INSTALLATION AND OPERATION GUIDE FOR
HARGROVE VENTED GAS LOGS
Ember Burner or H-Burner with COOL MOUNT Manual Safety Pilot Valve (1B*CMT)
Installation and service must be provided by a qualified installer, service agency or the gas supplier.
NOTE:
ADEQUATE FIREPLACE VENTILATION IS REQUIRED FOR SAFETY.
READ INSTRUCTIONS FULLY BEFORE INSTALLING OR OPERATING.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
WARNING:
If the information in this manual is not
followed exactly, a fire or explosion may
result, causing property damage, personal
injury, or loss of life.
WHAT TO DO IF YOU SMELL GAS
1. Open a window.
2. Do not try to light any appliance.
3. Do not touch any electrical switch; do not
use the phone in your building.
4. Immediately call your gas supplier from a
neighbor's
phone.
supplier's instructions.
5. If you cannot reach your gas supplier, call
the fire department.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
IMPORTANT:
Installation and service must
be performed by a qualified professional
installer, service agency, or the gas supplier.
NOTE:
This appliance is only for use with the
type of gas indicated on the rating plate.
Solid-fuels shall not be burned in a fireplace
where a decorative appliance is installed.
DESIGN CERTIFIED to ANSI Z21.60/CGA 2.26
Vented Decorative Appliance for Installation in
Solid-Fuel Burning Fireplaces.
Follow
the
This Hargrove vented gas log set is to be
installed only in a solid-fuel burning fireplace
with a working flue and constructed of
noncombustible material.
including provisions for combustion and
ventilation air must conform to the National
Fuel Gas Code, ANSI Z223.1/NFPA 54, or the
CSA B149.1, Natural Gas and Propane
Installation Code, and applicable local building
code. A damper clamp is included to maintain
the minimum permanent vent opening and to
prevent full closure of the damper blade. The
gas log set must be burned with the damper
completely open (In the Commonwealth of
gas
Massachusetts the damper must either be
welded in the fully open position or
completely removed) and the chimney free
of any obstructions or restrictions.
The realistic yellow flame produces carbon
monoxide and soot. Under normal conditions,
these products are exhausted up the chimney.
If fumes or soot, from the gas burning, are
evident in the room when the damper is fully
open it indicates that the fireplace draft is
defective. Do not operate your gas log set
until the fireplace draft is corrected. It is the
home-owners responsibility to assure their
fireplace has adequate draft.
ANSI
The installation,
REV 090623
