Summary of Contents for T-SPA T-800
- Page 1 OWNER MANUAL PLEASE SAVE THIS MANUAL FOR FUTURE REFERENCE VERSION: T-800 MODEL: MURANO PEDICURE CHAIR Page 1 Version: T-800...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety & Precaution Specification Identify Your Foot Spa Foot-spa Clearance Installations Operation & Use Maintenance & Use Warranty & Service UL Certificate Warranty Registration Form Page 2 Version: T-800... -
Page 3: Safety & Precaution
WARNING: Risk of electric shock; do not permit electric appliances (such as a hair dryer, lamp, telephone, radio, or television) within 1.SM (5 feet) of this hydro massage bathtub. CAUTION: Test the ground fault circuit interrupted protecting this appliance periodically in accordance with the manufacturer’s instructions Page 3 Version: T-800... - Page 4 WARNING: It is very important that you carefully follow the basin cleaning procedures on page 17 to ensure that the spa is sanitized after each use. T-SPA is not liable for any infections or disease that may result from improper cleaning or failure to adhere to sanitation requirements.
- Page 5 Keep the massage chair and its air openings clean and free of hair and dust; never operate the massage chair if the air openings are blocked. Misuse or failure to properly clean pedicure spa unit may result in serious health issues, bodily injury, and/or death. Page 5 Version: T-800...
- Page 6 Fatal electric shock and fire could occur with improper connection of the equipment- grounding conductor. Do not modify the plug provided with the product for any reason; if it will not fit the outlet, have a proper outlet installed by a qualified electrician. Page 6 Version: T-800...
- Page 7 30 minutes. Failure to turn the chair off may result in the chair starting unexpectedly when the device cools. Page 7 Version: T-800...
-
Page 8: Specification
SPECIFICATION VERSION: T-800 Dimension (Shipping) Pedicure Spa 55L x 28W x 20H Massage Chair 44L x 31W x 24H Stool 21L x 27W x 17H Weight (Shipping) Pedicure Spa 150 lbs. Massage Chair 120 lbs. Stool 17 lbs. Capacity T-800 4.5 US Gal... -
Page 9: Identify Your Foot Spa
IDENTIFY YOUR FOOT-SPA SEAT OPERATION Reclining 25’’ Armrest can be raised up/down Chair Sliding SPA DIMENSION Height 60” Rear Width 27” Front Width 22” Length 50” Page 9 Version: T-800... -
Page 10: Foot-Spa Clearance
FOOT-SPA CLEARANCE WALL CLEARANCE 22” between edge of spa and wall TYPICAL FOOT-SPA 23” between manicure trays 50” between each spa Page 10 Version: T-800... -
Page 11: Installations
INSTALLATIONS Align the seat with pre-drilled holes on the base then tightly secure with provided nuts and bolts. Attach trays or remote stand to armrest with provided screws. VERSION: T-800 MODEL: MURANO PEDICURE CHAIR Page 11 Version: T-800... - Page 12 6. Firmly hold the whirlpool jet cover and gently place it onto the round magnetic field. DO NOT release the hydro whirlpool jet cover until jet cover is on the round magnetic housing. Page 12 Version: T-800...
- Page 13 5. Very low power consumption (27W). 6. Manufactured in the U.S.A. MAGNET JET SPECIFICATIONS Model: MAGNA JET – 120 VAC, 60 Hz, 1.0 A Pump: Hydro Dual-Massage Jet Flow Mounting: Single 3.5”-diameter hole with auto tighten mounting screws (4) Page 13 Version: T-800...
- Page 14 6. Handheld sprayer. It has complied with applicable requirements of ASME A112.18.1-2005/CSA B125.1-05 FAILURE TO ANCHOR THE BASE MAY RESULT IN PERSONAL INJURY OR DAMAGE TO UNIT. DAMAGE AS A RESULT WILL VOID THE WARRANTY. Page 14 Version: T-800...
- Page 15 Typical Gravity Sink (Direct Drain) Installation: 2”-3” Gravity Sink to sewer line Typical Discharge Pump Installation (OPTIONAL): Backflow Valve supplied by plumber T-SPA MFG, LLC 10510-10520 Kinghurst St Houston, TX 77099 Page 15 Version: T-800 ☏ (888) 508-8772 | ✉ info@tspallc.com www.tspallc.com...
- Page 16 INSTALLATIONS Typical Ventilation System Installation (OPTIONAL) 1.5” Output 1.5” Input Page 16 Version: T-800...
-
Page 17: Operation & Use
If optional discharge pump system is installed: press Drain/Pump button to activate discharge pump motor. Average drain time approximately one minute (depending on plumbing characteristics). 4. MASSAGE CHAIR MANUAL BOOK WILL BE SEND SEPARATELY Page 17 Version: T-800... - Page 18 6. The unit must be connected to an electrical supply circuit that is protected by a ground fault circuit interrupter. 7. The clean jet motor is magnetically driven and is insulated twice. Therefore, it does not require to be bonded. Save these instructions! Page 18 Version: T-800...
-
Page 19: Maintenance & Use
NOTE: The use of oil-based products can build up in the whirlpool system, causing clogging in the jets. Adherence to the above cleaning will minimize build up. T-SPA DO NOT recommend the use of mineral oil-based products. Cleaning or sanitizing is NOT disinfecting. According to the Centers of Disease... - Page 20 After checking underside for leaks, turn on whirlpool system by pushing Jet button and watch for leaks as water circulates. Let the tub run on full cycle. Open drain plug to discharge Page 20 Version: T-800...
-
Page 21: Warranty & Service
WARRANTY & SERVICE T-SPA warrants to the original purchaser that the new pedicure spa will be free from defect during the Standard Warranty Period (listed below). The shipping date and the uniquely coded Serial Number on the back of each spa chair will justify the start of the warranty period for the product. - Page 22 4. All parts are to be shipped by Ground services, average of 2-5 days. 5. All defective parts must be shipped back to T-SPA within 30 days of receiving the new replacement parts or warranty will be void. 6. Any warranty claim that cannot be determined over the phone call, the customer must send photos to T-SPA for inspection related.
-
Page 23: Ul Certificate
T-SPA MFG, LLC 10510-10520 Kinghurst St Houston, TX 77099 Page 23 Version: T-800 ☏ (888) 508-8772 | ✉ info@tspallc.com www.tspallc.com...
