount Kit Please download IDIS Center software and product manual from this link : - IDIS Website (www.idisglobal.com) Overview Dimensions (Unit - mm) 430mm...
-
Page 6: Front Panel
Front Panel LEDs USB 2.0 Ports • Access various windows and menus using a USB mouse as you would on a personal computer. • For easier system configuration, a USB mouse is recommended. Rear Panel Audio Ports Video In / PoE Port Video In / Ext. -
Page 7: Remote Control (Optional)
Analog Camera Network Camera DirectIP™ Gigabit PoE Switch Network Camera eSATA Storage Network Device Sensor IDIS Center Remote Monitoring HDMI Monitor Keyboard Alarm Power Remote Control (Optional) ID Button Panic Button Camera Buttons Status Button Layout Button PTZ Control Buttons... -
Page 8: Getting Started
Getting Started Setup Wizard • Setup Wizard only appears during initial booting. When you login as an administrator account after initial booting, you can use Wizard to go to Live menu and select Wizard. • For more details on Setup Wizard, refer to the manual. ●... - Page 9 ● Authentication: Enter the necessary camera login info. This option is inactive for DirectIP / IDIS cameras because they do not require logins. This option is inactive for IDIS protocol only if the passoword is set. ● Multi-Selection Mode On/Off: Adds or removes cameras simultaneously by selecting multiple cameras from the list.
-
Page 10: Video Display Area
Login Video Display Area Left-click on the video display area to toggle between split screen and single screen modes. Drag the camera screens Configuring the NVR's settings and accessing its searching around to rearrange them. and other functions require an authorized user login. Bring up the Live menu and either press the Setup button on the remote control or click on icon using... -
Page 11: Basic Feature
• The password must be entered only with the Basic Feature virtual keyboard. • FEN service must be enabled to use find password functionS. Live Mode Enter an UPR(User Password Reset) verification and then click on UPR Verification button. Once Camera Registration is complete, the system will enter Live Mode. -
Page 12: Audio Recording
FEN server upon login) remote control. Contact your network administrator for the IP address of the NVR you wish to connect to and the IDIS Web All Channel Playback port number. Press the Menu button while in Live mode. -
Page 13: System Requirements
When IDIS Center software is installed, IDIS Center and IDIS Center Run as administrator shortcut icons will be created on the desktop. Run IDIS Center software by double-clicking on IDIS Center or IDIS Center Run as administrator shortcut icon. If a removable eSATA HDD or... -
Page 14: Device Registration
Device Registration This program does not have a password set by default. To use the functions provided by IDIS Center, you must first Leaving the admin account unassigned with a password register a device and add the device to a device group. -
Page 15: Live Video Mode
Live Video Mode When user authentication window appears, enter the User ID and Password set up on each device, and then select OK for remote access. In the Site List, make sure that the device has been added to the device group. In the panel tabs, click the Live tab. - Page 16 Open the Play Store(Google Play) on your Android Open the App Store on your device. device. Enter IDIS Mobile Plus in the search filed of the App In Play Store (Google Play), enter IDIS Mobile Plus in Store. the search field.
- Page 17 Installing or Replacing the HDD You can install an additional HDD or replace an HDD with an existing drive if necessary. (Image below is for illustrative purposes only and may differ from the actual product.) Please follow these steps to add or replace an HDD in an actual place where users use the product.요. Remove the screws from the left/right sides Disconnect the power and data cables and back side.
- Page 18 Remove one screw that secures the HDD Unscrew the screws on the left and right bracket, and push the bracket back to sides of the HDD bracket to detach the detach it from the mainboard. HDD from the bracket. Install the new HDD, and tighten the screws to fix it.
- Page 19 Attach the bracket. Close the cover. Connect the power and data cables to the After closing the cover, tighten the screws hard disk. to fix it.
-
Page 20: Specifications
100-240V~, 50 / 60Hz, 3.0-1.5A (DR-6508P / Data Export Device USB HDD, USB Stick DR-6516P / DR-6532P) Power Input 100-240V~, 50 / 60Hz, 4.0-2.0A (DR-6516P-A / DR-6532P-A) NETWORK 100-240V~, 50 / 60Hz, 3.0-1.5A, 250W (DR- 6508P / DR-6516P / DR-6532P)
