- Page 1 AS-603UR Operation Manual AS-61VR / RC-603VR/RPS-1 Set 6x3 Automatic Wireless Antenna Switch with Rotator Controller Commands over RF Cable Operation from 1.8 MHz to 450 MHz AS-603UR Operation Manual V. 1.1 http://www.hamplus.com...
- Page 2 To facilitate the operation, the RC-603VR has an internal switch that switches the Send command and the Com port to the selected Radio. The AS-603UR supports communication with the following radios: Icom (CI-V), Kenwood (RS-232), Elecraft K3 (RS-232), Yaesu (RS-232), Flex Radio (RS- 232) or any other Radio that uses one of these communication protocols.
- Page 3 RC-603VR with a cable, such as Hamplus ERC-6, IRC-6, KRC-6, YRC-6, FRC-6 or YRC-61, and the radio set to the correct baud rate (19,200 baud CI-V or 4800 baud CAT and COM) and set up as described in the previous section.
- Page 4 RC-603VR automatically change to the correct antenna. Correct any wrong Ant # on any band by manual selection. AS-603UR – Operation Manual Page...
- Page 5 Rotator clockwise (cw) in one complete revolution (360 degrees) using the Ant6 (cw) button and Ant4 (ccw) button until it reaches exactly the point where the Rotator started the turn. This is the end point of the Rotator stroke. AS-603UR – Operation Manual Page...
- Page 6 First step- Press the Encoder for five seconds. At this moment the buttons Ant1, Ant2, Ant3, Ant5 and Ant6 start to flash. b- Second step- To change the indication, press the Ant5 button. To abort the procedure, press the Ant6 button. AS-603UR – Operation Manual Page...
- Page 7 The Rotators that can be used with this controller are those with a 24 VDC motor and the direction indicator is a 500 Homs one-turn potentiometer, or a 10K Homs 10- turn potentiometer. Like Yaesu G800, G1000, G2800, Special Engine, Prosistel and others. -----------------------x---------------------- AS-603UR – Operation Manual Page...
- Page 8 2- Radio selection buttons 3- Azimuth indicator display 4- Power On LED indicator 5- Split Antenna LED indicator 6- Send indicator LED 7- Rotor 1 indicator LED 8- Encoder button 9- Rotor 2 indicator LED AS-603UR – Operation Manual Page...
- Page 9 4- Send Radio 2 11- RS-232 Remote Control Com 5- Send Radio 1 12- RF from Radio 1 6- RF from Radio 2 13- RF from Radio 3 7- RF Out to AS-61VR 14- GND AS-603UR – Operation Manual Page...
- Page 10 AS-603UR – Operation Manual Page...
- Page 11 Diagram of blocks and connections of the antenna switch AS-603UR without the rotator power supply module, mounted in two cabinets Cabinet 1 contains the RC-603VR controller Cabinet 2 contains the AS-61VR antenna switch AS-603UR – Operation Manual Page...
- Page 12 Diagram of the blocks and connections of the antenna switch AS-603UR with the rotator power supply module, mounted in three cabinets Cabinet 1 contains the RC-603VR controller Cabinet 2 contains the AS-61VR antenna switch Cabinet 3 contains the RPS-1 rotator power supply AS-603UR –...
- Page 13 Diagram of blocks and connections of the antenna switch AS-603UR with the rotator power supply module, mounted in two cabinets Cabinet 1 contains the RC-603VR controller Cabinet 2 contains the antenna switch and the rotator power supply AS-61VRP AS-603UR – Operation Manual...
- Page 14 AS-603UR – Operation Manual Page...
- Page 15 AS-603UR – Operation Manual Page...
- Page 16 AS-603UR – Operation Manual Page...
- Page 17 AS-603UR – Operation Manual Page...
- Page 18 AS-603UR – Operation Manual Page...
- Page 19 AS-603UR – Operation Manual Page...
- Page 20 AS-603UR – Operation Manual Page...
- Page 21 AS-603UR – Operation Manual Page...
- Page 22 AS-603UR – Operation Manual Page...
- Page 23 AS-603UR – Operation Manual Page...
