Omega ODW902X Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

ODW902X
Dishwasher
Instruction Manual

Advertisement

Table of Contents
loading

Related Manuals for Omega ODW902X

Summary of Contents for Omega ODW902X

  • Page 1 ODW902X Dishwasher Instruction Manual...
  • Page 2 You are welcoming an Omega appliance into your place and you can be sure it'll always serve you well. For important information about your Omega such as warranty registration, online manuals, specifications and catalogues, please visit...

  • Page 3: Table Of Contents

    CONTENTS Technical specifications …………………………………………………….. • Conformity with the standards and Test data …………………………….. • Safety information and Recommendations………………………………….. Recycling ..………………………............• Safety information …………………………………………………………… • Recommendations …...……………………………………………………… • Items not suitable for dishwashing ………………………………………… • Installing the machine ………………………………………………………….. Positioning the machine …………………………………………………….. •...
  • Page 4 Loading your dishwasher .……………………………………………………. Alternative basket loads …………………………………………………... • Programme descriptions .…………………………………………………….. Programme items ………………………………………………………….. • Getting familiar with your machine …………………………………………… 2 6 Switching on the machine and selecting a programme……………..Switching on the machine…………………………………………………. • Programme follow-up ……………………………………………………… •...

  • Page 6: Technical Specifications

    Technical specifications Capacity 15 place settings Height 850 mm Height 820 mm (without worktop) Width 598 mm Depth 598 mm Net Weight 52 kg Electricity input 220-240 V, 50 Hz Total Power 1900 W Heating Power 1800 W Pump Power 100 W Drain Pump Power 30 W...

  • Page 7: Safety Information And Recommendations

    SAFETY INFORMATION AND RECOMMENDATIONS • The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervised or instruction concerning use of the appliance by a responsible person for their safely. •...
  • Page 8 • Check whether the indoor electrical fuse system is connected according to the regulations. • All electrical connections must match the values indicated on the rating plate. • Pay special attention and be sure that the machine does not stand on the electricity supply cable. •...
  • Page 9 • Due to danger of explosion, do not put into the machine’s washing section any chemical dissolving agents such as solvents. • Check whether plastic items are heat-resistant before washing them in the machine. • Do not put into your machine those items which are not suitable for dishwashing.

  • Page 10: Recommendations

    • If EnergySave option is selected as "Yes", The door will be opened at the end of the program. Do not force to close the door to avoid damaging the auto door mechanism. The door must be open during 30 minutes to get effective drying.( in models with auto door opening system ) Warning: Do not stand in front of the door after the signal sounds belonging auto-open.

  • Page 11: Items Not Suitable For Dishwashing

    • Use the pre-wash programme only whenever necessary. • Place such hollow items as bowls, glasses and pots into the machine in such a way that they will face down. • You are recommended not to load into your machine any dishes different or more than indicated.

  • Page 12: Water Connections

    Do not put your machine in any location where there is the probability for the room temperature to fall below 0°C. Before positioning, take the machine out of its packaging by following the warnings located on the package. Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made.

  • Page 13: Water Inlet Hose

    Water inlet hose Do not use the water inlet hose of your old machine,if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long - unused water inlet hose to your machine ,run water through it for a while before making the connection.

  • Page 14: Water Outlet Hose

    Water outlet hose The water drain hose can be connected either directly to the water drain hole or to the sink outlet spigot. Using a special bent pipe (if available), the water can be drained directly into the sink via hooking the bent pipe over the edge of the sink.

  • Page 15: Electrical Connection

    Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur.

  • Page 16: Fitting The Machine Undercounter

    Fitting the machine undercounter If you wish to fit your machine undercounter, check whether you have sufficient space under your countertop and whether the wiring-plumbing is suitable to do so.1 If you decide that the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration.
  • Page 17 Adjust the machine feet according to the slope of the floor.3 Fit your machine by pushing it undercounter without letting the hoses get crushed or bent.4 Product  Without Insulation With Insulation  All Product  For 2nd Basket For 3rd Basket  Height 820 mm 830mm 835 mm Warning: After removal of worktop, the machine should be placed in such a closed place of which dimensions are shown at fig.

  • Page 18: Preparing The Machine For Use

    PREPARING THE MACHINE FOR USE Prior to using the machine for the first time • Check whether the electricity and supply water specifications match the values indicated by the installation instructions for the machine. • Remove all packaging materials inside the machine. •...

  • Page 19: Filling With Rinse Aid And Making The Setting

    They produce good results for certain types of usage only. If you are using this type of • detergents, you need to contact the manufacturers and find out about the suitable conditions of use. When the conditions of use of such products and the machine settings are appropriate, •...

  • Page 20: Loading Your Dishwasher

    Warning: Use only those rinse aid materials which are allowed for use in the machine. As rinse aid residues left as a result of overflowing will create extremely high amounts of foam and thus reduce the washing performance, remove the excess amount of rinse aid by wiping it with a rag. LOADING YOUR DISHWASHER If you properly place your dishes into the machine, you will be using it in the best way in terms of energy consumption, washing and drying performance.
  • Page 21 Spoon rack It allows your long-stemmed goblets to be washed safely as well as it is a part to provide your spoons and forks put easily to spoon rack. Do not lean your long-stemmed goblets and glasses against each other but spoon rack, thus during the washing it is ensured your glasses and goblets stay in place and a safe washing by preventing...
  • Page 22 Top basket height adjustment while it is full Basket height adjustment mechanism on the top basket of your machine is designed to let you adjust the height of your top basket upwards or downwards, without removing it from your machine when it is full, and create large spaces at the top or bottom area of your machine as needed.
  • Page 23 Modular fork spoon According to the number of your dirty forks, spoons and knives, you can separate your basket of modular fork and spoon into two separate parts. Hold your basket from both sides to separate it and you can separate your basket into two separate parts by moving the one side forward while moving the other side back.
  • Page 24 By placing your modular fork spoon basket in different places at upper or lower basket, you can form appropriate fields for your other dishes. Below you can see several recommended settlements.

  • Page 25: Alternative Basket Loads

    Alternative basket loads Lower Basket Top Basket...
  • Page 26 Faulty loads   Important Note for Test Laboratories   For detailed information on performance tests, please contact following address:   "dishwasher@standardtest.info” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door.  ...

  • Page 27: Programme Descriptions

    PROGRAMME DESCRIPTION Programme No Quick 40 ° C 30 min. Intensive Prewash ***Super 50 min. 65 ° C Programme names and ° 0 60 C ° ° 0 C ° C ° temperatures soups, sauces, pasta, Type of food waste Pre-wash to rinse Normally cold meats,...

  • Page 28: Getting Familiar With Your Machine

    GETTING FAMILIAR WITH YOUR MACHINE 1.) ON/OFF Button When one presses the on/off button, the machine is energized and the light on Start/Standby button goes on. 2.) Extra Hygiene Button By using this option, washing temperature and periods during respective cycles may be changed, which ensures more hygienic washing.
  • Page 29 7.) Start/Pause Button Once you press the Start/Pause button, the programme you selected w th the programme selector button w ll start runn ng and the status indicator lamp “wash” will light up. In the stop condition while wash led light is On, Start/Pause led will blink. 8.) Rinse Aid Lack Warning Indicator In order to check that there is sufficient rinse aid in your machine check rinse aid lack warning light on the display.When rinse aid...

  • Page 30: Switching On The Machine And Selecting A Programme

    SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME Switching on the machine The lamp on Program Start/Pause key goes off once the Program starts and the washing lamp is highlighted. Press the Power On/Off key. Select the program suiting your dishes via the Program Selector button.

  • Page 31: Changing A Programme With Resetting

    Changing a programme with resetting If you would like to cancel a program while a washing program is resumed. Hold Start/Pause button pressed for approx. 3 sec. until Finish light blinks. Once Finish light comes on, it means that the cycle has been cancelled.

  • Page 32: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine.

  • Page 33: Spray Arms

    Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left.

  • Page 34: Failure Codes And What To Do In Case Of Failure

    FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE ERROR CODE ERROR DESCRIPTION CONTROL • Make sure the water input tap is totally open and that there is no water cut. Inadequate water supply Close the water input tap, separate the water input hose from the tap and clean the filter at •...
  • Page 35 If one of program monitor lights is on and start/Pause light is on and off, Your machine’s door is open, shut the door. If the programme won’t start • Check if the plug is connected. • Check your indoor fuses. •...

  • Page 36: Practical And Useful Information

    Call an authorised person if the problem still persists after the controls or in case of any malfunction not described above. PRACTICAL AND USEFUL INFORMATION 1. Whenever you will not be operating your machine Unplug the machine and then turn the water off. •...
