- Page 1 CoreStation INSTALLATION GUIDE Version 1.09 English EN 101.00.CS-40 V1.09A...
-
Page 2: Table Of Contents
CONTENTS Safety information Product Specifications Instructional icons Dimensions Introduction FCC compliance information Components Accessory Appendices Name and function of each part Disclaimers Copyright Notice Installation Open Source License GNU General Public License Power Connection TERMS AND CONDITIONS GNU Lesser General Public License Network connection OpenSSL License TCP/IP... -
Page 3: Safety Information
Safety information Please read this safety instructions before you use the product to prevent injury to yourself and others and to prevent property damage. The term 'product' in this manual refers to the product and any items provided with the product. Instructional icons Warning: This symbol indicates situations that could result in death or severe injury. - Page 4 The product may malfunction. Use the IEC/EN 62368-1 approved power adapter that supports higher power consumption than the product. It is highly recommended to use the power adapter sold by Suprema. • If the right power supply is not used, the product may malfunction.
-
Page 5: Introduction
Introduction Components CoreStation Intelligent Biometric Controller QUICK GUIDE 201.00.CS40 V*.*** Quick Guide Open Source Software Linux Kernel GPL glibc LGPL QT LGPL OpenSSL Original SSLeay 306.00 V*.*** CoreStation Open Source Software Guide Fixing Screw x12 Spacer x6 Diode x4 Components may vary according to the installation environment. -
Page 6: Accessory
Introduction Accessory You can purchase an enclosure with CoreStation as an accessory. The enclosure includes a power status LED board, power distribution board, power supply, and tamper. To learn how to install the CoreStation in the enclosure, refer to Using the CoreStation with the enclosure. -
Page 7: Name And Function Of Each Part
Introduction Name and function of each part... - Page 8 Introduction Name Name HOST RS-485 connection RESET button HOST RS-485 terminating resistance switch AUX IN (0, 1) connection INIT button CS-40 power connection (DC 12V IN) Ethernet connection Relay 3 connection Relay 1 connection TTL input (6, 7) or supervised input (6, 7) connection TTL input (2, 3) or supervised input (2, 3) TTL output (6, 7) connection connection...
- Page 9 Introduction Communication status LED Status HOST RS-485 TX Orange flashing: Transmitting RS-485 data HOST RS-485 RX Green flashing: Receiving RS-485 data RELAY (0 ~ 3) Red lighting: Relay operation TTL input • Green lighting: Normal Close • Off: Normal Open SUPERVISED INPUT (0 ~ 7) Supervised Input •...
- Page 10 Introduction CS-40 status LED The status of CS-40 can be confirmed through STATUS LED 1 / 2 located on the left side from the front unit of the product. These status LEDs show the status of Ethernet, RS-485 0, RS-485 1, RS-485 2, RS-485 3, RS-485 HOST, and system in order for 1 second each.
- Page 11 Introduction Installation example CS-40 is a centralized access control system that can perform biometric authentication. CS-40, designed as an enterprise system, can save the information of up to 500,000 users and execute matching of 400,000 fingerprints per second. Both access control and attendance management can be used through the linkage with BioStar 2, and various interfaces are provided, including RS-485 (OSDP), Wiegand, Supervised input, and AUX.
- Page 12 Introduction Overall Connection Diagram The enclosure contains an LED control board, power distribution board, power supply, battery, and tamper.
- Page 13 Introduction • Do not connect to A receptacle controlled by A switch.
-
Page 14: Installation
Installation Fix a spacer on the position to mount CoreStation using a fixing screw. Fix the product on top of the fixed spacer firmly using a fixing screw. -
Page 15: Power Connection
Installation Power Connection DC Power • Make sure to use separate power for the access control device and CS-40. • Use the IEC/EN 62368-1 approved power adapter that supports higher power consumption than the product. If you wish to connect and use another device to the power supply adapter, you should use an adapter with a current capacity which is the same or larger than the total power consumption required for the terminal and another device. -
Page 16: Network Connection
Installation Network connection TCP/IP LAN connection (connecting to a hub) You can connect the product to a hub using a general type CAT-5e cable. LAN connection (connecting to a PC directly) CS-40 has automatic MDI/MDI-X function, so it can be connected to a PC directly using a normal type CAT-5e cable. -
Page 17: Rs-485 Connection
Installation RS-485 Connection CS-40 supports 5 RS-485 ports, and up to 31 devices can be connected to each RS-485 port. • The number of RS-485 devices connected to CS-40 cannot exceed 64. • Use an AWG24 twisted pair with a maximum length of 1.2 km for the RS-485 cable. •... -
Page 18: Relay
Installation Relay Fail Safe Lock In order to use the Fail Safe Lock, connect the NC relay as shown in the figure below. There is normally a current flowing through the relay for the Fail Safe Lock. When the relay is activated, blocking the current flow, the door will open. If the power supply to the product is cut off due to a power failure or an external factor, the door will open. -
Page 19: Wiegand In
Installation Wiegand IN Wiegand Device Door sensor and Exit button SUPERVISED INPUT terminals No. 0 ~ No. 7 can be set to be used for normal TTL input or supervised input. Door sensor Exit button Door... -
Page 20: Aux In
Installation AUX IN A power failure detector or a tamper can be connected to the AUX IN terminal. Tamper... -
Page 21: Using The Corestation With The Enclosure
Installation Using the CoreStation with the enclosure CoreStation can be installed inside the enclosure (ENCR-10) for physical and electrical protection. The enclosure includes a power status LED board, power distribution board, power supply, and tamper. The enclosure is sold separately. Securing the battery Insert the battery velcro strap into the enclosure and secure the battery. - Page 22 Installation Installing the CoreStation in the enclosure Check the position to install the CoreStation in the enclosure. After positioning the CoreStation in the enclosure, fix it with the fixing screws.
- Page 23 Installation Power / AUX IN You can connect an Uninterruptible Power Supply (UPS) to prevent power failure. And a power failure detector or a dry contact output can be connected to the AUX IN terminal. • Make sure to use separate power for the access control device and CS-40. •...
-
Page 24: Factory Default
For more information on CS-40 Setup Manager, refer to the user guide. To download the user guide, visit the Suprema website (https://www.supremainc.com). • You can verify the current version of BioStar2 software When CS-40 is reprogrammable when connected to a network. • For more information, contact the Suprema technical support team (https://support.supremainc.com). -
Page 25: Product Specifications
Product Specifications Category Feature Specification Model CS-40 1.4 GHz Octa-core Memory 8 GB Flash + 1 GB RAM Crypto chip Supported Multi-color • STATUS - 2ea • HOST RS-485 TX - 1ea • HOST RS-485 RX - 1ea • SUPERVISED INPUT - 8ea •... - Page 26 Product Specifications Category Feature Specification CoreStation • Voltage: 12 Vdc • Current: Max. 3 A Power Power Supply (SMPS) AC INPUT • 110 ~ 240 VAC, 50/60 Hz • Voltage: 12 Vdc Electrical Power Output • Current: Max. 1.5 A •...
-
Page 27: Dimensions
Product Specifications Dimensions (Unit: mm) * The tolerance is ±0.3 mm. -
Page 28: Fcc Compliance Information
• Modifications: Any modifications made to this device that are not approved by Suprema Inc. may void the authority granted to the user by the FCC to operate this equipment. -
Page 29: Appendices
Information in this document is provided in connection with Suprema products. • The right to use is acknowledged only for Suprema products included in the terms and conditions of use or sale for such products guaranteed by Suprema. No license, express or implied, by estoppel or otherwise, to any intellectual property is granted by this document. -
Page 30: Open Source License
Appendices Open Source License • The software of this product is based on "Linux Kernel 3.x", which is licensed under GPL. As for GPL, please refer to GNU General Public License in this manual. • This product uses the "glibc" library, which is licensed under LGPL. As for LGPL, please refer to the GNU Lesser General Public License in this manual. -
Page 31: Terms And Conditions
Appendices TERMS AND CONDITIONS 0. Definitions. “This License” refers to version 3 of the GNU General Public License. “Copyright” also means copyright-like laws that apply to other kinds of works, such as semiconductor masks. “The Program” refers to any copyrightable work licensed under this License. Each licensee is addressed as “you”. “Licensees”... - Page 32 Appendices 2. Basic Permissions. All rights granted under this License are granted for the term of copyright on the Program, and are irrevocable provided the stated conditions are met. This License explicitly affirms your unlimited permission to run the unmodified Program. The output from running a covered work is covered by this License only if the output, given its content, constitutes a covered work.
- Page 33 Appendices 6. Conveying Non-Source Forms. You may convey a covered work in object code form under the terms of sections 4 and 5, provided that you also convey the machine-readable Corresponding Source under the terms of this License, in one of these ways: a) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied by the Corresponding Source fixed on a durable physical medium customarily used for software interchange.
- Page 34 Appendices 7. Additional Terms. “Additional permissions” are terms that supplement the terms of this License by making exceptions from one or more of its conditions. Additional permissions that are applicable to the entire Program shall be treated as though they were included in this License, to the extent that they are valid under applicable law.
- Page 35 Appendices 10. Automatic Licensing of Downstream Recipients. Each time you convey a covered work, the recipient automatically receives a license from the original licensors, to run, modify and propagate that work, subject to this License. You are not responsible for enforcing compliance by third parties with this License.
- Page 36 Appendices 12. No Surrender of Others' Freedom. If conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot convey a covered work so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not convey it at all.
-
Page 37: Gnu Lesser General Public License
Appendices GNU Lesser General Public License Version 3, 29 June 2007 Copyright © 2007 Free Software Foundation, Inc. <http://fsf.org/> Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. This version of the GNU Lesser General Public License incorporates the terms and conditions of version 3 of the GNU General Public License, supplemented by the additional permissions listed below. - Page 38 Appendices 4. Combined Works. You may convey a Combined Work under terms of your choice that, taken together, effectively do not restrict modification of the portions of the Library contained in the Combined Work and reverse engineering for debugging such modifications, if you also do each of the following: a) Give prominent notice with each copy of the Combined Work that the Library is used in it and that the Library and its use are covered by this License.
-
Page 39: Openssl License
Appendices OpenSSL License Copyright (c) 1998-2017 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: 1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. -
Page 40: Original Ssleay License
Appendices Original SSLeay License Copyright (C) 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved. This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL. This library is free for commercial and non-commercial use as long as the following conditions are adhered to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code;... - Page 41 QR code. http://www.supremainc.com/en/about/contact-us.asp © 2023 Suprema Inc. Suprema and identifying product names and numbers herein are registered trade marks of Suprema, Inc. All non-Suprema brands and product names are trademarks or registered trademarks of their respective companies.
