- Page 1 AMPLIFIER Owner’s Manual Models: XM12.1 XM20.1 XM15.4 XM30.2 JAVELIN...
- Page 2 15.0in L x 7.5in W x 2.3in H All amplifer power specifications listed are CEA-2006 compliant and have been rated accordingly. Amplifiers were tested at 14.4V with a 4 ohm load and ≤ 1% THD+N © 2015 Exile Audio • www.exileaudio.com Amplifier Manual...
- Page 3 This must be connected to the fused positive terminal (+12V) of the car’s battery. REMOTE This must be connected to switched +12V, usually a trigger wire coming from the head unit or ignition. Amplifier Manual © 2015 Exile Audio • www.exileaudio.com...
- Page 4 This amplifier requires two 40A fuses. the vehicle. 12V+ This must be connected to the fused positive terminal (+12V) of the car’s battery. © 2015 Exile Audio • www.exileaudio.com Amplifier Manual...
- Page 5 This amplifier requires two 40A fuses. the vehicle. 12V+ This must be connected to the fused positive terminal (+12V) of the car’s battery. Amplifier Manual © 2015 Exile Audio • www.exileaudio.com...
-
Page 6: Monoblock Power Amplifier
This must be connected to the fused positive terminal (+12V) of the car’s battery. REMOTE This must be connected to switched +12V, usually a trigger wire coming from the head unit or ignition. © 2015 Exile Audio • www.exileaudio.com Amplifier Manual... - Page 7 This must be connected to the fused positive terminal (+12V) of the car’s battery. REMOTE This must be connected to switched +12V, usually a trigger wire coming from the head unit or ignition. Amplifier Manual © 2015 Exile Audio • www.exileaudio.com...
-
Page 8: Power Amplifier
Aux Input: Battery Battery phone/ mp3 player Ground Distribution Block 4 ga. Cabin Subwoofer Tower zoned line driver Amplifier Amplifier Amplifier Input Input Input 4ohm 2ohm subwoofer tower speakers 2ohm cabin speakers © 2015 Exile Audio • www.exileaudio.com Amplifier Manual... -
Page 9: Installation Diagram
LPF Settings: For Subwoofer Config Setting: Starting at 30Hz Set to 2 (fully turned counterclockwise), Use this setting when 1 input is available turn the knob to 11 o’clock from the source. 11 o’clock Amplifier Manual © 2015 Exile Audio • www.exileaudio.com... -
Page 10: Installation Diagrams
Starting at 30Hz Set to 4 (fully turned counterclockwise), Use this setting when only 2 inputs (front & turn the knob to 11 o’clock sub) are available from the source. 11 o’clock © 2015 Exile Audio • www.exileaudio.com Amplifier Manual... - Page 11 Starting at 30Hz Set to 6 (fully turned counterclockwise), Use this setting when all 3 inputs (front, rear turn the knob to 11 o’clock & sub) are available from the source. 11 o’clock Amplifier Manual © 2015 Exile Audio • www.exileaudio.com...
- Page 12 LIMITED WARRANTY Exile warrants this product to be free from defects in material and workmanship under normal use for a period of one year from date of original purchase when purchased from an Authorized Exile Dealer. If the product is labeled B Stock/Refurbished and purchased from an Authorized Exile Dealer, it is warranted for 90 days from date of purchase, regardless of place of installation.
