Summary of Contents for Blaupunkt 5II84253

  • Page 1 5II84253...
  • Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...

  • Page 3: Table Of Contents

    CONTENTS 1.SAFETY INSTRUCTIONS ....................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings ...................... 6 1.3 During Use........................7 1.4 During Cleaning and Maintenance ................. 8 2.INSTALLATION AND PREPARATION FOR USE .............11 2.1 Instructions for the Installer ...................11 2.2 Installation of the Hob ....................11 2.3 Electrical Connection and Safety..................

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS • Carefully read all instructions before using your appliance and keep them in a convenient place for reference when necessary. • This manual has been prepared for more than one model therefore your appliance may not have some of the features described within.
  • Page 5 WARNING: Danger of fire: Do not store items on the cooking surfaces. WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. • For induction hobs, metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface because they can get hot.

  • Page 6: Installation Warnings

    frequency) and the specifications of the appliance are compatible. The specifications for this appliance are stated on the label. CAUTION: This appliance is designed only for cooking food and is intended for indoor domestic household use only. It should not be used for any other purpose or in any other application, such as for non-domestic use, in a commercial environment or for heating a room.

  • Page 7: During Use

    • When the appliance is unpacked, make sure that it is has not been damaged during transportation. In the case of a defect do not use the appliance and contact a qualified service agent immediately. The materials used for packaging (nylon, staplers, Styrofoam, etc.) may be harmful to children and they should be collected and removed immediately.

  • Page 8: During Cleaning And Maintenance

    1.4 during cleAning And mAintenAnce • Make sure that your appliance is turned off at the mains before carrying out any cleaning or maintenance operations. • Do not remove the control knobs to clean the control panel. • To maintain the efficiency and safety of your appliance, we recommend you always use original spare parts and to call our authorised service agents in case of need.
  • Page 9 Disposal of your old machine The symbol of the crossed-out wheeled bin shown on the product or its packaging means that the device must not be disposed of with other household waste but requires separate collection. You can dispose of the device free of charge at your local waste return and collection system.
  • Page 10 If possible, please remove all batteries and accumulators as well as all removable lamps before disposing of the device. Please note that you are responsible for deleting all personal data on the device to be disposed of. EN - 10...

  • Page 11: Installation And Preparation For Use

    2. INSTALLATION AND PREPARATION FOR USE WARNING: This appliance must be installed by an authorised service person or qualified technician, according to the instructions in this guide Minimum Minimum 42 cm 42 cm and in compliance with the current local regulations.
  • Page 12 Separator Separator • Apply the supplied one-sided self- adhesive sealing tape all the way Worktop mounting around the lower edge of the cooktop. bracket Do not stretch the tape. Self-adhesive sealing tape • Screw the 4 worktop mounting brackets in to the side walls of product. EN - 12...

  • Page 13: Electrical Connection And Safety

    IInsert the appliance into the aperture. 2.3 electricAl connection And SAfety WARNING: The electrical connection of this appliance should be carried out by an authorised service person or qualified electrician, according to the instructions in this guide and in compliance with the current local regulations.

  • Page 14: Product Features

    3. PRODUCT FEATURES Important: Specifications for the product vary and the appearance of your appliance may differ from that shown in the figures below. List of Components 1. Induction zone 2. Control Panel EN - 14...

  • Page 15: Use Of Product

    4. USE OF PRODUCT • If a suitable pan is placed on the cooking zone symbol will disappear and cooking continues at the selected 4.1 hoB controlS power level. Induction Zone • To obtain best energy transferring the The information given in the following table diameter of the cookware base should is for guidance only.
  • Page 16 Touch Control Unit Switching the Cooking Zones On Press the heater selection button that corresponds to the heater you wish to use. A static dot will be shown on the selected heater display and the blinking dots on all other heater displays will no longer illuminate.
  • Page 17 Safety Switch-Off Function Timer Function A cooking zone will automatically switch off The timer function is available in two if the heat setting has not been modified versions, as follow. for a specified duration of time. A change Minute Minder Timer (1 - 99 min.) in the heat setting of the cooking zone will The minute minder timer can be operated reset the time duration to the initial value.
  • Page 18 Buzzer Error Codes While the hob is in operation, the following If there is an error, an error code will be shown on the activities will be signalled by the buzzer. heater displays. • Normal button activation will be Cooling Fan is disabled. Call an authorised accompanied with a short sound signal.

  • Page 19: Cleaning And Maintenance

    5. CLEANING AND • Dust on the surface must be cleaned with a wet cloth. MAINTENANCE • Any changes in colour to the ceramic 5.1 cleAning glass will not affect the structure or durability of the ceramic and is not due WARNING: Switch off the appliance to a change in the material.

  • Page 20: Troubleshooting&Transport

    6. TROUBLESHOOTING&TRANSPORT 6.1 trouBleShooting If you still have a problem with your appliance after checking these basic troubleshooting steps, please contact an authorised service person or qualified technician. Problem Possible Cause Solution Check the household fuse for the Hob control card’s display is appliance.
  • Page 21 Service ( 00 800 32 289 000 www.blaupunkt-einbaugeraete.com Luxemburg/Luxembourg Deutschland/Germany service.DE@blaupunkt-einbaugeraete.com service.LU@blaupunkt-einbaugeraete.com Österreich/ Austria Schweiz/Switzerland service.AT@blaupunkt-einbaugeraete.com service.CH@blaupunkt-einbaugeraete.com Niederlande/Netherlands ltalien/ltaly service.NL@blaupunkt-einbaugeraete.com service.lT@blaupunkt-einbaugeraete.com Belgien/Belgium Spanien/Spain service.BE@blaupunkt-einbaugeraete.com service.ES@blaupunkt-einbaugeraete.com Schweden/Sweden Gro13britannien/Great Britain service.SE@blaupunkt-einbaugeraete.com service.GB@blaupunkt-einbaugeraete.com Frankreich/France Malta/Malta service.FR@blaupunkt-einbaugeraete.com service.MT@blaupunkt-einbaugeraete.com 1800 252 878 658 1800 209 2096...
