Page 1: Dvd Player
OWNER'S MANUAL 8.8" TFT-LCD SCREEN WITH DVD PLAYER OVERHEAD COMBO CAUTION A grade screens constitute no more than 3 missing pixels. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. -
Page 2: Table Of Contents
Contents Caution Password Setup Password Mode Name And Function Of Each Parts Password Change Unit DVD Functions Remote Controller EJECT How To Operate The Monitor VOL+ / VOL- Power On/Off MUTE Monitor Angle Adjustment PLAY OR PAUSE Mute Function AUDIO Switch The Menu STOP ARROWS... -
Page 3: Caution
Caution CAUTION Quality installations are best performed by qualified and certifled installers. Don't touch the unit there is a flash of lightening. It may receive an electric shock. Do not cover or stop up heater ducts or vents. It may be the origin of a fire or receives an electric shock. -
Page 4: Remote Controller
Name And Function Of Each Parts PLAY/PAUSE button STOP button POWER button SEL Down / Up buttons External Connection Name And Function Of Each Parts Remote Controller EJECT button OPEN/CLOSE the disc tray. TITLE button Use to display the title menu of the loaded DVD disc. -
Page 5: How To Operate The Monitor
How To Operate The Monitor Power On/Off 1. Press the POWER button on either the remote controller or the unit once to turn the power on. Press the same POWER button to turn the power off. UNIT Monitor Angle Adjustment The monitor opens when the handle is pulled down. -
Page 6: Selecting The Mode
Selecting The Mode How To Select DVD Mode Press the MODE button on the remote control to achieve the desired mode. 1. Bring up the on-screen SETUP menu by pressing PICTURE button on the remote controller or MENU button on the unit. 2. -
Page 7: Extra Function
Extra Function FM TX Listening to the audio portion of the disk through your automotive speakers. 1. Bring up the on-screen SETUP menu by pressing PICTURE button on the remote controller or MENU button on the unit. 2. Select the FM TX menu by pressing PICTURE... -
Page 8: Screen
Picture Control Screen Select the desired screen modes as your taste. 1. Bring up the on-screen SETUP menu by pressing the PICTURE button on the remote controller or the MENU button on the unit. 2.Select the Screen menu by pressing PICTURE button on the remote controller SEL∨/∧... -
Page 9: Dvd Setup
DVD Setup ■ Setup Menu-Main Page An invalid button press. When this symbol appears, it indicates that an invalid button has been pressed. There are some differences between real functions and functions in manual. You can easily modify setup information on the setup menu. SETUP(A.MEMO) When the button is pressed, the monitor screen shows... -
Page 10: Captions
DVD Setup 4. Captions Adjust caption selection. On : Choose this setting to display captions. Off : Choose this setting to close captions. 5. Screen Saver The screen saver is useful to prevent your display from becoming damaged. The screen saver picture appears when you leave the DVD player in stop mode for about two minutes. -
Page 11: Video Setup
DVD Setup ■ Video Setup 1. Quality V i d e o S e t u p P a g e . . V i d e o S e t u p P a g e . . V i d e o S e t u p P a g e Quality Quality Quality... -
Page 12: Preference
DVD Setup ■ Preference This Menu is not available when play the disc. 1. TV Type Choose a proper operating setting according to the color system of the TV Type - Multi system, NTSC, PAL. 1) Press the SETUP button during stop mode. 2) Press the ◀/▶... -
Page 13: Password Setup
DVD Setup ■ Password Setup 1. Password Mode P a s s w o r d S e t u p P a g e . . P a s s w o r d S e t u p P a g e . . P a s s w o r d S e t u p P a g e Password Mode Password Mode... -
Page 14: Stop
DVD Functions STOP STOP [DVD] Press the STOP button and stop the movie. 1 Time Press Play Key To Continue And then Press the Play/Pause button and will display the last scene of the movie. 2 Time Press the Stop button two times and stop the movie. -
Page 15: Subtitle
DVD Functions SUB-T SUBTITLE [DVD] This button is used to select the language for on-screen display messages. (The title menu is different, depending on the particular DVD.) [AUDIO] / [MP3] An invalid button press. TITLE TITLE [DVD] Used to display the title menu of the loaded DVD disc. (This function is disc-dependent.) [AUDIO] / [MP3] An invalid button press. -
Page 16: Prev
DVD Functions PREV PREV [DVD] / [VCD] Used to move to the previous chapter from the current chapter. [AUDIO] / [MP3] Used to move to the previous track. NEXT NEXT [DVD] / [VCD] Used to move to the next chapter from the current chapter. [AUDIO] / [MP3] Used to move to the next track from the current track. -
Page 17: Pbc
DVD Functions [DVD] / [AUDIO] / [MP3] An invalid button press. [VCD] You can turn the PBC (Play Back Control) function on or off by pressing this button. When PBC is loaded, the PBC function is enabled automatically. This function is similar as selection of DVD title. -
Page 18: Connection Diagram
Connection Diagram CAMCORDER GAME Yellow White MONITOR VIDEO AUDIO (L) AUDIO (R) AV INPUT Yellow AV OUTPUT COMBO LOADER GROUND FILTER & FUSE BOX DC +12V POWER CABLE NOISE FILTER (OPTION) LAMP PCB Disc Information DVD features DVD discs provide high-resolution images with high-quality sound and surround sound effects. -
Page 19: Check Point
Troubleshooting Symptom Items to Check Button does not work. Is the power turned on? Check the car battery capacity. No sound Is the audio which is connected with Select the correct input mode for the audio receiver. the audio cable set to receive the DVD signal output? Is audio cable is connected securely? Connect the audio cable into the jacks securely.
