On the R7000 Smart WiFi Router that will run in Bridge mode, select Advanced >
2.
Advanced Setup > Wireless Settings.
Scroll down and select the Use other operation mode check box and the Enable Bridge
3.
mode radio button.
The screen adjusts.
Click the setup bridge mode wireless settings button.
4.
Specify the settings of the other router to which this router will connect.
5.
a. Select the wireless network frequency (2.4 GHz or 5 GHz).
For 802.11ac mode, select 5 GHz.
b. In the Name (SSID) field, enter the wireless network name (SSID).
c. In the Security Option section, select a radio button.
d. If prompted, type the passphrase (the WiFi password that you use to connect
wirelessly to the other router).
Click Apply.
6.
The settings for the other router are saved and the Advanced Wireless Settings screen
displays.
Click Apply on the Advanced Wireless Settings screen.
7.
R7000 Smart WiFi Router
Advanced Settings
97
