TP-Link TL-MR105 V1 Quick Installation Manual

Quick Installation Guide
Wireless 4G LTE Router
Images may differ from actual products.
©2023 TP-Link 7106510133 REV1.0.0

2. Verify the Hardware Connection

Check the following LEDs' status. If the Internet LED
connected to the internet successfully.
Power Internet Wi-Fi
On On On
Note: If the Internet LED does not turn on, please refer to Q2 of Need Help in this guide.
For better internet connection, make sure
router to a spot that may receive a stronger mobile network signal, such as near a
window.
is on, your router is
or is lit. Otherwise, try relocating the

1. Connect the Hardware

a. Insert the Nano SIM card into
the slot until you hear a click.
Tip:
You can also install and enable external antennas (not provided).
For detailed instructions, refer to the user guide at
https://www.tp-link.com/en/support/download/

3. Enjoy the Internet

Wired
Connect your computer to the router's LAN port via an Ethernet cable.
Wireless
a.
Find the default SSID (network name)
and wireless password printed on the
label at the bottom of the router.
b. Click the network icon of your computer or go to Wi-Fi settings of your smart device,
and then select the SSID to join the network.
b. Connect the power adapter
to the router.
Power Adapter
Wireless Password/PIN: XXXXXXXX
SSID:TP-Link_XXXX
Wireless Password/PIN: XXXXXXXX
SSID:TP-Link_XXXX
