  • Page 1 Operation Manual Network System Remote Mic Station RM-N10...
  • Page 2 A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
  • Page 3: Table Of Contents

    Contents and Accessories ....................3 Front Panel ........................4 Rear Panel .........................6 How To Set Up The Device And Precautions ...............8 Applications ........................13 Block Diagram ........................14 Specifications ........................15 Service Procedures ........................17 Schematic ........................17 Parts List..........................17 Variations and Options ....................17 Warranty .........................17 RM-N10...
  • Page 4: Unpacking

    NETWORK SYSTEM REMOTE MIC STATION Unpacking Unpacking Although your RM-N10 is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation.
  • Page 5: Features

    Features Features - BROADCAST PAGING VIA NETWORK The device can connect Inter-M’s Network Connecting System and paging broadcast through it. - GOOSENECK MICROPHONE You can use the gooseneck microphone to broadcast paging in each area. - 0~9 KEY, ALL, TALK, CHIME BUTTON You can select the broadcasting area simply by using the 0~9 key and the All button.
  • Page 6: Front Panel

    You can use the buttons to select the number of broadcasting areas or various modes. 5. TALK BUTTON Press the button to start broadcasting after selecting a broadcasting area. Refer to the 5. Talk Type Settings on page 18 of this manual for detailed information about the Talk button settings. RM-N10...
  • Page 7 It is the LED that shows the power status and communication status. The power LED is lit when power is applied, and the communication LED is lit to indicate Primary/Secondary operating status. 9. MONITOR / AUX / CHIME VOLUME This volume controls the MONITOR/AUX/CHIME output. RM-N10...
  • Page 8: Rear Panel

    It is a terminal to connect the device to the network. You can control the broadcasting by using integration software. ※ For more information on how to set up, refer to the integration software manual. Download the manual at home page. (www.inter-m.net) <100 Base-T> <1G Base-T>...
  • Page 9 4. AUX INPUT TERMINAL You can use this terminal to use the AUX IN jack to input an external sound source and broadcast through the RM-N10. 5. MIC GAIN ADJUSTMENT VOLUME This is the volume that adjusts the input GAIN of the microphone.
  • Page 10: How To Set Up The Device And Precautions

    ※ For more details, please refer to the manual of integrated management software. 3) The EVENT & PRESET can be set up on system set-up menu of the integrated management software. 4) If there is no input for 30 seconds on the standby screen, it switches to the sleep screen. RM-N10...
  • Page 11 6) You can repeat the step 4) and 6) to register multiple numbers. 7) Multiple numbers can be registered through repeating step 4) and 6). Selected key number registration line 8) If you want to cancel after adding a number to broadcast, re-enter the same number to remove it (Remove). RM-N10...
  • Page 12 1) The 1~5 Key on the front left side of the device. Press the 1 ~ 5 key to corresponding number is input. +3dB 2) The following screen is displayed when selecting key 1 of left 1 ~ 5 keys. 3) If the Talk Protocol is set up with Isls-CP, Isls-Group and Isls-Zone mode, it can be used as CP Event. RM-N10...
  • Page 13 2) Press the number button 2 to select Push to Talk. ※ If set to Push to Talk, the RM broadcast is output only while you press and hold the Talk button after selecting Zone. If the Talk button is Off, the broadcasting is ended. RM-N10...
  • Page 14 ※ M: Main board firmware version, F: Front board firmware version 2) Press the MENU button on the Firmware version screen to switch to the Chime Set screen, where you can switch from the MENU screen to standby screen by pressing the PREV button. RM-N10...
  • Page 15: Applications

    Contact Network(UTP) CONTROL PC L2 SWITCHING HUB fire receiver (P type fire signal) SYSTEM REMOTE MIC STATION POWER AMPLIFIER MAIN CONTROLLER(IPA-10) SPEAKER LINE MULTI SOURCE PLAYER CHECKER(IPA-R10) (CD-6208) NETWORK TRANSCEIVER(IPA-T10) ATTENUATOR fire receiver (P type/R type fire signal) SPEAKER RM-N10...
  • Page 16: Block Diagram

    NETWORK SYSTEM REMOTE MIC STATION Block Diagram Block Diagram RM-N10...
  • Page 17: Specifications

    NETWORK SYSTEM REMOTE MIC STATION Specifications Specifications RM-N10 Audio Feature Input Sensitivity -50dBV ± 3dB Output Sensitivity +10dBV ± 3dB Signal-to-noise Ratio More than 65dB (<20 kHz LPF) THD (<20kHzLPF) Less than 0.1% Frequency Response 100 Hz ~ 18 kHz 0dB ±...
  • Page 18 NETWORK SYSTEM REMOTE MIC STATION ※ DIMENSIONS RM-N10...
  • Page 19: Service

    To obtain specific warranty information and available service locations contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region.
  • Page 20 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
