1324222COM
Turntable Stand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
B341324222COM0
Tough
Advertisement
Related Manuals for Ameriwood HOME Novogratz 1324222COM
Summary of Contents for Ameriwood HOME Novogratz 1324222COM
- Page 1 Tough Visit: www.ameriwoodhome.com Assembly Difficulty Meter WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit. Tube...
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1 ESTIMATED ASSEMBLY TIME: 1 HOUR... -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. -
Page 4: Board Identification
Board Identification Not actual size Left Panel Right Panel 31324222020 31324222030 31324222010 Bottom Shelf Divider 31324222040 31324222050 31324222060 This part is paperboard construction. It is not made from wood, but is required for the assembly of your unit. Back Panel K132422200 ameriwoodhome.com... - Page 5 Board Identification Not actual size This part is paperboard construction. It is not made from wood, but is required for the assembly of your unit. ameriwoodhome.com...
-
Page 6: Part List
Part List Actual Size (x8) (x8) (x20) (x4) #A22610 #A22620 #A21660 #A23030 cam lock wood dowel confirmat screw cam bolt (x24) (x16) #A21110 #A14220 1/2" screw nail Not Actual Size (x4) #A44620 ameriwoodhome.com... - Page 7 STEP 1 Quick Assembly (x2) (x2) (x2) Proper orientation of CAM LOCK #A22620 #A21660 #A22610 ameriwoodhome.com...
- Page 8 STEP 2 Quick Assembly (x2) (x2) (x2) Proper orientation of CAM LOCK #A22610 #A22620 #A21660 ameriwoodhome.com...
- Page 9 STEP 3 Quick Assembly (x4) (x4) (x4) Proper orientation of CAM LOCK #A22610 #A22620 #A21660 ameriwoodhome.com...
- Page 10 STEP 4 (x12) #A21660 ameriwoodhome.com...
- Page 11 STEP 5 All finished edges will face up. ameriwoodhome.com...
- Page 12 STEP 6 All finished edges will face up. ameriwoodhome.com...
- Page 13 STEP 7 Position the bottom (D) as shown press up against the dividers (F) making sure the wood dowels (3) in the dividers (F) insert into the surface holes of the bottom (D). Fasten bottom (D) to left and right panels (A&B) with screws (4). (x4) #A23030 All finished edges will face up.
- Page 14 STEP 8 All finished edges will face up. ameriwoodhome.com...
- Page 15 STEP 9 IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY. Carefully turn your unit over on its front side as shown. Assure that the unit is square. (x24) Distance from corner to corner must be equal as shown. #A21110 Flush bottom edge of back panel (G) with bottom edge of bottom (D).
- Page 16 STEP 10 When mounting legs (7), be sure the legs angle outward. (x16) (x4) #A14220 #A44620 Front View Side View ameriwoodhome.com...
- Page 17 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 30 lbs 13.6 kg 25 lbs 11.3 kg 5 lbs 2.3 kg (each opening) Warning: Risk of injury to persons - do not place a television on this furniture.
- Page 18 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
- Page 19 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 20 Visite el sitio web de su tienda local, califique su comprado y denos sus comentarios! Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias ameriwoodhome.com...
- Page 21 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) du Lundi au Vendredi de 9h à...
- Page 22 Visitez le site Web de votre détaillant local, évaluez votre produit acheté et laissez-nous quelques commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci ameriwoodhome.com...
