IMPORTANT!! PLEASE READ ENTIRE INSTRUCTION SHEET BEFORE ASSEMBLY!!
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, PLEASE KEEP INSTRUCTION SHEET, WARRANTY CARD AND RECEIPT
Step 1:
Identify all parts packed in carton against the parts list. Remove all protective materials. Place parts on a
non-abrasive surface to avoid scratching. If you are missing any parts or are unsure how to proceed with assembly,
please call our Customer Service Center immediately at 1-800-416-3511.
any parts are damaged or missing.
IMPORTANT NOTE: This item is to be used with and assembled to item
,
Step 2:
Position items
AGQ08134
A
join items by attaching metal plate to the cross bars of the seat. Guide the bolts through the holes in the metal plates
and into the pre-drilled holes in the seat cross bar of chair.
adjustments to the alignment of all parts (items), tighten bolts. Tighten bolts a few revolutions at a time, alternating
between bolt joints until all bolts are tight.
Your sectional seating set is now ready for use. If you have any questions, please call our Customer Service Center
Step 3:
.
at 1-800-416-3511
IMPORTANT NOTE: Damage to welds or frames resulting from over tightened bolts or improper assembly is not
covered under our warranty. Please read all instructions carefully before assembly. If you have any questions
regarding your assembly, call our Customer Service Center at 1-800-416-3511.
AGQ08134
GQ
08
129
and A
GQ
08 3 as shown in diagram. Using bolts and washers as shown,
1 3
Hand tighten only.
Do not over tighten.
A
F
B
C
D
Do not attempt to assemble the chair if
AGQ08134&AGQ08133
.
After making any necessary
AGQ08133
Page 2
* NOTE: PARTS SHOWN ON PARTS LIST ARE NOT TO SCALE
PART LIST
DESCRIPTION
A
CHAIR FRAME
B
1/4" X 18 MM BOLT
Ø 6.5 X 1.0 MM
C
WASHER
D
METAL PLATE
E
HEX BOLT DRIVER
F
BOLT COVER
FOOT CAP
FACTORY ASSEMBLY
FOOT CAP
AGQ08129
ORDER PART # QTY
1
AK0763
4
HW0035
4
HW0004
2
HW0743
1
HW0006
4
HW0105
FC0030
