- Page 1 CHIMNEY HOOD INSTALLATIONS INSTRUCTIONS MODELS KU90 PRO 2X K92AMHU3X..50 KU122 PRO 2X K42AMHU3X..50 310641...
- Page 2 Fig. 1 Fig.2 fig.3...
- Page 3 fig.4 DIMENSION (mm)
- Page 5 CHIMNEY HOOD INSTALLATIONS INSTRUCTIONS Important safeguards - Do not connectthe exhaust hood to chimneys, flues and airductsserving the room. - The evacuated air must not be let into a warm air duct. - This appliance must be connected to a system equipped with earth or ground plate. - When performing maintenance operations, disconnect the appliance from the field connection.
- Page 6 WARNING: TO REDUCE THE RISK OF FIRE, USE ONL Y METAL DUCTWORK. Attention: The appliance is provided with a supply cord without plug, the appliance must be positioned so that the plug will be accessible. Attention: ifthere are three wires in the electrical supply cable they must be connected as follows: Green/yellow = ground - Blu = neutral - Brown = line Important: the hood manufacturer will not be responsible for any damage or loss caused by failure to observe these instructions.
- Page 7 Replacing or cleaning the filters Just push the handle towards the rear, clean and replace filter (Picl. 1/1). To remove the aluminium grease filter (Picl. 1/2), grab the opening tongue at the filter, pull it in your direction and move the filter down wards. To reinstall it operate reversed.
