- Page 1 27M1F5500P User manual Customer care and warranty Troubleshooting and FAQs Register your product and get support at www.philips.com/welcome...
-
Page 2: Table Of Contents
6. Technical Specifications ....18 6.1 Resolution & Preset Modes ..21 7. Power Management ....22 8. Customer care and warranty ...23 8.1 Philips’ Flat Panel Monitors Pixel Defect Policy ......... 23 8.2 Customer Care & Warranty ..26 9. Troubleshooting & FAQs ..27 9.1 Troubleshooting ...... -
Page 3: Important
This electronic user’s guide is intended for anyone who uses the Philips monitor. • Remove any object that could fall Take time to read this user manual into ventilation holes or prevent before you use your monitor. - Page 4 • To avoid potential damage, for When moving your monitor, grasp example the panel peeling from the the frame to lift; do not lift the bezel, ensure that the monitor does monitor by placing your hand or not tilt downward by more than -5 fingers on the LCD panel.
-
Page 5: Notational Descriptions
Ghost image Note Consult a service technician if the • Always activate a moving screen monitor does not operate normally, or saver program when you leave you are not sure what procedure to take your monitor unattended. Always when the operating instructions given in activate a periodic screen refresh this manual have been followed. -
Page 6: Disposal Of Product And Packing Material
From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end-of-life management primarily This marking on the product or on entails participation in national take-... -
Page 7: Setting Up The Monitor
Package contents Quick start 27M1F5500P 2. Hold the stand with both hands. Register your product and get support at www.philips.com/welcome (1) Gently attach the base to the stand. (2) Use your fingers to tighten the screw located at the bottom of the base. - Page 8 Connecting to your PC Connect to PC 1. Connect the power cord to the back of the monitor firmly. 2. Turn off your computer and unplug 1 2 3 4 5 6 7 8 9 10 11 its power cable. 3. Connect the monitor signal cable to the video connector on the back of your computer.
-
Page 9: Operating The Monitor
2.2 Operating the monitor USB charging This display has USB ports capable of Description of the control buttons standard power output including some with USB Charging function (identifiable with power icon ). You can use these ports to charge your Smart phone or power your external HDD, for example. - Page 10 On, O On-Screen Display (OSD) is a feature in SmartResponse O , Fast , Faster, Fastest all Philips LCD monitors. It allows an end On, O SmartFrame Size (1, 2, 3, 4, 5, 6, 7) user to adjust screen performance or...
- Page 11 Swivel Note • This Philips monitor is certified with AMD FreeSync™ Premium Pro. The technology is used to match the refresh rate of the monitor to the +45° graphic cards. Providing the smooth- -45° est gaming experience by reducing or eliminating judder, tearing, and stuttering.
-
Page 12: Remove The Base Assembly For Vesa Mounting
2.3 Remove the Base Assembly for VESA Mounting Before you start disassembling the monitor base, please follow the instructions below to avoid any possible damage or injury. 0° 90° 1. Place the monitor face down on a -5° smooth surface. Pay attention not to * Display design may differ from those scratch or damage the screen. -
Page 13: Multiview
Why do I need it? 3. Toggle to the up or down to select With the ultra high resolution Philips [PBP Mode], then toggle to the right. MultiView display, you can experience a 4. Toggle to the up or down to select... - Page 14 MultiView in OSD menu [PBP]: Picture by Picture Open up a sub-window side-by-side of another (main) signal source. When the sub source is not detected: (main) Note The black strip shows on the top and the bottom of the screen for the correct aspect ratio when in the PBP mode.
-
Page 15: Image Optimization
Off. in real time. Whether you're working with text applications, displaying images or watching a video, Philips SmartImage delivers great optimized monitor performance. Why do I need it? You want a monitor that delivers ... - Page 16 LCD displays. • HDR Photo: Enhancing red, green, Typical uniformity is measured and blue for true-to-life visuals. around 75-80%. By enabling Philips SmartUniformity feature, display • DisplayHDR 600: Meet VESA uniformity is increased to above DisplayHDR 600 standard.
-
Page 17: Smartcontrast
3.2 SmartContrast What is it? Unique technology that dynamically analyzes displayed content and automatically optimizes a Monitor's contrast ratio for maximum visual clarity and viewing enjoyment, stepping up backlighting for clearer, crisper and brighter images or dimming backlighting for clear display of images on dark backgrounds. -
Page 18: Amd Freesync™ Premium Pro
AMD Radeon R9 290X 4. AMD FreeSync™ Pre- • AMD Radeon R9 290 • mium Pro AMD Radeon R9 285 • AMD Radeon R7 260X • AMD Radeon R7 260 • ■ Processor A-Series Desktop and Mobility APUs PC gaming has long been an imperfect AMD A10-7890K •... -
Page 19: Hdr
5. HDR HDR Settings in Windows10 system. Steps 1. Right click on the desktop, enter to Display settings. 2. Select the display/monitor. 3. Select an HDR-capable display under Rearrange your displays. 4. Select Windows HD Color settings. STEP 5 5. Adjust Brightness for SDR content. Note Windows10 edition is required;... -
Page 20: Technical Specifications
6. Technical Specifications Picture/Display Monitor Panel Type Nano IPS Technology Backlight W-LED Panel Size 27" W (68.5 cm) Aspect Ratio 16:9 Pixel Pitch 0.2331 (H) mm x 0.2331 (V) mm Contrast Ratio(typ.) 1000:1 2560 x 1440 @ 144 Hz (HDMI) Optimum Resolution 2560 x 1440 @ 240 Hz (DP) Viewing Angle... - Page 21 Other Convenience VESA mount (100 x 100 mm), Kensington Lock Plug & Play DDC/CI, sRGB, Windows 10/8.1/8/7, Mac OS X Compatibility Stand Tilt -5 / +20 degree Swivel -45 / +45 degree Height adjustment 130 mm Pivot -90 / +90 degree Power AC Input Voltage AC Input Voltage...
- Page 22 100% recyclable Specific Substances 100% PVC BFR free housing Cabinet Color Black Finish Texture Note 1. This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet. 2. SmartUniformity and Delta E information sheets are included in the box.
-
Page 23: Resolution & Preset Modes
640x480 For best output performance, please 51.08 640x480 99.769 always ensure that your graphic card is capable of achieving the maximum 61.91 640x480 119.518 resolution and refresh rate of this Philips 31.469 720x400 70.087 display. 29.855 720x480 59.710 31.25 720x576 35.156... -
Page 24: Power Management
7. Power Management If you have VESA DPM compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the monitor will 'wake up' automatically. -
Page 25: Customer Care And Warranty
Other combinations of Pixel Defect Policy lit and dark sub pixels appear as single pixels of other colors. Philips strives to deliver the highest quality products. We use some of the Types of Pixel Defects industry's most advanced manufacturing... - Page 26 Proximity of Pixel Defects Because pixel and sub pixels defects of the same type that are near to one another may be more noticeable, Philips also specifies tolerances for the proximity of pixel defects. Three adjacent lit sub pixels (one white pixel). Note A red or blue bright dot must be...
- Page 27 BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15mm Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 4 or fewer 2 adjacent dark subpixels 2 or fewer...
-
Page 28: Customer Care & Warranty
If the Certified Service Partner cannot perform the required repairs under the offered extended warranty package, we will find alternative solutions for you, if possible, up to the extended warranty period you have purchased. Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below. • Local Standard •... -
Page 29: Troubleshooting & Faqs
• Contact with Philips customer service • First, ensure that the power button representative immediately. on the rear of the monitor is in the... - Page 30 • Uninterrupted display of still or Service contact information listed static images over an extended in Regulation & Service Information period may cause "burn-in", also Manual and contact Philips customer known as "after-imaging" or "ghost service representative. imaging", on your screen. "Burn-in", * Functionality different according to "after-imaging", or "ghost imaging"...
-
Page 31: General Faqs
Shut down your computer, disconnect that there is no pressure or force your old monitor and reconnect your applied to the panel surface side. Philips LCD monitor. This may affect your warranty • Turn on your monitor and then turn conditions. - Page 32 PC, workstation or Mac? repaired. The damage mentioned above Ans.: Yes. All Philips LCD monitors are is not covered under your warranty. fully compatible with standard Q12: Why is my Display not showing PCs, Macs and workstations.
-
Page 33: Multiview Faqs
Ans.: Regulation & Service Information become the “default” mode. Manual can be download on the Philips website support page. Why the sub-windows flickers when I enable PBP. Ans: It’s because the sub-windows video... - Page 34 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
