6652-4201 Mykonos Fountain
COMPONENTS AND PARTS LIST
NOTE: Component photos are not to scale
Pump Kit Parts List
PK500 pump (1)
Approx. 12" length of 1/2" black non-kink tubing (1)
Approx. 2" length of 5/8" clear vinyl tubing
(connected to non-kink tubing)
#10 rubber stopper (1)
Plumber's putty (1)
Wobble Wedges (4)
Hose clamps (2)
Note – Hose clamp may be used as flow restrictor
(3 pieces)
6652-4201A
25" dia x 23" H
112 Lbs
6652-4201B
15" dia x 10" H
36 Lbs
6655-4201
32" dia x 11" H
106 Lbs
Level
Revised March 29, 2016
Fountain holds approximately
21 Gallon(s) of water
Tools you will need
