Vig670W
Motherboard
Manual
.
.
C O M P U T E R S
N E T W O R K S
S O L U T I O N S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vig670W and is the answer not in the manual?

Questions and answers

Summary of Contents for Viglen Vig670W

  • Page 1 Vig670W Motherboard Manual C O M P U T E R S N E T W O R K S S O L U T I O N S...
  • Page 2 Viglen’s Environment laboratory To gain a 'CE' mark, the Viglen computer range has had to undergo many difficult tests to ensure it is Electromagnetically Compatible. These are carried out in the in-house 'Environment lab' at Viglen Headquarters. We have made every effort to guarantee that each computer leaving our factory complies fully with the correct standards.
  • Page 3 International Business Machines Corporation. Core i3/i5/i7 Pentium® are registered trademarks of Intel® Corporation. All other trademarks are acknowledged. Genie, Vig, Viglen, and Omnino are trademarks of Viglen Limited. Copyright and Patents This manual and all accompanying software and documentation are copyrighted and all rights reserved.
  • Page 4: Table Of Contents

    Installing & Removing Memory Modules Replacing the Clock/CMOS RAM Battery Chapter 3: Solving Problems Resetting the System Troubleshooting Procedures Problems & Suggestions Chapter 4: System BIOS What is the BIOS? The Power-On Sequence BIOS Upgrades BIOS Setup Chapter 5: Suggestions V1.0 Vig670W Motherboard Manual...
  • Page 5: Chapter 1: Motherboard Overview

    10/100/1000 network connection, as well as 2 USB 3.0 ports and 2 USB 2.0 ports to enrich your multimedia creation experience. The Vig670W supports Intel Core i3, i5, i7 processors and Intel Pentium processors as well as being Microsoft Windows 7 Premium WHQL certified.
  • Page 6: Feature Summary

    Integrated HD audio codec by Realtek® ALC662  Support JACK detection, multi-streaming and anti-pop functions  With ALC105 amplifier to support speakers  Front panel header  ® Gigabit (10/100/1000 Mbits/s) LAN subsystem using the Realtek RTL8111F Gigabit Ethernet Controller V1.0 Vig670W Motherboard Manual...
  • Page 7 Expansion Capabilities  ·1x mini PCIE full card slot,support Intel® 310 series SSD cards or others with same pin define  ·1x mini PCIE half card slot,support 802.11a/b/g/n WIFI and Bluetooth 3.0+HS BIOS  AMI EFI BIOS V1.0 Vig670W Motherboard Manual...
  • Page 8 If non-SPD memory is installed, the BIOS will attempt to correctly configure the memory settings, but performance and reliability may be impacted or the SO-DIMMs may not function under the determined frequency. V1.0 Vig670W Motherboard Manual...
  • Page 9 8 full range channels at 24-bit/96kHz audio of lossless audio formats such as Dolby TrueHD or DTS HD Master Audio. The maximum supported resolution is 1920 x 1200 at 60 Hz refresh (WUXGA). The HDMI port is compliant with the HDMI 1.3 specification. V1.0 Vig670W Motherboard Manual...
  • Page 10 Figure 1: Audio Connectors  Line-Out (Green) - Line Out, is a connector for speakers or headphones.  Mic (Pink) - Mic, is a connector for microphones. V1.0 Vig670W Motherboard Manual...
  • Page 11 Link Green LAN activity is occurring. LAN link is established. Blinking LAN activity is occurring. Data Green/yellow 10 Mb/s data rate is selected. rate 100 Mb/s data rate is selected. 1000 Mb/s data rate is selected. V1.0 Vig670W Motherboard Manual...
  • Page 12 POST. When the voltage drops below a certain level, the BIOS Setup program settings stored in CMOS RAM (for example, the date and time) might not be accurate. Replace the battery with an equivalent one. V1.0 Vig670W Motherboard Manual...
  • Page 13 If only the supervisor password is set, the computer boots without asking for a password. If both passwords are set, you can enter either password to boot the computer. V1.0 Vig670W Motherboard Manual...
  • Page 14: System Board Components

    SATA Power_ODD Mini PCI-E Half-card Slot System Fan Header Clear_CMOS Front Panel Header CPU Fan Header LVDS Connector Chassis Speaker Connector SoDIMM Slots Front Panel Audio Header Display Brightness Header Battery Connector USB2.0_12 Header Back Panel V1.0 Vig670W Motherboard Manual...
  • Page 15: Back Panel Connectors

    These audio connectors are used for audio devices (MIC-IN, LINE-OUT). Note: The back panel audio line out connectors is designed to power headphones or amplified speakers only. Poor audio quality occurs if passive (non-amplified) speakers are connected to this output. V1.0 Vig670W Motherboard Manual...
  • Page 16: Chapter 2: System Board Options

    Chapter 2: System Board Options The Vig670W motherboard is capable of accepting Intel® Core i3, i5, i7 processors and Intel Pentium processors. RAM can be upgraded to a maximum of 16GB using DDR3 1066, 1333MHz or 1600MHz Non ECC Unbuffered memory.
  • Page 17: Before You Begin

    BEFORE YOU BEGIN Make sure you are earthed and free of static charge before you open the computer case. If you are unsure about upgrading your computer, return it to Viglen so a qualified engineer can perform the upgrade. STEPS TO TAKE TO PREVENT STATIC DISCHARGE: 1.
  • Page 18: System Board Jumper Settings

    RAM onboard has a power supply from an external battery to keep the data of the system configuration. The CMOS RAM allows the system to automatically boot OS every time it is turned on. Status Normal Clear CMOS Figure 5: Clear CMOS jumper V1.0 Vig670W Motherboard Manual...
  • Page 19: Motherboard Connectors

    50 ms to signal the power supply to switch on or off. (The time Power Switch Header requirement is due to internal debounce circuitry on the board.) At least two seconds must pass before the power supply will recognize another on/off signal. V1.0 Vig670W Motherboard Manual...
  • Page 20 DC connector is compatible with a 7.4 mm/OD (outer diameter) and 5.1 mm/ID (inner diameter) plug, where the inner contact is +19 (±10%) V DC and the shell is GND. The maximum current rating is 12 A. V1.0 Vig670W Motherboard Manual...
  • Page 21 Signal Name Signal Name [Port 1] Left channel Ground [Port 1] Right channel PRESENCE# (Dongle present) [Port 2] Right channel [Port 1] SENSE_RETURN SENSE_SEND (Jack detection) Key (no pin) [Port 2] Left channel [Port 2] SENSE_RETURN V1.0 Vig670W Motherboard Manual...
  • Page 22 USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. Figure 8: Front USB connectors Front USB Connector: USB20_5 Figure 10: Front USB connector - single    V1.0 Vig670W Motherboard Manual...
  • Page 23 CPU fan control. Figure 11: Fan Power connectors Table 5: System FAN header, CPU FAN header 4-Wire support 3-Wire support +12V power +12V power FAN_FB FAN_PWM Control V1.0 Vig670W Motherboard Manual...
  • Page 24 This connector is a high-speed Serial ATA interface port. Each connector can connect to one Serial ATA device. Figure 12: Serial ATA Connector NOTE: Please do not fold the serial ATA cable into 90-degree angle. Otherwise, data loss may occur during transmission. V1.0 Vig670W Motherboard Manual...
  • Page 25: Upgrading The Cpu

    2. Rotate the socket lever to lift the load plate away from the socket (Figure 14, A). Make sure that the load plate is in the fully open position (Figure 13, B) while being careful not to damage adjacent components. Do not touch the socket contacts. Figure 14: Lift the load plate V1.0 Vig670W Motherboard Manual...
  • Page 26 B) and that the notches on the processor align with the posts on the socket (Figure 16, C). Lower the processor straight down without tilting or sliding it in the socket (Figure 16, A). Figure 16: Install the processor V1.0 Vig670W Motherboard Manual...
  • Page 27 (Figure 17, C, and D). The socket cover (Figure 17, B) will pop off as shown. Figure 17: Secure the load plate in place 6. Pick up the socket cover and remove it from the desktop board. V1.0 Vig670W Motherboard Manual...
  • Page 28 Make sure the four hooks are in the proper position before you install the cooler. If the heatsink is held in by screws, position heatsink correctly and screw into place. Figure 18: Connecting the processor fan heat sink power cable to the processor fan header V1.0 Vig670W Motherboard Manual...
  • Page 29: Installing & Removing Memory Modules

    5. When the SO-DIMM is seated, push down until the retaining arms at either ends of the socket snap into place. Make sure the clips are firmly in place. 6. Replace the computer cover. Figure 19: Memory Installation V1.0 Vig670W Motherboard Manual...
  • Page 30 Hold the SO-DIMM by the edges, lift it away from the socket, and store it in an antistatic package. 5. Reinstall and reconnect any parts you removed or disconnected to reach the SO- DIMM sockets. Figure 20: Removing Memory Modules V1.0 Vig670W Motherboard Manual...
  • Page 31: Replacing The Clock/Cmos Ram Battery

    CAUTION! Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by Viglen. Discard used batteries according to manufacturer’s instructions. To replace the battery, carry out the following: 1.
  • Page 32: Chapter 3: Solving Problems

    The second part lists error code messages that might be displayed. Please remember that if you cannot solve the problem by yourself then you should contact Viglen Technical Support for further assistance. Viglen Technical Support can be reached in the following ways: Telephone: 01727 201 850 Fax:...
  • Page 33: Troubleshooting Procedures

    Errors that prevent the boot process from continuing (fatal errors), are communicated by a series of audible beeps. If this type of error occurs, refer to the error codes and messages listed at the end of this chapter. 6. Confirm that the operating system has loaded. V1.0 Vig670W Motherboard Manual...
  • Page 34: Problems & Suggestions

    Check that the brightness and contrast controls are properly adjusted. Check that the video signal cable is properly installed. Make sure a video board is installed, enabled, and the jumpers are positioned correctly. Reboot the system. V1.0 Vig670W Motherboard Manual...
  • Page 35 System halts before This indicates a fatal system error that requires immediate service attention. Note the screen display and write down any beep code completing POST emitted. Provide this information to your dealer service department / Technical Support. V1.0 Vig670W Motherboard Manual...
  • Page 36: Chapter 4: System Bios

    (also known as the CMOS RAM) and provides a special Setup program to change this information. The BIOS in your Viglen computer is guaranteed to be fully compatible with the IBM BIOS. It has been written by Phoenix Award BIOS, an industrial leader in the field of BIOS software.
  • Page 37: Bios Upgrades

    AMIDEDOS.EXE utility or in Windows using the AEFUWIN utility that is available from the Viglen FTP site. This utility does BIOS upgrades as follows:  Updates the flash BIOS from a file on a disk or within the location of the utility.
  • Page 38: Bios Setup

    The main menu lists the setup functions you can make changes to. You can use the arrow keys ( ↑↓ ) to select the item. The on-line description of the highlighted setup function is displayed at the bottom of the screen. V1.0 Vig670W Motherboard Manual...
  • Page 39  Security - Use this menu to set supervisor and user passwords.  Save & Exit - This menu allows you to load the BIOS default values or factory When enter the BIOS Setup utility, follow the processes below for general use. V1.0 Vig670W Motherboard Manual...
  • Page 40 3. Save & Exit Setup: Use the arrow keys (←, →, ↑, ↓) to select the [Save Changes & Reset] in [Save & Exit] menu, and press <Enter>. A pop-up message will appear, please select [Yes] and press<Enter> to save the configurations and exit BIOS setup utility. Figure 12: Save & Exit Setup V1.0 Vig670W Motherboard Manual...
  • Page 41 1. From the BIOS main menu select the ‘Boot’ tab. Figure 13: Main menu 2. In the ‘Boot’ tab scroll down the options to ‘Fast Boot’ and select this option. Set the ‘Fast Boot’ option to ‘Enabled’. V1.0 Vig670W Motherboard Manual...
  • Page 42 3. In the ‘Boot’ tab scroll down the options to ‘UEFI Boot’ and select this option. Set the ‘UEFI Boot’ option to ‘Enabled’. For Windows 7 and Windows XP operating systems it should be set to Disabled. Figure 15: UEFI Boot option V1.0 Vig670W Motherboard Manual...
  • Page 43 To Enable Secure Boot From the BIOS tab options select the ‘Security’ tab and select the ‘Secure Boot’ option, set the ‘Secure Boot’ option to ‘Enabled’ Figure 16: Secure Boot Enabled/Disabled option V1.0 Vig670W Motherboard Manual...
  • Page 44 Security Tab options and Set the Secure Boot Mode to ‘Custom’ Figure 17: Secure Boot Enabled/Disabled option 2. In Custom mode scroll down the active options in the Security Tab option list and Select the ‘Key Management’ Option. Figure 18: Secure Boot V1.0 Vig670W Motherboard Manual...
  • Page 45 Figure 19: Default Key Provisioning 4. In the Key management options select the ‘Install default Secure Boot Keys’ option and confirm Installation in the pop up to install the default secure Boot Keys. Figure 20: Default Secure Boot Keys V1.0 Vig670W Motherboard Manual...
  • Page 46 5. Once the Default Secure Boot keys are installed it will state ‘Installed’ as shown in below image Figure 21: Default Secure boot keys V1.0 Vig670W Motherboard Manual...
  • Page 47 1. In the Key management options select ‘Default Key Provisioning’ and Set the option to ‘Disabled’ Figure 22: Default Key Provisioning 2. Select ‘Clear Secure Boot Keys’ and confirm Installation in the prompt pop up to clear the default secure Boot Keys. Figure 23: Reset platform V1.0 Vig670W Motherboard Manual...
  • Page 48 Once all BIOS settings have been configured press F4 key to Save and Exit the BIOS Setup. For Non EFI OS support (Windows 7) secure boot keys must be set to default and secure boot disabled. Otherwise system will not detect SATA hard disk drive under boot menu. V1.0 Vig670W Motherboard Manual...
  • Page 49: Chapter 5: Suggestions

    Viglen is interested in continuing to improve the quality and information provided in their manuals. Viglen has listed some questions that you may like to answer and return to Viglen. This will help Viglen help to keep and improve the standard of their manuals.
  • Page 50 Are there any technological improvements that could be made to the system? 7. Other points you would like to mention? Please return this slip to: Product Development Dept. Viglen Ltd. 7 Handley Page Way Colney Street St Albans Hertfordshire AL2 2DQ V1.0 Vig670W Motherboard Manual...
  • Page 51 Notes V1.0 Vig670W Motherboard Manual...
