2.0 Microscope at a Glance

Microscope at a Glance
3 & 4
15 & 16
5 & 6
7 & 14
17
12
1. Monocular Head
2. Stand
3. Nosepiece
4. Objective Lens
5. Attachable Mechanical Stage
6. Stage
7. Condenser Knob
8. Fine Adjustment Knob
9. Coarse Adjustment Knob
10. Light Intensity Adjust
Note: Microscope features may vary based on your location, language,
carrier, and model number. Accessory parts may incur additional fees.
Contact your local distributor to ensure the features.
1
BIMC-01NS
11. Power Plug (DC 5V)
12. On/Off Switch
13. Viewing Head adjust
14. Iris Turning
15. Y-axis movement
16. X-axis movement
17. Light Source Cover
Page 4
13
2
9
8
11
10
