1053214COM
1053301COM
1053342COM
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Secure Your Furniture
Keep your home and family safe
with the wall anchor kit that is
included with the product.
Serious or fatal crushing injuries can
occur from tipping furniture.
WARNING: Manufacturer assumes no liability
for improper installation or excessive loads
placed on screws or bracket. This wall anchor
is not a substitute for proper adult supervision.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
B341053000COM0
Tough
You
Tube
Advertisement
Related Manuals for Ameriwood HOME 1053214COM
Summary of Contents for Ameriwood HOME 1053214COM
- Page 1 Easy Tough Assembly Difficulty Meter Serious or fatal crushing injuries can occur from tipping furniture. Follow Ameriwood Home WARNING: Manufacturer assumes no liability for improper installation or excessive loads placed on screws or bracket. This wall anchor Tube is not a substitute for proper adult supervision.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 - Open your item in the area you plan to keep it to avoid excessive heavy lifting. -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. - Page 4 Before You Start Please Note: You may need to lightly tap the wood dowels into the holes during your assembly process. ameriwoodhome.com...
-
Page 5: Board Identification
1053214COM - PARTS LIST Board Identification Not actual size Back 31053000050 31053214030 Right Panel Left Panel Bottom Support 31053214010 31053214020 31053214040 31053000060 SIDE SIDE (x5) (x5) Left Drawer Side Right Drawer Side (x5) Kick 399921673462010L 399921673462010R Drawer Front 31053214070 31053214080 This part is paperboard construction. - Page 6 1053301COM - PARTS LIST Board Identification Not actual size Back 31053000050 31053301030 Left Panel Right Panel Bottom Support 31053301010 31053301020 31053301040 31053000060 SIDE SIDE (x5) (x5) Left Drawer Side Right Drawer Side (x5) Kick 399921673462010L 399921673462010R Drawer Front 31053301070 31053301080 This part is paperboard construction.
- Page 7 1053342COM - PARTS LIST Board Identification Not actual size Back 31053000050 31053342030 Left Panel Right Panel Bottom Support 31053341010 31053342020 31053342040 31053000060 SIDE SIDE (x5) (x5) Left Drawer Side Right Drawer Side (x5) Kick 399921673462010L 399921673462010R Drawer Front 31053342070 31053342080 This part is paperboard construction.
- Page 8 Board Identification Not actual size This part is paperboard construction. It is not made from wood, but is required for the assembly of your unit. SIDE BACK SIDE ameriwoodhome.com...
-
Page 9: Part List
Part List Actual Size (x12) (x12) (x8) (x50) (x44) #A22610 #A21660 #A22620 #A11080 #A12120 cam bolt wood dowel 7/16" pan screw cam lock 7/16" flat screw (x10) (x28) (x20) (x4) #A11600 #A12930 #A21110 #A53510 1-1/4" flat 1-1/8" pan screw nail angle bracket Not Actual Size left cabinet member... - Page 10 STEP 1 (x4) (x1) Do not fully tighten this screw. finished edge ameriwoodhome.com...
- Page 11 STEP 2 Quick Assembly (x8) (x6) (x8) (x4) Proper orientation of CAM LOCK ameriwoodhome.com...
- Page 12 STEP 3 mark with a "L" left cabinet member (x4) (x2) (x1) (x15) (x5) Quick Assembly Proper orientation of CAM LOCK finished edge ameriwoodhome.com...
- Page 13 STEP 4 mark with a "R" right cabinet member (x1) (x15) (x2) (x4) (x5) Quick Assembly Proper orientation of CAM LOCK finished edge ameriwoodhome.com...
- Page 14 STEP 5 finished edge ameriwoodhome.com...
- Page 15 STEP 6 finished edges face up ameriwoodhome.com...
- Page 16 STEP 7 finished edges face up ameriwoodhome.com...
- Page 17 STEP 8 finished edges face up ameriwoodhome.com...
- Page 18 STEP 9 (x6) (x28) #A12120 #A21110 IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY. With the help of another person, carefully turn your unit over on its front side. Make sure the unit is square.
- Page 19 STEP 10 (x10) Carefully tap the drawer bracket (10) onto each drawer side as shown. SIDE SIDE bracket orientation bracket orientation ameriwoodhome.com...
- Page 20 STEP 11 (x20) Be sure to center the groove in the drawer sides with the groove in the drawer front (F). SIDE SIDE Please note, you will repeat this step for each of the 5 drawers. ameriwoodhome.com...
- Page 21 STEP 12 (x20) Note: You will need to tap the drive fastener (7) with a hammer to securely fasten. BACK SIDE finished surface SIDE ameriwoodhome.com...
- Page 22 STEP 13 left drawer member right drawer member (x5) (x20) (x10) (x10) Attach the slides first and then the knobs. BACK SIDE SIDE ameriwoodhome.com...
- Page 23 STEP 14 (x10) (x5) Turn each drawer over. Using screws (5), attach the drawer brace (14) as shown. BACK ameriwoodhome.com...
- Page 24 STEP 15 For Masonry, Concrete, or other wall materials: Consult your local hardware store for appropriate anchors to securely attach the safety bracket. (x1) IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT.
- Page 25 STEP 16 Note: The drawer bracket holes are slotted. Drawer fronts can be adjusted by loosening screws, making needed adjustments and retightening screws. roller cabinet member drawer runner roller ameriwoodhome.com...
- Page 26 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 25 lbs 11.3 kg 50 lbs (each drawer) 22.7 kg Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
- Page 27 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
- Page 28 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 29 Español Página 10 No apriete completamente este tornillo. Página 18 ¡IMPORTANTE! EL PANEL TRASERO ES UNA PARTE ESTRUCTURAL DE ESTA UNIDAD Y DEBE SER INSTALADO CORRECTAMENTE. Con la ayuda de otra persona, voltee cuidadosamente su unidad sobre su lado frontal. Asegúrese de que la unidad está...
- Page 30 Español Página 24 Para mampostería, hormigón u otros materiales de pared: Consulte en su ferretería local los anclajes apropiados para fijar el soporte de seguridad de forma segura. IMPORTANTE: ESTA UNIDAD DEBE ESTAR FIJADA A LA PARED PARA EVITAR QUE SE VUELQUE. SIGA ESTAS INSTRUCCIONES PARA INSTALAR EL SOPORTE DE SEGURIDAD ANTIVUELCO SUMINISTRADO CON ESTE PRODUCTO.
- Page 31 Visite el sitio web de su tienda local, califique su comprado y denos sus comentarios! Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias ameriwoodhome.com...
- Page 32 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) du Lundi au Vendredi de 9h à...
- Page 33 Français Page 10 Ne serrez pas complètement cette vis. Page 18 IMPORTANT! LE PANNEAU ARRIÈRE EST UNE PARTIE STRUCTURELLE DE CET APPAREIL ET DOIT ÊTRE INSTALLÉ CORRECTEMENT. Avec l'aide d'une autre personne, retournez soigneusement votre appareil sur sa face avant. Assurez-vous que l'appareil est carré.
- Page 34 Français Page 24 Pour la maçonnerie, le béton ou d'autres matériaux muraux : Renseignez-vous auprès de votre quincaillerie locale pour obtenir des ancrages appropriés afin de fixer solidement le support de sécurité. IMPORTANT : CET APPAREIL DOIT ÊTRE FIXÉ AU MUR POUR ÉVITER TOUT BASCULEMENT. SUIVEZ CES INSTRUCTIONS POUR INSTALLER LE SUPPORT DE SÉCURITÉ...
- Page 35 Visitez le site Web de votre détaillant local, évaluez votre produit acheté et laissez-nous quelques commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci ameriwoodhome.com...
