Model 1631-06C
PCB L&T S-Type Load Cell, 5,000 lbf rated capacity, 150% of RO static overload protection,
2mV/V output, 5/8-18 UNF threads, integral 10 ft cable w/ open end, nickel-plated steel
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: 716-684-0987
E-mail: info@pcb.com
Web: www.pcb.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1631-06C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PCB Piezotronics 1631-06C

Summary of Contents for PCB Piezotronics 1631-06C

  • Page 1 PCB L&T S-Type Load Cell, 5,000 lbf rated capacity, 150% of RO static overload protection, 2mV/V output, 5/8-18 UNF threads, integral 10 ft cable w/ open end, nickel-plated steel Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 716-684-0001 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com...
  • Page 2  Assistance is needed to safely operate equipment  PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected  calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
  • Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
  • Page 5 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.

  • Page 6: Table Of Contents

    S-TYPE LOAD CELL OPERATION MANUAL TABLE OF CONTENTS 1.0 INTRODUCTION ........................2 2.0 SAFETY PRECAUTIONS ....................2 3.0 OVERVIEW .......................... 2 3.1 Dimensions ............................2 4.0 MECHANICAL INSTALLATION ..................2 5.0 ELECTRICAL INSTALLATION ................... 2 5.1 Electrical Drawing / Western Regional Std..................3 5.2 Output Polarity ..........................

  • Page 7: Introduction

    Figure 2 - Dimensions Figure 1 – S-Type Load Cell Loading Table 2 - Dimension Values Series Number The following document explains the characteristics and Dimensions 1630 1631 1631-06C (see Figure 2) installation of the S-type load cells. (in) (mm) (in) (in) (in) (mm) 2.50...

  • Page 8: Electrical Drawing / Western Regional Std

    S-TYPE LOAD CELL OPERATION MANUAL 5.1 Electrical Drawing / Western Regional Std. The instrument or control system is grounded through its power cord. Ground loops and measuring system wiring may All load cells are wired following the Western Region result in unstable or noisy signals. Standard.

  • Page 9: Hysteresis

    S-TYPE LOAD CELL OPERATION MANUAL 7.1 Resistor Value 6.1.2 Hysteresis S-type load cells have a nominal 2.0 mV/V full scale output. The difference between the ascending and descending For a 350 ohm strain gage bridge the precision shunt resistor measured readings at 40% of full scale is used to calculate the is, 60,000 ohms ±...

  • Page 10: Trouble Shooting

    S-TYPE LOAD CELL OPERATION MANUAL Yearly calibrations are recommended to ensure that the unit’s Standard calibration certificates list five force points outputs match the factory specifications. ascending and one point descending. Additional data points are available at extra cost upon request. A 60 K ohm (±0.1%) shunt calibration resistor is supplied with each load cell 9.0 TROUBLE SHOOTING calibration.
  • Page 11 Model Number Revision: E STRAIN GAGE LOAD CELL 1631-06C ECN #: 43825 Performance ENGLISH OPTIONAL VERSIONS Measurement Range 5000 lb 22.2 kN Optional versions have identical specifications and accessories as listed for the standard Sensitivity(± 10 %) 2 mV/V 2 mV/V model except where noted below.
  • Page 12 X ± 0.3 XXX ±.005 XX ± 0.13 (716) 684-0001 E-MAIL: ltinfo@pcbloadtorque.com OUTLINE DRAWING DWG. NO. ANGLES .5 DEGREES ANGLES .5 DEGREES MODEL 1631-06C 46139 S-CELL FILLETS AND RADII FILLETS AND RADII SCALE: FULL SHEET 1 OF 1 .015 MAX...
