INSTALLATION, OPERATION AND MAINTENANCE MANUAL
RADIANT INFRARED ELECTRIC HEATER
–
BIG ASS FANS OBSIDIAN® ELECTRIC HEATER
MODELS
VOLTAGE
TOTAL POWER (W)
CURRENT(AMPS)
BAFC15120B
120
1500
12.5
FIRE/EXPLOSION HAZARD WARNING
NOT FOR USE IN HAZARDOUS OR EXPLOSIVE ATMOSPHERES
During operation, always ensure combustible materials are kept at a safe distance from the heater
body and from the emitted radiant energy. This heater is not intended for use in hazardous areas where
flammable vapours, gases, liquids or other combustibles are present. Failure to do so can result in
personal injury/or property damage.
FOR INDOOR AND OUTDOOR COMMERCIAL AND RESIDENTIAL USE
BIG ASS FANS dba DELTA T LLC
2348 INNOVATION DR. LEXINGTON KY 40511
PHONE: 877.BIG.FANS
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BIG ASS FANS OBSIDIAN BAFC15120B
Summary of Contents for BIG ASS FANS OBSIDIAN BAFC15120B
- Page 1 Failure to do so can result in personal injury/or property damage. FOR INDOOR AND OUTDOOR COMMERCIAL AND RESIDENTIAL USE BIG ASS FANS dba DELTA T LLC 2348 INNOVATION DR. LEXINGTON KY 40511 PHONE: 877.BIG.FANS...
-
Page 2: Table Of Contents
TABLE OF CONTENTS - SAFETY ................................3 - INSTALLATION INSTRUCTIONS ........................5 3 - OPERATING INSTRUCTIONS ..........................7 3.2.1 Operation of the Remote Control ...................... 8 4 - MAINTENANCE ..............................9 5 - GROUNDING INSTRUCTIONS ........................... 12 WARNINGS THIS ELECTRIC APPLIANCE PRODUCES INFRARED HEAT, AND FAILURE TO FOLLOW WARNINGS AND INSTRUCTIONS CAN CAUSE FIRE, ELECTRIC SHOCK, OR INJURY. -
Page 3: Safety
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following outlined in section 1 – SAFETY. Read all instructions before installing or using this heater. 1 - SAFETY WARNINGS WARNING: FIRE OR EXPLOSTION HAZARD... - Page 4 WARNING: PERSONAL INJURY HAZARD - CLEANING AND MAINTENANCE • • To avoid property damage, personal injury Before cleaning the unit or replacing the or death due to electrical shock DO NOT emitter, turn off the main power. Make sure service the unit without turning the unit the heater and/or the emitter is cool before OFF and disconnecting the heater from the handling.
-
Page 5: Installation Instructions
2 - INSTALLATION INSTRUCTIONS Heater installation must be carried out by qualified personnel in compliance with local National Codes (NEC) as well as any other applicable standards. Failure to comply with applicable requirements could result in personal injury and/or property damage. Wiring procedures and connections shall be made in accordance with national and local electrical codes having jurisdiction. - Page 6 ELECTRICAL INSTALLATION Safety Precautions 1. Each power supply circuit must be properly grounded. 2. Use a certified ground fault protection device for wet environment installations. 3. Use a proper electrical connection box 4. Supply voltage and frequency must correspond to the electrical rating indicated on unit’s information plate WALL-MOUNTED INSTALLATION 1.
-
Page 7: Operating Instructions
ADJUSTING DIRECTIONAL POSITIONING Never attempt to move or adjust the heater angle while it is running. Personal WARNING injury could result. 1. Turn off the heaters electrical supply line from the main power supply. 2. Allow the heater to cool before adjusting the angle. 3. -
Page 8: Operation Of The Remote Control
PCB BYPASS MODE When the bypass mode is selected, the heater will operate at 100% of rated power OR may be controlled by other type of external control system. Installer or specifier is responsible for compatibility and safety of controls not included with this heater. -
Page 9: Maintenance
Notice: 1. Use 2 pieces AAA, 1.5V batteries (not included) in the remote control. Remove the batteries when not in use for an extended period of time to increase battery life. 2. The heater can be still used normally in the event the remote control is misplaced, however it must be used in PCB bypass mode where the heater will run fully on. - Page 10 REPLACING THE EMITTER Contact your distributor for the correct replacement emitter, providing the model number and rating from the rating label. Using an incorrect replacement emitter can cause the heater to fail. Notice: Read through the Emitter replacement procedure below before beginning the replacement. For easier replacement, remove the heater from the wall or ceiling.
- Page 11 8. Insert the new emitter through the reflector 9. Connect the new emitter to the terminals of openings. Insert the Reflector Shields and bend the heater; screw in the protective plastic caps the tabs back into place. The Reflector Shields hold the emitter in the correct position during operation.
-
Page 12: Grounding Instructions
5 - GROUNDING INSTRUCTIONS Connection to GFCI protected outlet is recommended For outdoor, exposed environments and/or as required by local, state and National Electrical Code (NEC) requirements. WARNING FAILURE TO USE A GFCI PROTECTED OUTLET COULD RESULT IN FIRE OR ELECTRIC SHOCK! This heater is for use on 120-volt circuits. - Page 13 BIGASSFANS.COM/PRODUCT-WARRANTIES...
