Related Manuals for Philips EVNIA 27M1C3200VL
Summary of Contents for Philips EVNIA 27M1C3200VL
- Page 1 27M1C3200VL User manual Customer care and warranty Troubleshooting and FAQs Register your product and get support at www.philips.com/welcome...
-
Page 2: Table Of Contents
5. Technical Specifications ...13 5.1 Resolution & Preset Modes ..15 6. Power Management ....16 7. Customer care and warranty ..17 7.1 Philips’ Flat Panel Monitors Pixel Defect Policy ........ 17 7.2 Customer Care & Warranty ..20 8. Troubleshooting & FAQs ..21 8.1 Troubleshooting ......21... -
Page 3: Important
Keep the display away from oil. Oil may damage the plastic cover of the display and void the warranty. This electronic user’s guide is intended for anyone who uses the Philips monitor. • Remove any object that could fall Take time to read this user manual into ventilation holes or prevent before you use your monitor. - Page 4 monitor damage will not be covered • Oil-based cleaning solutions may under warranty. damage the plastic parts and void the warranty. • Do not knock or drop the monitor during operation or transportation. • Unplug the monitor if you are not going to use it for an extensive •...
-
Page 5: Notational Descriptions
Important information for Burn-in/Ghost Note image Consult a service technician if the monitor does not operate normally, or • Always activate a moving screen you are not sure what procedure to take saver program when you leave when the operating instructions given in your monitor unattended. -
Page 6: Disposal Of Product And Packing Material
From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end-of-life management primarily This marking on the product or on entails participation in national take- its packaging illustrates that, under... -
Page 7: Setting Up The Monitor
2.1 Installation Package contents Quick start 27M1C3200VL Register your product and get support at www.philips.com/welcome 2. Hold the stand with both hands. *Earphone-Hang (1) Gently attach the base to the stand. (2) Use your fingers to tighten the screw located at the bottom of the base. -
Page 8: Operating The Monitor
2.2 Operating the monitor Connecting to your PC Description of the control buttons Earphone-Hang Press to switch power on. Press more than 3 seconds to switch power off. Access the OSD menu. Confirm the OSD adjustment. Adjust the Game Setting. Kensington anti-theft lock Adjust the OSD menu. - Page 9 What is On-Screen Display (OSD)? MPRT MPRT Level On-Screen Display (OSD) is a feature Crosshair Low Input Lag in all Philips LCD monitors. It allows an SmartResponse SmartFrame end user to adjust screen performance Size (1,2,3,4,5,6,7) Brightness (0~100) or select functions of the monitors Contrast(0~100) H.
-
Page 10: Remove The Base Assembly For Vesa Mounting
2.3 Remove the Base Assembly Resolution notification for VESA Mounting This monitor is designed for optimal performance at its native resolution, Before you start disassembling the 1920 x 1080. When the monitor is monitor base, please follow the powered on at a different resolution, an instructions below to avoid any possible alert is displayed on screen: Use 1920 x damage or injury. - Page 11 Note This monitor accepts a 100mm x 100mm VESA-Compliant mounting interface. VESA Mounting Screw M4. Always contact manufacturer for wall-mount installation. 100mm 100mm 0° 90° -5° * Display design may differ from those illustrated. Warning • To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward by more than -5 degrees.
-
Page 12: Image Optimization
RTS, Gamer 1, Gamer 2, LowBlue Mode, in real time. Whether you're working EasyRead and Off. with text applications, displaying images or watching a video, Philips SmartImage delivers great optimized monitor performance. ... -
Page 13: Smartcontrast
LED displays can cause eye backlighting for clearer, crisper and damage and affect vision over time. brighter images or dimming backlighting Developed for wellbeing, Philips for clear display of images on dark LowBlue Mode setting uses a smart backgrounds. -
Page 14: Adaptive Sync
4. Adaptive Sync AMD Radeon R7 260X • AMD Radeon R7 260 • ■ Processor A-Series Desktop and Mobility APUs Adaptive Sync AMD A10-7890K • AMD A10-7870K • PC gaming has long been an imperfect AMD A10-7850K • experience because GPUs and monitors update at different rates. -
Page 15: Technical Specifications
5. Technical Specifications Picture/Display Monitor Panel Type Backlight W-LED Panel Size 27" W (68.5 cm) Aspect Ratio 16:9 Pixel Pitch 0.3114 (H) mm x 0.3114 (V) mm Contrast Ratio (typ.) 3000:1 Viewing Angle 178° (H) / 178° (V) @ C/R > 10 (typ.) Monitor Colors 16.7M (8 bits) Picture Enhancement... - Page 16 500 to 1060hPa (Non-operation) Environmental and energy ROHS Packaging 100% recyclable Specific Substances 100% PVC BFR free housing Cabinet Color Black Finish Texture Note This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet.
-
Page 17: Resolution & Preset Modes
For best output performance, please always ensure that your graphic card Recommended Resolution is capable of achieving the maximum 1920 x 1080 @ 60 Hz resolution and refresh rate of this Philips display. H. freq Resolution V. freq (Hz) (kHz) 31.47... -
Page 18: Power Management
6. Power Management If you have VESA DPM compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the monitor will 'wake up' automatically. -
Page 19: Customer Care And Warranty
Pixel Defect Policy pixels of other colors. Philips strives to deliver the highest Types of Pixel Defects quality products. We use some of the Pixel and sub pixel defects appear on the industry's most advanced manufacturing screen in different ways. - Page 20 Black Dot Defects the warranty period, a TFT Monitor Black dot defects appear as pixels or sub panel in a Philips flat panel monitor pixels that are always dark or 'off'. That must have pixel or sub pixel defects is, a dark dot is a sub-pixel that stands...
- Page 21 BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15mm Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 3 or fewer 2 adjacent dark subpixels 2 or fewer...
-
Page 22: Customer Care & Warranty
Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below. -
Page 23: Troubleshooting & Faqs
• Disconnect the monitor from mains power source immediately for safety 8.1 Troubleshooting • Contact with Philips customer service This page deals with problems that can representative immediately. be corrected by a user. If the problem Imaging Problems still persists after you have tried these... -
Page 24: General Faqs
For further assistance, refer to the Service step 2 and 3 to verify that your PC is contact information listed in Important set at 1920 x 1080. information manual and contact Philips • Shut down your computer, customer service representative. - Page 25 Can I connect my LCD monitor to soft cloth. For extensive cleaning, any PC, workstation or Mac? please use isopropyl alcohol. Do Ans.: Yes. All Philips LCD monitors are not use other solvents such as fully compatible with standard ethyl alcohol, ethanol, acetone, PCs, Macs and workstations.
- Page 26 Q10: Are Philips LCD monitors Plug- Q13: How to unlock/lock my hot key? and- Play? Ans.: Please press for 10 seconds Ans.: Yes, the monitors are Plug-and- to unlock/lock the hot key, by Play compatible with Windows doing so, your display pops out 11/10/8.1/8/7, Mac OSX.
- Page 27 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
