  • Page 1 HIGHlite 4100gv HIGHlite 4100gvcc HIGHlite 5100gv Super High Brightness Digital Video Projector User Manual...
  • Page 2 HIGHlite 4100gv HIGHlite 4100gvcc HIGHlite 5100gv Super High Brightness Digital Video Projector User Manual...
  • Page 3 Precautions: Please read this manual carefully before using your CAUTION: To turn off main power, be sure to remove the plug from Digital Projection HIGHlite 5100gv/4100gv/4100gvcc Projector and power outlet. The power outlet socket should be installed as near to keep the manual handy for future reference.
  • Page 4 1500 hours of operation” e Do not attempt to stack projectors on the ceiling. Lamp Running Time is Over 1500 Hours!!” When you see this message please contact your Digital Projection Dealer for a re- To Dealer or Installer: placement.
  • Page 5 Ne pas superposer les projecteurs accrochés au plafond. Lorsque ce message s’affiche, prière de contacter son revendeur Digital Projection pour un remplacement. A l’attention du revendeur ou de l’installateur: Si la lampe explose, de la fumée peut être émise par les fentes Afin d’empêcher une chute éventuelle du projecteur, veuillez prendre...
  • Page 6 Low Voltage directive has been compiled by the signatory below and is available for inspection by the relevant enforcement authorities. The CE mark was first applied in May 2001 to HIGHlite 4100gv and HIGHlite 5100gv. The CE mark was first applied in September 2002 to HIGHlite 4100gvcc. Signed: Authority: D.J.
  • Page 7: Table Of Contents

    TABLE OF CONTENTS Video Adj ................ E-31 INTRODUCTION Noise Reduction ............E-31 Introduction to the 5100gv/4100gv/4100gvcc Projector ..E-1 Color Matrix ............. E-32 Getting Started ............... E-1 Y/C Delay ..............E-32 What's in the Box? ..............E-1 Telecine ..............E-32 Motion Select ............
  • Page 8: Introduction

    • CompactFlash Memory Card (8MB) with Adapter • A high-performance 1.0 KW Xenon lamp that delivers 5,000 ANSI (High-Bright mode: HIGHlite 5100gv) / 3,500 ANSI (Variable mode at max: HIGHlite 4100gv/4100gvcc) lumens with a lamp life of 1500 hours. • Digital Projection’s unique DLP based light engine offers true color reproduction.
  • Page 9: Part Names And Functions

    1. Part Names and Functions Stacking Pad (4 pcs) Digital Input Terminal Panel Remote Sensor PC Card Access Indicator PC Card Slot Insert a PC memory card here to upgrade the projector system software or copy data Lens (Optional) Carrying Handle Input Terminal Panel Ventilation (out) Ventilation (in)
  • Page 10: Projector

    Controls Remote sensor LENS SHIFT FOCUS ZOOM MENU SELECT ENTER INDICATOR POWER ON/OFF STATUS CANCEL 1. Power Button 6. Cancel Button Press to turn the projector on when the projector is in the standby con- Press this button to exit the menu. Press this button to return the adjust- dition (Main Power switch must be on and the POWER indicator lit or- ments to the last condition while you are in the adjustment or setting ange).
  • Page 11: Terminal Panel

    1. INPUT 3 RGB Connector (Mini D-Sub 15 pin) Terminal Panel Connect your PC or other analog RGB equipment such as a high-defi- nition document camera. 2. Option Connector (Mini D-Sub 9 pin) For system expansion such as PC-control. IN ....connect to the external equipment such as PC. INPUT3 INPUT2 INPUT1...
  • Page 12 Push the left side of the panel to open the compartment for the RGB Digital connectors and the optional SDI board. OUTPUT INPUT9 OUTPUT INPUT 0 DIGITAL Space to install the optional SD SDI board. (HIGHlite 5100gv only) 11. DVI Digital Video Interface RGB Digital Input/Output Connectors These connectors are used for double or triple stacking.
  • Page 13: Remote Control

    5 SELECT (Up/Down/Left/Right) Remote Control When pressed together, the CTL and buttons work as a Back Space key in the entry screen. Pressing and holding CTL, then this button moves the menu, slidebar or dialog box. POWER 6 ADJUST WHITE BAL Press to display the Color adjustment screen.
  • Page 14: Remote Control Precautions

    Remote Control Precautions 18 MUTE SOUND (available only when using with the ISS -6020 or IPS4000) • Use the remote control within a distance of about 7m (23feet) and at Turns off the sound for a short period of time. Press again to restore the an angle of 30˚...
  • Page 15: Installation

    2. INSTALLATION This section describes how to set up your projector and how to connect Screen Size and Projection Distance video and audio sources. Applicable lens and throw distance/ List of screen sizes Setting Up Your Projector Your Projector is simple to set up and use. But before you get started, you must first: 1.
  • Page 16: Lens Shift Adjustable Range

    Lens Shift Adjustable Range Lens Shift Adjustable Range for Desktop and Ceiling Mount Application The diagram below shows the location of the image position in the lens. The lens can be shifted within the shaded area as shown using the normal projection position as a starting point.
  • Page 17: Moving The Projector

    Moving The Projector Selecting A Location Always carry your projector by the handle. Ensure that the power cable The further your projector is from the screen or wall, the larger the im- and any other cables connecting to video sources are disconnected age.
  • Page 18: Setup

    3. SETUP Using the Power Cable Stopper Connecting the Power Cable and Turn- The Power cable wire stopper is provided on the projector so that the ing on the Projector cable cannot be accidentally unplugged from the AC IN. Before you turn on your projector, ensure that the computer or video 1.
  • Page 19: Set Up The Projector

    (2) Press and hold the CTL and press the ZOOM + or - button to adjust the Set up the projector image size. You can also adjust the image size by using the ZOOM + or - button on the projector cabinet. 1.
  • Page 20: Keystone

    Keystone 2) Hookup 2-1. Use the supplied DVI-D cable to connect the RGB DIGITAL output of the master projector to the RGB DIGITAL input (INPUT9 )of the slave projector (the second and third stack) until all the projectors are connected. Keystone distortion Normal 2-2.
  • Page 21 3-1-6-3. Remove the PC card from the slave projector. 6-4 Project a source image from all projectors 6-4-1. Display any signal onto the screen. NOTE: If you select the RGB1 input on the master projector, you must select the same input on the slave projector and the RGB2 on the master projector 6-4-2.
  • Page 22: Projector Orientation

    • Installing your projector on the ceiling must be done by a qualified An image can be projected from in front or behind a screen, and the technician. Contact your Digital Projection dealer for more information. projector can be installed on the ceiling*.
  • Page 23: Connections

    4. CONNECTIONS Connecting Your VCR Or Laser Disc Player When used in standalone operation Use common RCA cables (not provided) to connect your VCR or laser Connecting Your PC Or Macintosh Computer disc player to your HIGHlite 5100gv/4100gv/4100gvcc Projector. To Connecting your PC or Macintosh computer to HIGHlite 5100gv/ make these connections, simply: 4100gv/4100gvcc Projector will enable you to project your computer's...
  • Page 24: When Used With One Switcher (Iss-6020/Iss-6020G

    When Used with One Switcher (ISS-6020/ISS-6020G) Up to 10 input signals can be accepted when the projector is connected to one Switcher. Using the projector with the Switcher allows easy adjustment and signal selection. INPUT3 INPUT2 INPUT1 INPUT4 R/Cr R/Cr OPTION B/Cb B/Cb...
  • Page 25: When Used With Two Or More Switchers (100 Inputs

    NOTE: When Used with Two or More Switchers • Be sure to set all the slide switches (S8603) of the Switcher to RS-422 posi- (100 Inputs) tions. Set the one on the last slave Switcher to the appropriate position to match the connected equipment such as a personal computer.
  • Page 26 Set the DIP switch (S8601) of the Switcher as follows: NOTE: Slave numbers 1 to 10 must correspond to the master’s slot numbers 1 to 10. ISS-6020 Setting of S8601 Output to ISS-6020G OPEN Master The Projector 1 2 3 4 5 6 7 8 SHORT OPEN Slave 1...
  • Page 27: Remote 1 Connector

    REMOTE 1 Connector This connector is used for either connecting the ISS-6020/ISS-6020G Switcher or a third party external control device (Contact Closure). When the Switcher is used, connect it with the optional control cable (15-15 pin; 50 ft./16m; CTL-6010) to this connector. When used with the Switcher.
  • Page 28 When used in stand alone operation. Pin No. SHORT/OPEN FUNCTION SHORT External control mode ON External control mode OFF OPEN POWER ON SHORT POWER OFF OPEN PICTURE MUTE ON SHORT OPEN PICTURE MUTE OFF 12pin 8pin 11pin 4pin 4,8,12,11 OPEN OPEN RGB 1 (INPUT 1) OPEN...
  • Page 29: Operating Multiple Projectors With The Remote Control

    Operating Multiple Projectors with Remote Control You can operate multiple projectors with the same remote control in wireless operation. To do so: 1. Select [Menu] → [Projector Options] → [Setup] → [Page 5] → [Projector ID] and assign an ID number to each projector. See also page E-39. 2.
  • Page 30: Using The Rgb Digital Connectors (5100Gv Only

    Using the RGB DIGITAL connectors (HIGHlite 5100gv only) The Link mode function allows you to adjust or set multiple projectors using the RGB DIGITAL and OPTION connectors. The DVI DIGITAL input accepts up to the XGA (1024 x 768 @85Hz) signal. NOTE: The Auto Adjust feature does not work for DVI digital signal.
  • Page 31: Operation

    5. OPERATION This section describes how to select a computer or video source, adjust Using The Menus the picture and sound, edit a signal and adjust all other settings and adjustments for proper projector set-up. 1. Press the MENU button on the remote control to display the menu. 2.
  • Page 32: A List Of Direct Key Combinations

    A List of Direct Key Combinations CTL+ INPUT (1-10) Switches to any selected signal found in the Entry List. To enable this combination, you must first assign specific remote keys for direct input selection in the Entry Edit window. CTL+ ENTER (While displaying Entry list) Displays the Entry Edit Command window.
  • Page 33: Menu Tree

    Menu Tree When Switcher Control is turned on: Switcher Brightness Advanced Menu Entry List Contrast Source Select Saturation Adjust (Source) Stand alone Color Ref Adj RGB1 Factory Default RGB2 Sharpness Projector Options RGB3 V-Aperture PC Card Files Component (YCbCr) Gamma Correction Help NTSC, Graphics, Graphics/NTSC, PAL/SECAM2.8, Video1...
  • Page 34 Keystone Lamp Mode HIGHlite 5100gv: Auto / High-Bright / Variable HIGHlite 4100gv,4100gvcc: Auto / Variable Advanced Menu Lamp Output Lamp Source Select Ref. White Bal. Adjust (Source) Brightness R/G/B, Contrast R/G/B Ref Adj All Data / Current Signal Factory Default...
  • Page 35: Menu Elements

    Menu Elements Title bar Highlight Radio button OK Button Cancel Button Solid triangle Check box Slide bar Menu windows or dialog boxes typically have the following elements: Title bar: Indicates the menu title. Highlight: Indicates the selected menu or item. Solid triangle: Indicates further choices are available.
  • Page 36: Menu Descriptions & Functions

    Entry List Menu Descriptions & Functions Displays the list of the entry signals. Use the ▲▼ buttons on your re- Source Select mote control or the projector cabinet to select the signal and press the ENTER button on the remote control or the projector cabinet to project the image of the selected source.
  • Page 37: Adjust (Source

    Select "List" and press ENTER to display the direct Key assignment White Balance list. Select "OK" and press ENTER to close the window. To close the List window, press CANCEL on the remote. Color Temperature This feature adjusts the color temperature using the slide bar. Move the slide bar to the right to increase the color temperature for a bluish image;...
  • Page 38: Horizontal/Vertical Position

    Horizontal/Vertical Position (when Auto Adjust is off): Video Filter This feature reduces video noise. Select the appropriate filter for your signal. Bar 0 .... Off Adjusts the image location from left to right. Bar 1/3 ..High This adjustment is made automatically when the Auto Adjust is turned Bar 2/3 ..
  • Page 39: Color Matrix

    Color Matrix Option Adj Clamp Timing: First, select an appropriate color matrix for your input signal, either HDTV or SDTV. Then select an appropriate matrix type from B-Y/R- Y, U/V, Cb/Cr, Pb/Pr or IVX. NOTE: The Color Matrix feature is available for component video signal only. Y/C Delay (not available for RGB) According to the signal, this function sets the detection position (i.e., clamp position) of the black level reproduction of the analog input...
  • Page 40: Lens Memory

    Lens Memory Switcher (available only when used with ISS-6020) Switcher Gain The Lens Memory function stores the adjusted values when using shift, focus* and zoom buttons on the projector cabinet or the remote control for a specific signal. Example of usage: When a signal with 4:3 aspect ratio and a signal with 5:4 aspect ration both need to be displayed on the 4:3 screen.
  • Page 41: Lamp

    Lamp Projector Options Lamp Mode Enables you to set preferences and other operating options. Timer This feature allows the lamp power supply to operate under three set- tings. Auto ..... This setting keeps the projector's original light output level for a certain period of time. Enables you to turn the projector on or off automatically at a specified High-Bright (HIGHlite 5100gv only) time.
  • Page 42: Sleep Timer

    5. To enable your setting, select Active on the Execute Switch. Menu Display Time This option allows you to select how long the projector waits after the 6. Select OK and press the ENTER button on the remote control to complete last touch of a button to turn off the menu.
  • Page 43: Setup

    Setup [Page 3] Enables you to set operating options. Press "OK" to save your changes for all the features of Page1, Page2, Page3, Page 4 and Page5. [Page 1] Signal Select (VIDEO 1/2, S-VIDEO1/2 and Switcher) This feature enables you to select composite video standards manu- ally.
  • Page 44: User Name

    Keystone Save Link Mode This option enables you to save your current keystone settings. Saving your change once affects all sources. The changes are saved when you turn off the projector. Lens Memory This feature is used for multiple projector connection using RGB This function applies the stored lens shift, focus, and zoom adjust- Digital Input/Output connectors.
  • Page 45: Pc Card Files

    PC Card Files Help Displays a list of all the files stored in the PC card so that you can select a file you want to display. You can also sort files by file name or date, or display the file. Although a list of all the files in the PC card is displayed, you can view files in idx, text, HTML, JPEG and BMP format only.
  • Page 46: Link Mode

    [Page 4] Test Pattern Press to display the test pattern. Pressing this button sequentially se- lects nine test patterns. Link Mode Selecting a new signal that is close to one of the Displaying Current Status of Link Mode listed signals in horizontal and vertical frequency When selecting the tab "Page 4 ", you will get the following dialog box.
  • Page 47: Specifications

    Built in: Overheat Protection Lamp Over-Usage Protection Light Output HIGHlite 5100gv: 5,000 ANSI lumens (High-Bright mode) 4,300 ANSI lumens (Normal mode) HIGHlite 4100gv: 3,500 ANSI lumens (Variable mode) HIGHlite 4100gvcc: >2000 ANSI lumens (Variable mode) Full Light Output at 200- 240V Brightness Uniformity >80% edge to center...
  • Page 48 External Control RS232C (1) D-sub 9 pin Contact Closure Switcher (2) D-sub 15 pin In/Out Addressable Remote Control (wired / wireless) Power Requirement 100-120 / 200-240 VAC, 50/60Hz Input Current 11 A / 7.3 A Power Consumption 1.0 kW / 1.5 KW Mechanical Installation Orientation:...
  • Page 49: Optional Accessories

    7. Optional Accessories Lens TL-08SF (Short Focal Lens 0.84) : 10kg LA00111 TL-1Z/1ZX (Zoom Lens 1.5 - 2.5:1) :5.5kg Normal - LA00107, High Contrast - LA00282 TL-2Z/2ZX (Zoom Lens 2.5 - 4.0:1) : 4.5kg Normal - LA00108, High Contrast - LA00281 TL-4Z (Zoom Lens 4.0 - 7.0:1) : 4.5kg LA00109 Interface Board SD SDI BOARD - LA00105...
  • Page 50: Compatible Input Signal List

    8. Compatible Input Signal List Compatible Input Signal List Signal Name Resolution (H V) Horizontal Frequency Vertical Frequency Video (NTSC) 15.734 60.0 Video (PAL/SECAM) 15.625 50.0 Video (HDTV) 480p 31.5 60.0 (SX6000 only) 1280 720p 45.0 60.0 1920 1035 33.75 60.0 1920 1080p...
  • Page 51: List Of Menu Items Available On Link Mode

    List of Menu Items Available on Link Mode See the table below for available functions in the digital link mode (HIGHlite 5100gv only) and the analog link mode. * The digital signals available in the Link mode are the VESA compatible-signals except interlaced signals of VGA@60Hz to XGA@85Hz. * The VESA compatible signals that can connect to the master projector as analog input and connect to the slave projector as digital output are interlaced signals of SVGA@85Hz, XGA@60Hz, XGA@70Hz, XGA@75Hz and XGA@85Hz.
  • Page 52: Appendix

    Appendix Dimensions 30 (1.18) 506 (19.92) 35.5 (1.40) (2.76) 300 (11.81) 326 (12.83) The drawings do not include the lens part. Unit: mm (inch) E – 45...
  • Page 53: Tips On Adjusting Focus For Lens Memory Function

    Tips on Adjusting Focus for Lens Memory Function Optimum focus for lens memory function can be achieved on the projector by paying special attention in a few areas. Focus adjustment after the projector has warmed up to normal operating temperature is better than doing so when the projector is cold. Lens mechanics interact differently when adjusting focus from one direction to the other.
