Summary of Contents for Mission Critical Xantrex Freedom X 1800
- Page 1 Owner’s Guide Freedom X 1800 (12VDC) Freedom X 1800 (12VDC) Inverter 817-1800-02...
- Page 2 Copyright © 2023 Xantrex LLC. All Rights Reserved. All trademarks are owned by Xantrex LLC and its affiliates. Exclusion for Documentation UNLESS SPECIFICALLY AGREED TO IN WRITING, SELLER (A) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION;...
- Page 3 Information About Your System As soon as you open your product, record the following information and be sure to keep your proof of purchase. Serial Number ____________________________ Product Number ____________________________ Purchased From ____________________________ Purchase Date ____________________________ To view, download, or print the latest revision, visit the website shown under Contact Information. 975-1169-01-01...
- Page 4 Purpose Accessory in vehicle ignition system The purpose of this Owner’s Guide is to provide explanations and Absorbed Glass Mat (a battery type) procedures for installing, operating, configuring, maintaining, and Battery Temperature Sensor troubleshooting a Freedom X 1800 (12VDC) Inverter for Direct Current [Z] Commercial and Fleet Vehicle.
-
Page 5: Important Safety Instructions
IMPORTANT SAFETY DANGER INSTRUCTIONS DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. ’ READ AND SAVE THIS WNER UIDE FOR FUTURE REFERENCE WARNING This guide contains important safety instructions for the Freedom WARNING indicates a hazardous situation which, if not avoided, could result X that must be followed during installation, operation, in death or serious injury. -
Page 6: Product Safety Information
Product Safety Information Turning the inverter to Standby mode using the Power button Product Safety Information on the front panel will not reduce an electrical shock hazard. 1. Before using the inverter, read all instructions and cautionary 8. The inverter must be provided with an equipment-grounding markings on the unit, the batteries, and all appropriate conductor connected to the AC input ground. - Page 7 Product Safety Information DANGER WARNING HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FIRE AND EXPLOSION HAZARD FLASH Unit’s components may produce arcs or sparks. Apply appropriate personal protective equipment (PPE) and follow safe Do not install near batteries, in machinery space, or in an electrical work practices.
- Page 8 Product Safety Information NOTES: CAUTION Follow these instructions and those published by the battery manufacturer and the manufacturer of any equipment you intend to use in the vicinity of the battery. ELECTRICAL SHOCK AND FIRE HAZARD Review cautionary markings on these products and on the Do not open.
-
Page 9: Precautions When Working With Batteries
Precautions When Working With Batteries Precautions When Working With CAUTION Batteries PHYSICAL INJURY HAZARD IMPORTANT: Battery work and maintenance must be done by This Freedom X 1800 (12VDC) Inverter is not intended for use by qualified personnel knowledgeable about batteries to ensure persons (including children) with reduced physical, sensory, or compliance with battery handling and maintenance safety mental capabilities or lack of experience and knowledge, unless... -
Page 10: Precautions When Placing The Unit
Precautions When Placing the Unit NOTES: Precautions When Placing the 1. Mount and place the Freedom X 1800 (12VDC) Inverter unit Unit away from batteries in a well ventilated compartment. 2. Always have someone within range of your voice or close enough to come to your aid when you work near a lead-acid WARNING battery. -
Page 11: Emi Information To The User
Regulatory EMI Information to the User NOTICE This equipment has been tested and found to comply with the RISK OF INVERTER DAMAGE limits for a Class B digital device, pursuant to part 15 of the FCC / ISED CAN ICES-003 Class B Rules. These limits are Never allow battery acid to drip on the inverter when designed to provide reasonable protection against harmful reading gravity, or filling battery. -
Page 12: End Of Life Disposal
End of Life Disposal End of Life Disposal The Freedom X 1800 (12VDC) Inverter is designed with environmental awareness and sustainability in mind. At the end of its useful life, the Freedom X can be decommissioned and disassembled. Components which can be recycled must be recycled and those that cannot be recycled must be disposed of according to local, regional, or national environmental regulations. -
Page 13: Table Of Contents
CONTENTS Important Safety Instructions Basic Installation Procedures Product Safety Information Installation Tools and Materials Precautions When Working With Batteries Step 1: Designing the Installation Precautions When Placing the Unit Step 2: Choosing a Location for the Unit Regulatory Step 3: Mounting the Unit EMI Information to the User Step 4: Connecting the AC Input Cables End of Life Disposal... - Page 14 LCD Screen High Surge Loads LCD Screen Icons Over-temperature Conditions Routine Maintenance Viewing Information During Battery Mode Viewing Information During Grid Mode Maintaining the Freedom X Unit Troubleshooting Adjusting Feature Settings in Configuration Mode Settings Pre-service Checklist Warning Messages Operating in Battery Mode Troubleshooting Reference Turning Inverter Operation ON and OFF Inverter Applications...
-
Page 15: Introduction
1 INTRODUCTION The Freedom X 1800 (12VDC) Inverter is designed with integrated inverting functions and power management features suitable for commercial/fleet vehicle installations. Please read this section to familiarize yourself with the main performance and protection features of the Freedom X. This section includes: Materials List Key Features... -
Page 16: Materials List
Materials List Materials List Key Features The Freedom X 1800 (12VDC) Inverter base package includes the Power for Most The Freedom X inverter provides up to following items: Appliances 1800 watts of continuous utility grade, sine one Freedom X unit wave power derived from a battery bank. It is one Product Notice and extra safety labels designed to handle loads such as microwave one pre-installed DC ground enclosure lug (not shown) - Page 17 Materials List Comprehensive The Freedom X’s built-in protection features Configurable AC The Freedom X allows two speed settings for Protection safeguard your batteries (from unnecessary Transfer Speed the AC transfer from AC Mode to Battery drain) such as the low battery voltage alarm Mode and vice versa which avoids nuisance and shutdown and protect equipment such as resetting of appliances.
- Page 18 Materials List Ignition Control The Freedom X provides two user-selectable options for ignition control: Ignition Auto-on: The Freedom X can automatically turn the inverter on and off in tandem with the vehicle's ignition circuit or a manually operated remote switch. Ignition Lockout: The Freedom X features the ability to inhibit the inverter from operating in the absence of a...
-
Page 19: Features
2 FEATURES This section identifies the default settings and the hardware features of the Freedom X 1800 (12VDC) Inverter. This section includes: Default Settings AC/DC and GFCI Panel Display Panel Side Panel 975-1169-01-01... -
Page 20: Default Settings
Default Settings Default Settings Table 1 lists the default settings for the Freedom X system. You may record your settings in the right-hand column after you have configured the Freedom X. Table 1 Freedom X Default Values Program Item Default Setting Setting Inverter ignition control Low battery cutoff (LBCO) voltage 10.5 volts DC 10.5... -
Page 21: Ac/Dc And Gfci Panel
AC/DC and GFCI Panel AC/DC and GFCI Panel WARNING ELECTRICAL SHOCK HAZARD Use a torque screwdriver to tighten the captive nut panel screw to 5 in-lb (0.56 N-m) torque of force to ensure a proper ground connection and a required tool access to the wiring compartment. Failure to follow these instructions can result in death, serious injury, or equipment damage. - Page 22 AC/DC and GFCI Panel Feature Description Feature Description DC terminal opening for routing (–) negative DC 20 A supplementary protector with reset button cable. Press to recover from an overload condition. Provides protection for the wiring of the GFCI duplex DC terminal opening for routing (+) positive DC receptacle AC output.
-
Page 23: Display Panel
Display Panel Display Panel Table 3 Display Panel Features Feature Description Display panel displays status information on the screen. It is comprised of a display screen, LEDs, and buttons. INPUTBATTTEMP OUTPUTBATTLOAD ERROR Multi-function LCD screen shows status information INPUTBATTTEMP OUTPUTBATTLOAD BYPASS OVERLOAD 100% ERROR... -
Page 24: Side Panel
Side Panel Side Panel Table 4 Side Panel Features Feature Description Captive nut panel screw holds the wiring compartment cover in place. See WARNING above. Wiring compartment cover protects the wiring compartment from debris and keeps the cables secure. Using the captive nut panel screw, the cover can be opened and lifted out during wiring. -
Page 25: Installation
3 INSTALLATION Please read this section for safety information and installation instructions regarding your Freedom X. This section includes: Before You Begin the Installation Installation Codes Basic Installation Procedures Installation Tools and Materials Step 1: Designing the Installation Step 2: Choosing a Location for the Unit Step 3: Mounting the Unit Step 4: Connecting the AC Input Cables Step 5: Connecting AC Output Cables to an Existing AC... -
Page 26: Before You Begin The Installation
Before You Begin the Installation Before You Begin the Installation Codes Governing installation codes vary depending on the specific Installation location and application of the installation. Some examples Before beginning your installation: include the following: The U.S. National Electrical Code (NEC) WARNING The Canadian Electrical Code (CEC) The U.S. -
Page 27: Basic Installation Procedures
Basic Installation Procedures Basic Installation Procedures Installation Tools and Materials You will need the following to install the Freedom X 1800 (12VDC) This section provides sample installation information as a guide Inverter: for your installation. For your convenience, the overall procedure Wire stripper is divided into these main steps: Mounting (#2) screws or bolts... -
Page 28: Step 1: Designing The Installation
Basic Installation Procedures Figure 5 Typical Recreational Vehicle and Fleet Vehicle Step 1: Designing the Installation Installation Most Freedom X installations share common components, and some of these are briefly described in Step 1: Designing the Installation. Figure 5 shows some components and their relationship to each other in a typical vehicle or fleet vehicle installation. - Page 29 Basic Installation Procedures AC Shore Power AC Disconnect and Over-Current A source of 120 volts AC 60Hz sine wave alternating current Protection Device provides energy to pass power through to AC loads. This source Most safety requirements and electrical codes require the is usually the utility grid (power company) or an AC generator.
- Page 30 Basic Installation Procedures AC Distribution Panels Each system requires a method of disconnecting Disconnect the AC circuits. If the over-current protection Devices Most systems incorporate distribution centers both ahead of the devices are circuit breakers, they will also serve as Freedom X (the AC source panel) and between the Freedom X the disconnects.
- Page 31 Basic Installation Procedures Installation codes usually specify solid or stranded, overall size of AC Output Neutral Bonding the conductors, and type and temperature rating of the insulation The neutral conductor of the Freedom X’s AC output circuit (that around the wire. is, AC Output Neutral) is automatically connected to the safety AC breakers and fuses must be sized to adequately protect the ground during inverter operation.
- Page 32 Basic Installation Procedures Ground Fault Circuit Interrupters (GFCIs) DC Cabling A GFCI is a device that de-energizes a circuit when a current to This includes all the cables and connectors between the batteries, ground exceeds a specified value that is less than that required to the DC disconnect and over-current protection device, and the blow the circuit breaker.
- Page 33 Basic Installation Procedures DC Disconnects and Over-Current Devices Table 6 Required Cable Sizes The DC circuit from the battery to the Freedom X must be Cable Length: Minimum Maximum equipped with a disconnect and over-current device. This usually Inverter Battery to Inverter Cable battery consists of a circuit breaker, a “fused-disconnect”, or a separate...
-
Page 34: Step 2: Choosing A Location For The Unit
Basic Installation Procedures Ground Fault Circuit Interrupters (GFCIs) Step 2: Choosing a Location for the A GFCI is a device that de-energizes a circuit when a current to Unit ground exceeds a specified value that is less than that required to blow the circuit breaker. -
Page 35: Step 3: Mounting The Unit
Basic Installation Procedures The Freedom X should only be installed in locations that meet the Step 3: Mounting the Unit following requirements: To mount the Freedom X: Dry. Do not allow water or other fluids to drip or splash on 1. - Page 36 Basic Installation Procedures Figure 6 Approved Mounting Orientations Connecting the DC Equipment Ground WARNING ELECTRIC SHOCK HAZARD Never operate the Freedom X without properly connecting the DC equipment ground. A shock and energy hazard could result from improper grounding. Failure to follow these instructions can result in death, serious injury, or equipment damage.
-
Page 37: Step 4: Connecting The Ac Input Cables
Basic Installation Procedures DC Grounding Locations Step 4: Connecting the AC Input You must connect the DC equipment ground lug to a grounding Cables point—usually the vehicle’s chassis or DC negative bus ground— using recommended copper wire (if insulated then green insulation WARNING with or without one or more yellow stripes) or larger. - Page 38 Basic Installation Procedures AC Wiring and GFCIs The AC input terminal is located inside the unit through the front panel’s ½" trade-size hole (or ¾" trade-size knockoutd) and is You can plug loads of up to 20 amps directly into the GFCI labeled properly as AC IN or AC INPUT.
- Page 39 Basic Installation Procedures Figure 8 Loosening the captive nut panel screw NOTICE REVERSE POLARITY DAMAGE Make sure the wires are connected properly. Improper connections (connecting a line conductor to a neutral conductor, for example) will cause the Freedom X to malfunction and may permanently damage the inverter.
- Page 40 Basic Installation Procedures 8. Connect each AC wire into its corresponding terminal on the Figure 9 Routing the AC input wires no-tool cage clamp terminal block. a. Lift the terminal lever (as shown in the previous figure). b. Insert the wire fully into the open slot. c.
-
Page 41: Step 5: Connecting Ac Output Cables To An Existing Ac Circuit
Basic Installation Procedures Step 5: Connecting AC Output WARNING Cables to an Existing AC Circuit ELECTRICAL SHOCK HAZARD Use a torque screwdriver to tighten the captive nut panel screw to WARNING 5 in-lb (0.56 N-m) torque of force to ensure a proper ground connection and a required tool access to the wiring compartment. - Page 42 Basic Installation Procedures AC Output Connections NOTICE Figure 10 Routing and connecting the AC output wires EQUIPMENT DAMAGE Do not connect any AC source (such as a generator or utility power) to the AC output wiring of the Freedom X. The Freedom X will not operate if its output is connected to AC voltage from another source, and potentially hazardous or damaging conditions may occur.
- Page 43 Basic Installation Procedures 3. Remove the wiring compartment cover, if not already done the Neutral (N), Ground (G), and Line (L) connections. from AC Output Connections on page 28. WARNING ELECTRIC SHOCK HAZARD Use a screwdriver to loosen the captive nut panel screw. Failure to follow these instructions can result in death, serious 9.
-
Page 44: Step 6: Connecting The Dc Cables
Basic Installation Procedures Follow the procedure given below to connect the battery leads to Step 6: Connecting the DC Cables the terminals on the DC end. The cables should be as short as possible and large enough to handle the required current, in NOTICE accordance with the electrical codes or regulations applicable to your installation. - Page 45 Basic Installation Procedures 6. Strip ½" (13 mm) to ¾" (19 mm) of insulation from each To make the DC connections: cable end that will be connected to the inverter cable. The 1. Make sure the inverter is off and no AC or DC is connected amount stripped off will depend on the terminals chosen.
- Page 46 Basic Installation Procedures Figure 12 DC Cable Connections WARNING ELECTRICAL SHOCK HAZARD Tighten the nuts on the DC terminals properly. Loose connections cause excessive voltage drop and may cause overheated wires and melted insulation. Do not over-tighten the nut on the DC input terminals because damage to the DC input terminals may result.
- Page 47 Basic Installation Procedures 15. Replace the wiring compartment cover by tightening the WARNING captive nut panel screw. See the following electrical shock hazard warning. FIRE HAZARD WARNING Do not complete the next step if flammable fumes are present. Explosion or fire may result if the disconnect/battery selector switch ELECTRICAL SHOCK HAZARD is not in the off position.
- Page 48 Basic Installation Procedures Marine DC Grounding Use copper wire that is bare or has insulation rated minimum To connect the DC ground: 105 °C, and connect it between the Chassis Ground lug and the 1. The DC equipment grounding lug (DC ground lug) on the DC end of the Freedom X is used to connect the chassis of the boat’s DC grounding bus or engine negative bus.
-
Page 49: Step 7: Connecting To Port(S) On The Freedom
Basic Installation Procedures Figure 13 ACC input port Step 7: Connecting to Port(s) on the Freedom X Connecting to ACC Signal To enable ignition control: 1. Ensure that AC and DC power are both OFF. 2. Ensure the vehicle’s ignition is turned to OFF position. It is highly recommended to remove battery power by disconnecting the vehicle's battery cables. - Page 50 Basic Installation Procedures Description of Ignition Control Features Connecting to the Remote Port For information about the features and instructions on changing The Freedom X can accommodate the Freedom X Remote Panel the ignition control features, see Operation on page 41. with cable (PN: 808-0817-01) or with the Bluetooth option (PN: 808-0817-02) (sold separately;...
-
Page 51: Step 8: Testing Your Installation
Basic Installation Procedures Testing in Battery Mode Step 8: Testing Your Installation To test the Freedom X: 1. For hard wired installations, ensure shore power is not WARNING present. 2. Press the Power button to turn the inverter on. ELECTRIC SHOCK HAZARD 3. - Page 52 Basic Installation Procedures NOTE: Whether or not the Power button is turned ON, shore power will pass through the Freedom X to the output when shore power is within normal operating range. NOTE: In the event of low or no battery voltage, shore power will pass through the Freedom X to the output even when shore power is outside the normal operating range.
-
Page 53: Marine Installation
Marine Installation Marine Installation Figure 14 Typical Marine Installation Figure 14 illustrates a typical marine installation with the following components: DC Equipment ground – Engine negative bus / DC ground bus Freedom X DC fuse/disconnect/DC circuit breaker 12/24V deep cycle battery bank (house) and protected by a DC fuse in the positive cable Battery isolator DC alternator... -
Page 54: Drip Shield Installation
Marine Installation Drip Shield Installation Figure 15 Drip shields To install the drip shields: The drip shields help to protect the unit from dripping or splashing 1. Gather the four screws needed liquids, which will cause a shock hazard when moisture comes in to fasten a single drip shield to a contact with electrical circuits in the unit. -
Page 55: Operation
4 OPERATION This section includes descriptions of the different modes and settings of the Freedom X 1800 (12VDC) Inverter. This section includes: Freedom X Display Panel Status LED Indicators Function Buttons LCD Screen LCD Screen Icons 975-1169-01-01... -
Page 56: Freedom X Display Panel
Freedom X Display Panel Freedom X Display Panel Status LED Indicators Figure 17 Display Panel Indicator Definition Solid green. Indicates grid mode in which shore power is available and passing through to the loads. INPUTBATTTEMP OUTPUTBATTLOAD ERROR Solid green. Indicates Battery mode BYPASS OVERLOAD (Inverter mode) in which the inverter is... -
Page 57: Function Buttons
Freedom X Display Panel Function Buttons LCD Screen The LCD Screen changes depending on the operating mode of the Button Definition inverter. Figure 18 Parts of the LCD Screen Return to default screen or exit setting mode Next screen or next selection Press and hold for three seconds to go back one step INPUTBATTTEMP... -
Page 58: Lcd Screen Icons
Freedom X Display Panel LCD Screen Icons Icon Definition Icon Definition The load icon is displayed if there is voltage available at the AC output. AC input and output indicator. The bar represents load consumption The wrench icon underneath a number is levels. -
Page 59: Viewing Information During Battery Mode
Viewing Information During Battery Mode Viewing Information During Info and Setting LCD Screen Battery Mode The LCD screen displays information related to battery mode operation. Screen 2 of 4 - Press the Scroll button to move from screen to screen. AC Output Press and hold for three seconds to go back one step. - Page 60 Viewing Information During Battery Mode Info and Setting LCD Screen Screen 4 of 4 - Firmware version Firmware version = U1 1.01 Freedom X 1800 (12VDC) Owner's Guide...
-
Page 61: Viewing Information During Grid Mode
Viewing Information During Grid Mode Viewing Information During Grid Info and LCD Screen Mode Setting 1. The LCD screen displays information related to AC bypass operation. 2. Press the Scroll button to move from screen to screen. Screen 2 of 4 - 3. - Page 62 Viewing Information During Grid Mode Info and LCD Screen Setting Screen 4 of 4 - Firmware version Firmware version = U1 1.01 Freedom X 1800 (12VDC) Owner's Guide...
-
Page 63: Adjusting Feature Settings In Configuration Mode
Adjusting Feature Settings in Configuration Mode Adjusting Feature Settings in To change the default value to a different value: 1. Press and hold the button for three seconds to enter the Configuration Mode feature settings mode. 2. Press the Scroll button to move through the different , Scroll , and... -
Page 64: Settings
Adjusting Feature Settings in Configuration Mode Settings Setting Default Setting Name Range of Values Description Number Value Inverter Ignition See Description of Ignition Control Features on page 36. Control The voltage setting value can be adjusted by 0.1 increments. 10.5 10.0 to 12.8 LBCO Voltage The inverter is able to recover automatically at LBCO voltage... - Page 65 Adjusting Feature Settings in Configuration Mode Setting Default Setting Name Range of Values Description Number Value After changing the output frequency setting, turn the unit off Output Frequency and then on again, in order for the change to take effect. Output Voltage The wattage setting value can be adjusted by 100-W Inverter Output...
- Page 66 Adjusting Feature Settings in Configuration Mode Setting Default Setting Name Range of Values Description Number Value Utility AC Under 85 to 110 In VV Voltage Level The inverter shuts down when there is an over temperature, overload, and short circuit condition. Selecting ATO (auto- restart) will allow the inverter to recover automatically from a At0(auto-restart) Inverter Shutdown...
-
Page 67: Operating In Battery Mode
Operating in Battery Mode Operating in Battery Mode Turning Inverter Operation ON and OFF The Freedom X is in Battery Mode (also called Inverter Mode) Press the Power button to a down position (it is in Standby in the up position). when all the following conditions exist: When the inverter’s Ignition Control feature is set to Auto-on (ATO) -
Page 68: Power Save Timer
Operating in Battery Mode Power Save Timer Checking Battery Status The Power Save Timer is an adjustable countdown timer from 1 to During inverter operation (in battery mode), you can check the 25 h that automatically shuts down inverter operation to reduce battery status by observing the battery capacity indicator on the battery discharge and preserve battery life. -
Page 69: Turning The Audible Alarm On Or Off
Operating in Battery Mode Turning the Audible Alarm ON or OFF The Freedom X’s audible alarm can be muted. See Adjusting Feature Settings in Configuration Mode on page 49. Any warnings such as error or fault conditions or imminent shutdown are both displayed on the LCD screen and sounded on the alarm speakers. -
Page 70: Operating During Transition Between Grid Mode And Battery Mode
Operating During Transition Between Grid Mode and Battery Mode Operating During Transition Transitioning from Grid Mode to Battery Mode Between Grid Mode and Battery When the unit is operating in grid mode and shore power is lost, Mode the Freedom X has less than 20 milliseconds (default) to switch to The Freedom X’s advanced power management is capable of operating in battery mode (if the Power button is pressed in the On transitioning power from an AC source to DC source within a... -
Page 71: Operating Limits
Operating Limits Operating Limits Power Output The Freedom X can deliver up to 1800 W of continuous utility These are the operating limits of the Freedom X: grade sine wave AC power. The wattage rating applies to resistive Power Output loads such as incandescent lights. Input Voltage Input Voltage Overload Conditions... -
Page 72: Overload Conditions
Operating Limits Overload Conditions Operating Battery Comment There are two kinds of overload conditions – an overload warning Condition Voltage and an overload shutdown. The buzzer sounds a single 1 s low battery alarm beep and the LCD screen shows error code Overload When the Freedom X’s AC load is approximately 100 W Low Voltage E01. -
Page 73: Routine Maintenance
5 ROUTINE MAINTENANCE Regular maintenance is required to keep your Freedom X operating properly. This section includes: Maintaining the Freedom X Unit 975-1169-01-01... -
Page 74: Maintaining The Freedom X Unit
Maintaining the Freedom X Unit Maintaining the Freedom X Unit WARNING ELECTRICAL SHOCK HAZARD Turning the Power k button to Standby mode does not disconnect DC battery power from the Freedom X. You must disconnect from all power sources before working on any circuits connected to the unit. -
Page 75: Troubleshooting
6 TROUBLESHOOTING This section will help you narrow down the source of any problem you encounter. Before contacting customer service, please work through the steps listed in Pre-service Checklist on page 62. This section includes: Pre-service Checklist Warning Messages Troubleshooting Reference 975-1169-01-01... -
Page 76: Pre-Service Checklist
Pre-service Checklist Any known unusual AC shore power factors such as Pre-service Checklist low voltage, unstable generator output, etc. Whether any extreme ambient conditions existed at the time (temperature, vibrations, moisture, etc.) WARNING 3. When there are no observable flashing LEDs on the LED panel, check the following to make sure the present ELECTRICAL SHOCK HAZARD state of the installation allows proper operation:... -
Page 77: Warning Messages
Warning Messages Warning Messages Warning messages in the form of audible alarms and error codes that appear on the LCD screen to alert you to an impending system change. Warnings do not affect operation. With the exception of the error codes displayed on the screen, only the audible alarm can be turned ON or OFF. - Page 78 Warning Messages Table 12 Error codes displayed on the LCD screen Error Code Condition Mode Action Low battery voltage Check battery status and recharge if necessary. shutdown is imminent Battery mode depending on the setting, Check for proper DC cable sizing. (inverting) see Maintaining the Check for loose connections and tighten if necessary.
- Page 79 Warning Messages Error Code Condition Mode Action If there is no issue with the fan, disconnect the unit from its DC and AC power sources, then reconnect, and then restart the Fan lock error Grid mode (bypass) unit. Perform Drip Shield Installation on page 40. If error detection persists, contact customer service.
-
Page 80: Troubleshooting Reference
Troubleshooting Reference Troubleshooting Reference WARNING ELECTRICAL SHOCK HAZARD Do not disassemble the Freedom X. It does not contain any user- serviceable parts. Attempting to service the unit yourself could result in an electrical shock or burn. Failure to follow these instructions can result in death, serious injury, or equipment damage. - Page 81 Troubleshooting Reference Table 13 Troubleshooting reference Problem Possible Cause Solution Alarm does not sound when an error is Alarm is turned OFF. See Maintaining the Freedom X Unit on page 60 and encountered. follow instructions to turn the alarm buzzer on again. No output voltage.
- Page 82 Troubleshooting Reference Problem Possible Cause Solution No output voltage is shown in the LCD GFCI (when installed downstream) Check load and reset the GFCI or supplementary screen but the green status LED for has tripped or supplementary breaker. Battery mode is illuminated. breaker has tripped.
- Page 83 Troubleshooting Reference Problem Possible Cause Solution No output voltage. The status LED is Ignition lock (ACC) signal is not If the ignition control feature is in use, ensure the not lighting up. present. vehicle’s ignition is On and the ignition control switch on the front of the Freedom X unit is On (|).
-
Page 84: Inverter Applications
Inverter Applications Inverter Applications Motor Loads Induction motors (that is, motors without brushes) require two to The Freedom X performs differently depending on the AC loads six times their running current on start up. The most demanding connected to it. If you are having problems with any of your loads, are those that start under load, for example, compressors and read this section. -
Page 85: Specifications
7 SPECIFICATIONS This section summarizes the hardware and electrical specifications of the Freedom X 1800 (12VDC) Inverter. This section includes: Physical Specifications Environmental Specifications System Specifications Regulatory Approvals NOTE: Specifications are subject to change without prior notice. 975-1169-01-01... -
Page 86: Physical Specifications
Physical Specifications Physical Specifications Environmental Specifications Table 14 Physical specifications Table 16 Environmental specifications Freedom X 1800 (12VDC) Freedom X 1800 (12VDC) Ambient Temperature: 14.6” × 10.8” × 3.9” Operating Temperature Range -4 –140 ºF (-20 –60 ºC), with (370mm × 275mm × 100mm) L ×... -
Page 87: System Specifications
System Specifications System Specifications Table 18 DC input for inverting Freedom X 1800 (12VDC) Table 17 System specifications Operating voltage range LBCO voltage –18.0 VDC Freedom X 1800 (12VDC) Maximum non-operating voltage 24 VDC Transfer relay rating (A Nominal voltage 12 VDC Transfer time (milliseconds Nominal current at full load 173 ADC Shore to inverter:... -
Page 88: Regulatory Approvals
Regulatory Approvals Regulatory Approvals Table 20 Regulatory approvals Freedom X 1800 (12VDC) ETL-listed complies to CSA 107.1 UL458 and UL458 Marine Supplement (drip shield with Product Safety product number 808-1050 required) ABYC E-11, A-31, A-32 CFR 47, (FCC Part 15) Subpart B, Class B ISED CAN ICES-3(B)/NMB-3(B) Freedom X 1800 (12VDC) Owner's Guide... - Page 89 This page is intentionally left blank. [2]...
- Page 90 http://www.xantrex.com/ (Toll Free USA/Canada) +1 800 670 0707 (Outside USA/Canada) +1 408 987 6030 Printed in: 975-1169-01-01 Rev A...
