CONGRATULATIONS!
You now own the REFERENCE
uncompromising design and
Soundstream REFERENCE amplifier will outperform any other
amplifier in the world.
To maximize the performance of your system, we recommend that you
thoroughly acquaint yourself with its capabilities and features. Please
retain this manual and your sales and installation receipts for future
reference.
Soundstream amplifiers are the result of American craftsmanship and
the highest quality control standards, and when properly installed, will
provide you with many years of listening pleasure. Should your
amplifier ever need service or replacement due to theft, please record
the following information, which will help protect your investment.
Model and Serial # ____________________________________
Dealer's Name _______________________________________
Date of Purchase _____________________________________
Installation Shop ______________________________________
Installation Date ______________________________________
CAUTION!
Prolonged listening at high levels may result in hearing loss. Even
though your new Soundstream REFERENCE amplifier sounds better
than anything you've ever heard, exercise caution to prevent hearing
damage.
Amplifier, the product of an
engineering philosophy.
2
POWER
Your
Watts
Watts
Watts
THD
Signal to Noise
Frequency Response
Stereo Separation
Damping
Input Sensitivity
Input Impedance
Crossover Specifications
Low Pass: 45 - 180 Hz at 12 dB/Octave
High Pass: 45 - 180 Hz at 12 dB/Octave
LSE.Q (REFERENCE1000s)
0.7 - 2.8 Q (0 TO +9 dB), adjustment from 30 to 60 Hz
Dimensions (W x D x H)
REFERENCE500s: 11.0" x 9.8" x 2.25"
REFERENCE700s: 12.25" x 9.8" x 2.25"
REFERENCE1000s: 16.0" x 9.8" x 2.25"

SPECIFICATIONS

4 Stereo 2 Stereo 1
(8 Bridged) (4 Bridged) (2
(12 Vdc)
REFERENCE500s
75 x 2 150 x 2 250 x 2
(150 x 1) (300 x 1) (500 x 1)
REFERENCE700s
125 x 2 250 x 2 350 x 2
(250 x 1) (500 x 1) (700 x 1)
REFERENCE1000s
200 x 2 400 x 2 500 x 2
(400 x 1) (800 x 1) (1000 x 1)
<0.1%
>100 dB
20 Hz to 20 kHz
>90 dB
>200
200mV - 2.0V, or 500mV to 5.0V
10K ohms
23
Stereo 1/2 Stereo
Bridged) (1 Bridged)
250 x 2
(500 x 1)
350 x 2
(700 x 1)
500 x 2
(1000 x 1)
0.5 dB
