BATTERY PACK
SHOWN INCHARGER CI'.I_GING
ASSEMBLY
TO REMOVE BATTERY PACK
See Figure3.
• Lock the switch triggeran the drill by placingthe direc-
tion of rotation selectorin the center position.
• Locate the latcheson the side of the battery pack and
depress to releasethe battery pack fTomthe drill.
• Remove the battery pack from the drill.
REDLED
ORANGE LED
CHARGING STAND
Fig. 2
TO INSTALL BATTERY PACK
See FTgure3.
• Lock the switch trigger on the drillby placingthe direc-
t(on of rotation selector in the center position.
• Place the battery pack in the ddlLAlignthe raised rib
on the bakery pack wtth the groove Inside the drill
CAUTION: When placing baC_tery paeY, _ nthe tool,
be sure raised rib on battery pack alignswith the
bottom of the ddll and latches into place propedy.
Improper installationof the battery pack can _use
damage to internalcomponents.
• Make sure the latches on each side of the battery pack
snap into place and the battery pack issecwed in the
dd[{before beginning operation.
DEPRESS UITCHES TO
RELEASE B AT'rERY P ACK
LATCHES
F_g.3
11
