Speco CVC-128RS Features & Benefits

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
High Resolution B/W Weatherproof Camera
with Sunshield
Features
Weatherproof . . . . . . . . . . . . . . . . . . .
Snap-on Sunshield . . . . . . . . . . . . . . . .
Universal Mounting System. . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . . . .
Resolution . . . . . . . . . . . . . . . . . . . . . . . . . .
Minimum Illumination . . . . . . . . . . . . . . . . . .
Image Device . . . . . . . . . . . . . . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lens Options . . . . . . . . . . . . . . . . . . . . . . . .
Video Output Level . . . . . . . . . . . . . . . . . . . .
Video S/N Ratio . . . . . . . . . . . . . . . . . . . . . .
Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . .
Number of Pixels . . . . . . . . . . . . . . . . . . . . . .
Scanning System . . . . . . . . . . . . . . . . . . . . . .
Scanning Frequency . . . . . . . . . . . . . . . . . . . .
Operating Temperature . . . . . . . . . . . . . . . . . .
Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Consumption . . . . . . . . . . . . . . . . . . . .
Power Supply . . . . . . . . . . . . . . . . . . . . . . . .
Camera Mount . . . . . . . . . . . . . . . . . . . . . . .
Housing . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CVC-128RS Camera
12V DC Regulated Power Supply
Mounting Screws
For more information contact us at:
CVC-128RS
Benefits
Use indoors or outdoors
Eliminates glare from the sun or strong
sources of light
Mount on wall, ceiling or parapet
Perfect pictures in all lighting conditions
420 lines
0.02 lux
1/3" B/W CCD image sensor
1/60 - 1/100,000 seconds
3.6mm wide angle lens
2.9, 6, 8mm
1.0 Vp-p, 75 ohm
Greater than 48 dB
Video- BNC, Power- DC jack
512 H x 492 V
EIA standard 525 line 60 fields/second
15.75 kHz horizontal 60 Hz vertical
- 14˚F to 120˚F
Within 95% RH
100 mA
Regulated 12V DC power supply included
(UL and CSA listed)
Bracket included
Black metal, with removable sunshield
2.37"L x 1.07"W x 1"H
2.2 oz

Package Includes:

Installation Instructions
Universal Mounting Bracket
