1005339COM
TV Stand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
B341005339COM1
Tough
Advertisement
Related Manuals for Ameriwood HOME 1005339COM
Summary of Contents for Ameriwood HOME 1005339COM
- Page 1 1005339COM TV Stand B341005339COM1 Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 ESTIMATED ASSEMBLY TIME: 2 HOUR... -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. -
Page 5: Board Identification
Board Identification Not actual size Left Panel Right Panel Left Partition Right Partition 31005339010 31005339020 31005339040 31005339030 Bottom 31005339060 31005339050 Center Shelf Center Shelf Rail TV Rail 31005339080 31005339090 31005339070... - Page 6 Board Identification Not actual size Door Back Adjustable Shelf 31005339110 31005339120 31005339100 This part is paperboard construction. It is not made from wood, but ais required for the assembly of your unit. Back Panel K100533910...
-
Page 7: Part List
Part List Note: Your model may have Actual Size extra hardware included. (x18) (x18) (x12) (x20) (x8) #A22620 #A22610 #A21670 #A12110 #A23030 cam lock cam bolt wood dowel confirmat screw 7/16" round head screw (x18) (x2) (x5) (x4) (x12) #A52365 #A12420 #A21960 #A71870... - Page 8 Part List Not Actual Size (x6) (x6) #A54800 #A44325 foot bracket foot (x1) #A82835 (x1) door track #B64356 TV Warning Label...
- Page 9 STEP 1 Quick Assembly (x2) (x3) (x2) Proper orientation of CAM LOCK #A22610 #A22620 #A21670...
- Page 10 STEP 2 Quick Assembly (x2) (x3) (x2) Proper orientation of CAM LOCK #A22610 #A22620 #A21670...
- Page 11 STEP 3 Quick Assembly (x2) (x2) (x2) Proper orientation of CAM LOCK #A22610 #A22620 #A21670...
- Page 12 STEP 4 Quick Assembly (x2) (x2) (x2) Proper orientation of CAM LOCK #A22610 #A22620 #A21670...
- Page 13 STEP 5 Quick Assembly (x8) (x4) Proper orientation of CAM LOCK #A22620 #A21670...
- Page 14 STEP 6 finished edge s face up finished surface...
- Page 15 STEP 7 finished edge s face up finished surface...
- Page 16 STEP 8 (x8) #A23030 finished edge s face up...
- Page 17 STEP 9 (x2) (x10) #A21960 #A22610...
- Page 18 STEP 10 Note: Small pilot hole in top (E) we be located along the front edge.
- Page 19 STEP 11 Notice: Groove in TV Rail (G) will be in front of the cam bolt (1) when attaching the TV Rail (G). Note: You may need to tap the TV Rail (G) in the area of the hidden fasteners (6) to securely insert into the end holes in the left and right partitions (C&D)
- Page 20 STEP 12 (x18) (x6) (x6) #A12420 #A54800 #A44325 With the help of another person, carefully turn your unit over on its top as shown. Using screws (8), attach foot brackets (14) and screw in feet (15).
- Page 21 STEP 13 (x22) #A21110 With the help of another person, carefully turn your unit onto its front. Position back panel as shown. Align squarely with edges of top, bottom, left partition and right partition. Nail (12) straight into back edges as shown. "raw surface"...
- Page 22 STEP 14 (x4) (x20) (x2) (x2) (x4) #A12110 #A71870 #A52365 #A71880 #A17400 Note: The knob (7) and upper door guide (13) will be attached towards the top edge of the Do not fully tighten these 2 screws. Snug fit only.
- Page 23 STEP 15 (x1) #A82835 Using a hammer, gently tap the door track (16) into the groove in the bottom (F).
- Page 24 STEP 16 lower position upper position Press button to lower guide stem. Fig. 1 Fig. 2 The white roller will This part inserts roll on the top part into the track. of the track. Lower the guide stem in the upper door guides (13) as shown in Fig. 1. Position the door a shown.
- Page 25 STEP 17 (x3) #A21960 End View...
- Page 26 STEP 18 (x12) #A80250...
- Page 27 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Apply the TV Warning label to your unit for future reference. NOTICE: Once applied to your model, you will not be able to remove it.
- Page 28 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback.
- Page 29 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 30 Español Página 18 Nota: Sobre el borde frontal encontrará un pequeño agujero (E) previamente perforado. Página 19 Aviso: La ranura del TV Rail (G) debe quedar delante del perno de leva (1) al fijar el TV Rail (G). Nota: Es posible que deba presionar el TV Rail (G) en el área de los sujetadores ocultos (6) para insertarlo de forma segura en los orificios de los extremos de las particiones izquierda y derecha (C&D).
- Page 31 Visite el sitio web de su tienda local, califique su comprado y denos sus comentarios! Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias...
- Page 32 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) du Lundi au Vendredi de 9h à...
- Page 33 Français Page 18 Remarque : Petit trou pilote sur le dessus (E) sera le long du bord avant. Page 19 Remarque : La rainure dans le rail du téléviseur (G) sera devant le boulon à came (1) lors de la fixation du rail du téléviseur (G).
- Page 34 Visitez le site Web de votre détaillant local, évaluez votre produit acheté et laissez-nous quelques commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci...
