- Page 1 Operating Instructions Version 4/01.16 Part 2-O: Device Functions METRAHit 30M METRAwin 10 Parameters Configuring and Analysis Software for Electrical Measuring Instruments the measuring software for the PC...
-
Page 2: Preface
® Users must be familiar with basic Windows functions. Scope of Validity These instructions are valid for METRAwin 10 version 6.20 or higher. Note The version number can be displayed by clicking About in the Help menu. GOSSEN METRAWATT Version 4/01.16... -
Page 3: Table Of Contents
METRAwin 10 - Device Functions METRAHit 30M Table of Contents PREFACE ..........................2 TABLE OF CONTENTS ...................... 3 1 FEATURES ........................4 1.1 Scope of Functions ........................... 4 1.2 System Requirements ..........................4 Hardware Requirements ........................4 Software Requirements ......................... 4 2 INITIAL START-UP ...................... -
Page 4: Features
Adapters 1 to 4 RS232 Interface Adapter(s) BD232 or 1 IR-USB Interface Adapter USB-HIT (optional accessory) Software Requirements Installed METRAwin 10 software (version 6.20 or higher) with device drivers for METRAHit 30M multimeters (MULTL_O.DLL). Installed device driver „GMC-I Driver Control“ for IR-USB interface adapter USB-HIT with assigned virtual COM port in the range COM1 ... -
Page 5: Initial Start-Up
BD232, it is mandatory to set the individual multimeters to different addresses: MENU : Addr : 1 / 2 / … / 15 The measuring channels C1 through C10 in METRAwin 10 are assigned in ascending order of the device addresses. -
Page 6: Connecting Via Usb Ir Interface Adapter
A CD ROM is provided with the adapter which includes the driver installer "GMC-I Driver Driver Control" and the corresponding Installation Instructions. Both can also be found on the METRAwin 10 installation CD and on our website for free download: http://www.gossenmetrawatt.com > Products > Software > Software for Measuring Devices >... -
Page 7: Plug The Adapter To The Multimeter
METRAwin 10 - Device Functions METRAHit 30M Initial Start-Up Plug the Adapter to the Snap-on the adapter USB-HIT at the top of the Multimeter multimeter as shown here. Connecting the Adapter Insert the adapter’s USB plug into a free USB port at the PC. -
Page 8: Executing The Communication Test
METRAwin 10 and the multimeter for correct functioning: Switch the multimeter(s) on and select any desired measuring function. Start METRAwin 10 and make sure that METRAHit 30M is selected under Device Type in the Device menu. Open the Communication Setup dialog box by clicking Communication in the Device menu. -
Page 9: Operation
METRAwin 10 - Device Functions METRAHit 30M Operation 3 Operation 3.1 Online Recording of Live Measurement Data Before starting online recording, be sure to read all of the applicable notes included in the description of the Program Functions in section 3.5.2 regarding the Start Online Recording function in the File menu. - Page 10 METRAwin 10 - Device Functions METRAHit 30M Operation Move Memory Data to File Opens the Save as dialog box in order to select a directory path and enter a filename for the memory data file to which the memory contents from the selected devices will be saved after clicking the [Save] button.
-
Page 11: Device Settings Via The Interface
METRAwin 10 - Device Functions METRAHit 30M Operation 3.3 Device Settings via the Interface With METRAwin 10 the current settings of the connected multimeter(s) can be queried and controlled remotely. The remote setting of the measurement functions and ranges is possible regardless of the current position of the function selector switch. -
Page 12: Appendix
METRAwin 10 - Device Functions METRAHit 30M Appendix 4 Appendix 4.1 Schematic Diagram of Program Functions Software Settings Channel selection, Start Program names, colors Exit Program Online measuring and trigger parameters Communications Options: parameters Save Setup Axis scaling... -
Page 13: Examples Of Measurement Data
METRAwin 10 - Device Functions METRAHit 30M Appendix 4.2 Examples of Measurement Data METRAwin 10 contains some sample data files for this multimeter type: DEMO_O.MDF, DEMO_O2.MDF GOSSEN METRAWATT Version 4/01.16...
