- Page 1 Successor Pedicure Spa Model: T-300 Version 2 (Successor) Customization References Bases Massage Chairs Successor Black Throne Successor Gold T-timeless Triumph Trident User Manual Read this manual before using the unit and keep it for future reference.
-
Page 2: Introduction
This manual should be saved for future reference. Your T-SPA pedicure spa unit should not be used in any other manner than described in this manual. Please read, understand, and follow all safety warnings, labels, and instructions. Misuse, use of unnecessary force, or using the chair for unintended or unauthorized procedures can result in injury to operator, client, and/or equipment. -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION SAFETY INFORMATION SHIPMENT INSPECTION HEALTH RISKS RESPONSIBLE USE PEDICURE SPA SPECIFICATIONS COMPONENTS INSTALLATION INSTALLATION REQUIREMENTS CHAIR ASSEMBLY TO SPA BASE PLUMBING INSTALLATION WIRING TESTING AFTER INSTALLATION PEDICURE SPA OPERATION CLEANING AND MAINTENANCE TROUBLESHOOTING LIMITED WARRANTY LIMITED WARRANTY REGISTRATION FORM APPENDIX... -
Page 4: Safety Information
Shipping Damage Claim If concealed loss or damage is found, you MUST report it to T-SPA’s Customer Support within 24 hours after receiving the products. Do Not Discard The Shipping Carton Failure to do so constitutes acceptance of the shipment as-is and in good order and, additionally, waives any right to collect possible compensation from shipping claims. - Page 5 20 to ensure that the spa is sanitized after each use. T-SPA is not liable for any infections or disease that may result from improper cleaning or failure to adhere to sanitation requirements. Misuse or failure to properly clean the spa unit may result in serious health issues and/or severe disease contagion.
-
Page 6: Responsible Use
adjustments to your chair. Keep all equipment • DO NOT drop or insert anything into jet opening. and body parts away from moving parts while • DO NOT operate without the complete jet making any adjustments. assembly installed or without water filled 1 inch •... -
Page 7: Pedicure Spa Specifications
(Power source 115 V – 3.2 A – 60 Hz) Auto-fill Optional upgrade Ventilation Optional upgrade Thermometer shower head Optional upgrade Importer T-SPA MFG, LLC Base Tiana Household Products Co.,Ltd Manufacturer Irest Health Science and Chair Foresee Scientech Ltd. Technology Co.,Ltd... -
Page 8: Components
COMPONENTS Successor / T-timeless Successor / Throne 1. Massage chair 11. Whirlpool jet head 2. Flip-up armrest 12. Shower head 3. Flip-out manicure tray 13. Mixer knob 4. Built-in remote control 14. Overflow knob 5. USB charger 15. Technician controller 6. - Page 9 Successor / Triumph Successor / Trident 1. Massage chair 11. Whirlpool jet head 2. Armrest: Flip-up (Triumph) / Slidable (Trident) 12. Shower head 3. Flip-out manicure tray 13. Mixer knob 4. Built-in remote control 14. Overflow knob 5. USB charging 15.
-
Page 10: Installation
INSTALLATION INSTALLATION REQUIREMENTS Your pedicure spa cannot operate safely or efficiently unless it is provided with adequate electrical power, sufficient water pressure, proper water temperature, and required drainage capabilities. Electrical Service 110V, 60Hz, 15Amp GFCI (Ground Fault Circuit Interrupter) protected grounded circuit must be used to supply power to each spa unit, and the main circuit breaker must be at Reset button 25Amp. -
Page 11: Chair Assembly To Spa Base
Wall clearance Safety distance between units Minimum distance between trays 2 - 3” (5 - 8 cm) 22” (56 cm) 50” (127 cm) CAUTION - INSTALL ENSURING AN UNOBSTRUCTED OPERATION OF THE CHAIR Both the backrest and the seat position are adjustable. When the backrest is at its maximum recline, it must allow 22”... -
Page 12: Plumbing Installation
PLUMBING INSTALLATION Due to differences in construction layout of salons and city plumbing codes, PVC pipes & elbow connectors are not included. Your certified plumber will need to provide them when doing the installation. The installation must comply with federal, state, and local building, electrical, and safety codes, where applicable. - Page 13 Drain system recommendation Height needs to be adjusted based on your salon setup Water supply installation Hot and Cold water supply connections are located at the rear of the unit. Please be aware that the Hot/Cold water supply lines are not fitted with optional backflow by default.
-
Page 14: Wiring
WIRING Have a qualified licensed electrician install the wiring according to local codes. The clean jets are 1/18 HP, 120V A.C., 0.55 AMP, 60 Hz. GFI protected circuit must be used to supply power to the unit. The roller back massage chair uses a 115V A.C. supply. Throne Chair T-timeless Chair 4 connectors... -
Page 15: Testing After Installation
Throne T-timeless 4. Gently lift up the backrest, making sure that the two side pivots are properly secured to the quick release brackets in the seat frame. Adjust the two side pivots into the quick release brackets if necessary. Triumph 5. -
Page 16: Pedicure Spa Operation
PEDICURE SPA OPERATION WARNING: THERMAL RESETTING PROTECTION DEVICE The massage chair is equipped with a thermal resetting protection device. This is a safety feature to protect it from overheating. If the chair should suddenly stop and will not start, turn the main power switch off, and do not operate the chair for at least 30 minutes. - Page 17 DRAINING THE BASIN Push open the drain plug. If the spa has a gravity drain system installed, the basin will empty at a speed determined by the waste-water plumbing. If the optional discharge pump system is installed, press the Drain / D ischarge Pump button to activate the discharge pump motor.
- Page 18 THRONE CHAIR REMOTE CONTROL POWER 1. Turns Spa ON to Stand By mode until a function is Press and hold for 1.5 seconds, this will reset all set-ups. introduced. The light indicator will blink until the restoration process 2. Spa will auto shut-down if no functions are introduced completes (24 seconds).
- Page 19 TRIDENT CHAIR REMOTE CONTROL POWER Start or stop massage UPPER BACK Power The massage device mainly covers the neck and shoulder area Auto Mode FULL BACK The massage device works with various techniques at different body areas of the upper body Upper Full Lower...
-
Page 20: Cleaning And Maintenance
CAUTION The use of oil-based products can build up in the whirlpool system, causing clogging in the jets. Adherence to the above cleaning will minimize build up. T-SPA DO NOT recommend the use of mineral oil-based products. Failure to comply with all cleaning instructions can cause damage and void your warranty. - Page 21 A special note pertaining to bleach While bleach seems to be used extensively for cleaning and disinfecting of pedicure chair basins, it is NOT recommended nor is it effective. Moreover, excessive use of bleach may greatly reduce the longevity of your pedicure chair internal components (i.e.
-
Page 22: Troubleshooting
TROUBLESHOOTING This helpful troubleshooting guide will provide you with information about how to recognize a problem with your product, determine possible causes, and find a solution. In the event your specific situation is not covered in this guide, please contact our technical support department to assist you. -
Page 23: Limited Warranty
LIMITED WARRANTY T-SPA designs and assembles pedicure spas to the highest quality standards. Accordingly, T-SPA guarantees to the original owner that this product leaves the factory free from defects related to materials and manufacturing. If for any reason a failure related to materials and manufacturing were to occur, check the Standard Warranty period list below to know the time periods for the different components. - Page 24 No dealer or other person has any authority to bind T-SPA to changes or additions to this warranty or its products. Accordingly, T-SPA is not responsible for such warranties or representations.
-
Page 25: Limited Warranty Registration Form
To validate the limited warranty, Limited Warranty Registration Form MUST be filled out completely and return to T-SPA within 30 days of original purchased date. This Limited Warranty is valid if T-SPA received the registration form from the original purchaser. - Page 26 APPENDIX Drain pipes and fittings NO. Item Name Material QTY Remarks Drain and Overflow Material QTY NO. Item Name 26 | APPENDIX...
- Page 27 Mixer NO. Item Material QTY Name APPENDIX | 27...
- Page 28 Shower head NO. Item Name Material QTY 28 | APPENDIX...
- Page 29 IAPMO RESEARCH AND TESTING, INC. 5001 E. Philadelphia Street, Ontario, CA 91761 • Phone (909) 472-4100 • Fax (909) 472-4244 • www.iapmort.org CERTIFICATE OF LISTING IAPMO Research and Testing, Inc. is a product certi cation body which tests and inspects samples taken from the supplier's stock or from the market or a combination of both to verify compliance to the requirements of applicable codes and standards.
- Page 30 IAPMO RESEARCH AND TESTING, INC. CERTIFICATE OF LISTING Issued To: QIANG YING HOSE FACTORY E�ective Date: April 2021 File Number: 12907 Product: Flexible Water Connectors Void After: April 2026 This certi cate is not evidence of current listing.To verify listing status, visit the IAPMO R&T Product Listing Directory at pld.iapmo.org Identification: Manufacturer's name or trademark and cUPC®...
- Page 31 IAPMO RESEARCH AND TESTING, INC. 5001 E. Philadelphia Street, Ontario, CA 91761 • Phone (909) 472-4100 • Fax (909) 472-4244 • www.iapmort.org CERTIFICATE OF LISTING IAPMO Research and Testing, Inc. is a product certi�cation body in which its product certi�cation system includes inspection and testing of samples taken from the supplier’s stock or from the market or a combination of both to verify compliance to the requirements of applicable codes and standards.
- Page 32 IAPMO RESEARCH AND TESTING, INC. CERTIFICATE OF LISTING Issued To: FOSHAN XIARUN HEALTHTEC CO., LTD. E�ective Date: June 2023 File Number: 14474 Product: Plumbing Fixture Fittings Void After: June 2028 This certi cate is not evidence of current listing.To verify listing status, visit the IAPMO R&T Product Listing Directory at pld.iapmo.org Identification: Plumbing supply fittings shall be marked with the manufacturer's recognized name, trademark, or other mark or, in the case of private labeling, the name, trademark or other mark of the customer for whom the fitting was manufactured.
- Page 33 C E R T I F I C A T E O F C O M P L I A N C E Certificate Number UL-US-L472949-11-31804102-2 Report Reference E472949-20140813 Date 2-Nov-2023 T SPA MFG LLC Issued to: 10520 Kinghurst St Houston, TX 77099 United States QMTX - Plumbing Accessories...
- Page 34 C E R T I F I C A T E O F C O M P L I A N C E Certificate Number UL-CA-L472949-31-31804102-2 Report Reference E472949-20140813 Date 2-Nov-2023 T SPA MFG LLC Issued to: 10520 Kinghurst St Houston, TX 77099 United States QMTX7 - Plumbing Accessories Certified for Canada...
- Page 35 C E R T I F I C A T E O F C O M P L I A N C E Certificate Number UL-US-L472949-11-31804102-2 Report Reference E472949-20140813 Date 2-Nov-2023 This is to certify that representative samples of the product as specified on this certificate were tested according to the current UL requirements Model Category Description...
- Page 36 T-SPA MFG, LLC 10510 Kinghurst Dr Houston, TX 77099 1(888)508-8772 WWW.TSPALLC.COM Info@tspallc.com ©2024 T-SPA. All rights reserved. Design and Specifications are subject to change without notice.
