- Page 1 USER MANUAL PLEASE SAVE THIS MANUAL FOR FUTURE REFERENCE MODEL: TRIANNA T920 T-SPA MFG, LLC 10510-10520 KINGHURST ST HOUSTON, TX 77099 1(888) 508 -8772 www.tspallc.com P a g e...
-
Page 2: Table Of Contents
TABLE OF CONTENTS CONTENT PAGE SAFETY & PRECAUTION SPECIFICATION IDENTIFY YOUR FOOT SPA FOOT-SPA CLEARANCE INSTALLATIONS OPERATION & USE CLEANING, MAINTERNANCE & USE WARRANTY & SERVICE UL CERTIFICATE WARRANTY REGISTRATION FORM P a g e... -
Page 3: Safety & Precaution
SAFETY & PRECAUTION DANGER: Risk of Electric Shock. Connect only to a circuit protected by a ground fault circuit interrupted GROUNDING IS REQUIRED. The unit should be installed by a qualified service representative and grounded. Install to permit access for servicing. CAUTION: Risk of electric shock. - Page 4 WARNING: It is important that you carefully follow the basin cleaning procedures on page 17 to ensure that the spa is sanitized after each use. T-spa is not liable for any infections or disease that may result from improper cleaning or failure to adhere to sanitation requirements.
- Page 5 SAFETY & PRECAUTION Health Risk Warning Use of the pedicure spa unit should be pleasant and comfortable; if there is any pain or discomfort, stop use of the pedicure spa immediately. A physician should be consulted before use of the massage chair by anyone with the following conditions: Malignant tumor, heart disease, pregnancy, Conditions requiring rest, and back disease or trouble from an injury or accident.
-
Page 6: Specification
SPECIFICATION Dimension & Weight (Shipping) 55L x 28W x 20H 125 lbs Pedicure Spa 44L x 31W x 24H 176 lbs Massage Chair 20.25L x 27.5W x 17H 19 lbs Stool Capacity of Tub T-920 4.5 US Gallon Switch On/ Off Air Activated Switch Power Source Dedicated 15Amp Wall Outlet Require 120 Vac, 0.4 Amp.60 Hz... -
Page 7: Identify Your Foot Spa
IDENTIFY YOUR FOOT-SPA SEAT OPERATION Reclining 25˚ Armrest can be raised up/down Chair Sliding SPA DIMENSION 60” 27” 22” P a g e... -
Page 8: Foot-Spa Clearance
FOOT-SPA CLEARANCE WALL CLEARANCE Wall 22” Distance from center drain to the back of the spa TYPICAL FOOT-SPAS 23” Clearance 50” 24” 24” P a g e... -
Page 9: Installations
INSTALLATIONS Align the seat with the pre-drilled holes on the base then tightly secure with the nuts and bolts provided. Attach trays or remote stand to armrest with screws provided. MODEL: TRIANNA T920 P a g e... - Page 10 INSTALLATIONS When using electrical equipment, Basic safety precautions must be followed to reduce the risk of fire, electrical shock, and injury to Persons. Read and follow all instructions before using the equipment. Keep electrical cord out of heavy traffic area. To avoid fire hazard NEVER place electrical cord under the rug, near heat Generating devices.
- Page 11 INSTALLATIONS Jet Unit Components Motor Magnetic Jet Base Magnetic Impeller Magnetic Whirlpool cover Bottom view of magnetic jet base Magnet Jet Feature 1. Hydro dual massage jet stream 2. Magnetic whirlpool jet cover can be removed for quick cleaning and sanitizing 3.
- Page 12 INSTALLATIONS Plumbing Connections 1. Discharge pump may be connected to an existing sink drain or floor drain. It can also pump up to 7 ft high, but this will increase the length of the drain time. The drain connection is at the rear of the unit by a 3/4”...
- Page 13 INSTALLATIONS Typical Discharge Pump Installation (OPTIONAL) Backwater Valve Supplied by plumber 3/8 Hot and Cold Hoses Typical Gravity Sink (Direct Drain) Installation 3/8 Hot and Cold Hoses Drain Elbow Gravity Sink 2’- 3’ to sewer line 13 | P a g e...
- Page 14 INSTALLATIONS Typical Vent System Installation (OPTIONAL) 14 | P a g e...
-
Page 15: Operation & Use
OPERATION & USE Overflow Mixer Discharge pump switch Ventilation (optional) 1. To fill water: The foot-spa is provided with a single hot and cold mixing valve located on the front of your spa. This is a pressure balance valve that requires you to lift the handle to start the water flow and to adjust to the temperature that is desired. -
Page 16: Cleaning, Mainternance & Use
CLEANING & MAINTENANCE & USE Please refer the diagrams to remove jet covers for cleaning T-spa MFG, LLC highly recommends the following cleaning regimen. You should always contact your local governing agency for their specific cleaning and disinfecting requirements and regulations for pedicure spas. -
Page 17: Warranty & Service
No dealer or other person has any authority to bind T-spa MFG, LLC to changes or additions to this warranty or its products. Accordingly, T-spa MFG, LLC is not responsible for such warranties or representations. -
Page 18: Ul Certificate
18 | P a g e... -
Page 19: Warranty Registration Form
IMPORTANT To validate the limited warranty, The Limited Warranty Registration Form MUST be filled out completely and return to T-SPA MFG, LLC within 30 days of original purchased date. This Limited Warranty is valid if T-SPA MFG, LLC received registration form SERIAL NO.: T……………………………………....INVOICE #: ……………………………………... - Page 20 T-SPA MFG, LLC 10510-10520 KINGHURST ST HOUSTON, TX 77099 1(888)508-8772 www.tspallc.com 20 | P a g e...
