Speco CVC-648IRHQ Specifications

Specifications subject to change
*HQ-1 is a trademark of the Sony Corporation
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
High Resolution Color Indoor Dome Cameras
w/Built-In IR LEDs, Fixed or Varifocal Lens
CVC-648IRVFHQ
(4-9 mm auto iris varifocal lens)
The CVC - 6 4 8 I RVFHQ is a high resolution color day/night camera based upon the HQ-1 CCD
& DSP. It fe a t u res special shielding to eliminate IR re fl e c t i o n s . It is used for indoor applications
to cover the full spectrum of bright light to no light surve i l l a n c e . This dome camera can be
wall or ceiling mounted by using the matching bra cket that is included in the box .

Specifications

Resolution . . . . . . . . . . . . . . . . . . .
Image Device . . . . . . . . . . . . . . . . .
Effective Pixels . . . . . . . . . . . . . . . .
Cell Size . . . . . . . . . . . . . . . . . . . .
Minimum Illumination . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . . . . .
Synchronization . . . . . . . . . . . . . . .
Scanning System . . . . . . . . . . . . . . .
S/N Ratio . . . . . . . . . . . . . . . . . . .
Gain Control . . . . . . . . . . . . . . . . .
Back Light Compensation
AGC . . . . . . . . . . . . . . . . . . . . . . .
Gamma Characteristic . . . . . . . . . . .
Video Output . . . . . . . . . . . . . . . . .
LED IR Wave Length . . . . . . . . . . . . .
Number of LED . . . . . . . . . . . . . . . .
Effective IR range . . . . . . . . . . . . . .
Power Supply . . . . . . . . . . . . . . . . .
Consumption Current . . . . . . . . . . . .
Reverse Polarity Protection
Dimensions . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . .
Operating Temperature . . . . . . . . . . .
Case . . . . . . . . . . . . . . . . . . . . . .
For more information contact us at:
Features
540 lines
1/3" Sony HQ-1* color CCD with DSP
762 (H) x 495 (V)
9.6µm (H) x 7.5µm (V)
0 lux (65 ft. range) with IR on, 0.5 lux with IR off
Auto 1/60-1/100,000 sec.
3.6 mm lens (optional lenses available)
Varifocal version: 4-9 mm auto iris
Internal 2:1
EIA standard 525 line 60 fields/second
Greater than 50 db
Automatic
. . . . . . . . . Auto
Auto
0.45 typ.
1.0 Vp-p, 75 ohm
850 NM
22 IR LEDs
65 feet (depending on scene reflection)
12V DC regulated - included, UL approved
Max. 380mA @ 12 Volts DC, LED on
. . . . . . . . Yes
5"Diameter x 3"H
8 oz.
14˚F to 120˚F
High impact ABS
CVC-648IRHQ
(3.6 mm lens)
