  • Page 1 Network Video Recorder Installation Manual DR-6308P-S / DR-6308P-SA DR-6316PS-S / DR-6316PS-SA DR-6332PS-S / DR-6332PS-SA Powered by...
  • Page 2 Before reading this manual This manual contains basic instructions on installing and using DirectIP™ Network Video Recorder, an IDIS product. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Before reading this manual 1. Read Instructions 14. Damage requiring Service All the safety and operating instructions should be read before the appliance Unplug this equipment from the wall outlet and refer servicing to qualified is operated. service personnel under the following conditions: 2.
  • Page 4 Before reading this manual Important Safeguards In-Text Symbol Type Description Caution Important information concerning a specific function. Note Useful information concerning a specific function. User’s Caution Statement Caution: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
  • Page 5 IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice.

  • Page 6: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 7 Product Features .

  • Page 7: Part 1 - Introduction

    Part 1 – Introduction Product Features This is a DirectIP™-enabled video recorder that supports surveillance, recording, and playback of video from network cameras (or video encoders). This NVR (Network Video Recorder) unit offers the following features: ● Real-time 8/16/32-channel DirectIP™ network surveillance ●...
  • Page 8 Part 1 – Introduction This document covers the 8-, 16-,and 32-channel network video recorders. The NVRs are identical except for the number of cameras and alarms that can be connected and the number of cameras that can be displayed. For simplicity, the illustrations and descriptions in this document refer to the 32-channel model.

  • Page 9: Accessories

    Part 1 – Introduction Accessories Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included. Network Video Recorder Power Cable Quick Guide SATA2 cables Optical USB Mouse IR Remote Control Assembly Screws for Adding Hard Rack-mount Kit Disk Drives...

  • Page 10: Overview

    Part 1 – Introduction Overview Front Panel LEDs USB Ports • Remote control sensor is located on the right side of the front panel. Ensure that the sensor remains unobstructed at all times. If obstructed, the sensor might not be able to receive remote control signals. •...
  • Page 11 Part 1 – Introduction Connections on the Front Panel IR Remote Control Flash Memory Mouse USB HDD...

  • Page 12: Dimensions

    Part 1 – Introduction Dimensions (Unit : mm) 430mm (16.92ʺ)

  • Page 13: Rear Panel

    Part 1 – Introduction Rear Panel Factory Reset Button Video In / PoE Ports Video In / Ext. Port Network Port eSATA Ports Alarm Connection Ports RS-485 Port RS-232 Port HDMI Out Port VGA Out Port Audio Ports Power In Port Vent Rear Panel Connections •...
  • Page 14 Part 1 – Introduction Video Connection Network Connection ● Video In/PoE Port This NVR is capable of connecting to networks via an ethernet connector. Connect an RJ-45 cable (Cat5e, or Cat6) to the NVR's network port. It's possible to operate and upgrade the NVR remotely over a network.
  • Page 15 Part 1 – Introduction ● G (Ground) RS-232 Connection Connect alarm in or out's ground cable to the G Connect an external device such as a POS unit to this connector. port. All connectors marked "G" are common connectors. ● NC/NO (Relay Alarm Outputs) RS-485 Connection This NVR is capable of activating/deactivating buzzers, This NVR supports the RS-485 half-duplex serial...
  • Page 16 Part 1 – Introduction Turn off the NVR. Insert a straightened paper clip into the factory reset switch hole and press the switch. Turn on the NVR while holding the switch. • Organize the power cable so that it will not cause Press and hold until you hear 2 beeps from the NVR's people to trip over or become damaged from chairs, internal buzzer.
  • Page 17 Part 1 – Introduction Connections on the Rear Panel Video Encoder Analog Camera Network Camera DirectIP™ Gigabit PoE Switch Network Camera Sensor eSATA Storage Network Device Microphone IDIS Center Speaker Remote Monitoring VGA Monitor Keyboard Alarm HDMI Monitor Power...

  • Page 18: Remote Control

    Part 1 – Introduction Remote Control ID Button PANIC Button Camera Buttons STATUS Button LAYOUT Button PTZ Control Buttons REGISTER MODE Button THUMBNAIL Button CALENDAR Button KEYLOCK Button SETUP Button FREEZE Button LOG Button Enter Button Arrow Buttons ALARM Button SEQUENCE Button &...
  • Page 19 1 ID Button 7 REGISTER MODE Button Used to assign remote control ID values. Used in Live mode to access Camera Registration mode. No additional remote control assignment is necessary if the system's ID is 0. If the system's ID is 8 THUMBNAIL Button a number between 1 and 99, however, you will need Used in Playback mode to access Thumbnail Search...
  • Page 20 Part 1 – Introduction $ Enter Button b MENU Button Pressing the MENU button while in Live mode Used to make menu option selections and register data entries. In addition, pressing this button while displays the Live menu. Alternatively, pressing the a camera screen is selected by pressing the Menu button while in Time-lapse Search mode displays the button in Live or Playback mode displays the Camera...

  • Page 21: Part 2 - Appendix

    Part 2 - Appendix System Log Types Boot Up Panic On System Shutdown Panic Off Restart Clear All Data Upgrade Success Clear Disk Upgrade Error Format Disk Power Failure Disk Full Time Changed Auto Deletion Time Zone Change Search Begin Time Sync.

  • Page 22: Error Code Types

    Part 2 - Appendix Error Code Types Upgrade Error Codes Type Type Unknown Error Remote Network Error Incorrect File Version No Remote Upgrade Permission Incorrect OS Version Remote Upgrade File Save Failure Incorrect Software Version Remote Upgrade Cancelled by User Incorrect Kernel Version USB Storage Device Mount Failure Storage Device Mount Failure...
  • Page 23 Part 2 - Appendix Clip Copy Error Codes Type Type Unknown Error Disk Error Device Error Clip Player Execution File Not Found Device Connection Failure Clip Player Execution File Access Failure CD Media Not Found Clip Player Execution File Save Failure Incorrect Media Image Generation Failure File Name Taken...
  • Page 24 Part 2 - Appendix Network Error Codes Type Type Cause of Failure Unknown Connection Cancelled by User Normal Logout No Response from Network Device Host All Channels in Use - Connection Denied High Network Noise Level Incorrect Product Version Info Transmission Queue Full Incorrect User Name or Password Incorrect OEM Info...

  • Page 25: Troubleshooting

    Part 2 - Appendix Troubleshooting Problem Solution ● Check the power cable connection status. The main unit won't turn on. ● Check the power outlet. ● Check the camera's video cable connection status. ● Check the monitor's video cable connection status. Unable to display Live video.

  • Page 26: Specifications

    Part 2 - Appendix Specifications These product specifications may change without prior notice. VIDEO 8/16/32 IP channels (DR-6308P-S, DR-6308P-SA/ DR-6316PS-S, DR-6316PS-S/ DR- Video Inputs 6332PS-S, DR-6332PS-SA) Video Outputs 1 HDMI, 1 VGA Display Resolution 3840x2160, 1920 x 1200, 1920 x 1080, 1680 x 1050, 1600 x 1200...
  • Page 27 PoE(IEEE 802.3at class 4) supported 16 ports, 120W (DR-6332PS-S/ DR-6332PS-SA) Camera Power PoE(IEEE 802.3at class 4) supported 16 ports, 120W (DR-6316PS-S/ DR-6316PS-SA) PoE(IEEE 802.3at class 4) supported 8 ports, 120W (DR-6308P-S/ DR-6308P-SA) Email (attach clip (.cbf ) .MP4), Callback to Remote S/W, Push notification (IDIS Event Notification Mobile) INTERFACE...
  • Page 28 Hard disk compatibility chart is subject to change without notice. Contact your retailer for the latest compatibility chart. Storage Manufacturer Model Note TOSHIBA DT01ABA100V Western Digital WD20PURX-64P6ZY0 Western Digital WD30PURX-64P6ZY0 Western Digital WD40PURX-64GVNT0 Western Digital WD80PUZX-64NEAY0 Western Digital HUH721010ALE600 10TB DR-6308P-S/DR-6316PS-S/ SEAGATE ST10000VX0004 DR-6308P-SA/DR-6316PS-SA...
  • Page 29 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
