- Page 2 CONTENTS Installation Wiring Connection Operation Specification INSTALLATION PRECAUTIONS • Choose the mounting location carefully so that the unit will not interfere with the normal driving functions of the driver. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight or hot air from the heater, or where it would be subject to dust, dirt or excessive vibration.
-
Page 3: Wiring Connection
INSTALLATION TO SUPPORT THE UNIT Dashboard CONNECTOR A 4. MEMORY + 12V 5. AUTO ANTENNA OUTPUT 7. +12V (TO IGNITION KEY) 8. GROUND Note: (connector A no. 7) must be connected by car ignition key in order to avoid that car battery not used for long period CONNECTOR B... - Page 4 When pressed longer than 1 sec., they will operate as CUE or REVIEW mode. LCD DISPLAY The Liquid Crystal Display will display the current state of the unit. SELECT SMP3-100R STEREO/MONO SELECTOR This function will only affect the FM reception. Press this button if the FM reception becomes noisy/hissy. If the station being received is in stereo, it will now be played in mono.
- Page 5 When press the SEL button for more than 2 seconds, it is activated as selecting mode of these function. 2 sec. SMP3-100R SEEK 1: When SEEK 1 mode is activated, AUTO SEEK SCAN is stopped when station is detected even user still push SEEK button.
- Page 6 • Press “SEL”, then the first digit will flash. • With “VOL • Press “SEL”, then the first digit is fixed and second digit will flash. SMP3-100R • With “VOL • Then automatically the song selected will start. 2. Searching File Name: •...
-
Page 7: Specifications
OPERATION REMOTE CONTROL POWER: Use to turn the CD receiver ON or OFF SEL Turning the VOL knob Right or Left, you can adjust VOL/BASS/TREB/BAL/FAD. To select other functions, press the SEL button shortly until the desired functions is shown on the display. VOLUME Use to increase or decrease volume level.
