INSTALLATION AND OPERATION GUIDE FOR
ADEQUATE FIREPLACE VENTILATION IS REQUIRED FOR SAFETY.
GAS LOGS MUST BE INSTALLED BY PERSONNEL QUALIFIED FOR IN-
STALLING GAS APPLIANCES.
NOTE !
READ INSTRUCTIONS FULLY BEFORE INSTALLING OR OPERATING.
INSTALLERS LEAVE THESE INSTRUCTIONS WITH CONSUMER!
Hargrove Manufacturing Corporation uses refractory material to create ceramic logs. Each log is
hand finished to assure the most realistic, detailed log available. The gas log burner system is
designed to burn like wood with a yellow smoky flame. For this reason the gas log set must be
burned only in a fully vented, non-combustible fireplace with the damper completely open and the
chimney free of any obstructions or restrictions. The fireplace must be designed and approved to
burn wood. The minimum permanent, free opening provided by the fireplace chimney must be 8" in
diameter (50 square inches)
IT IS THE HOMEOWNERS RESPONSIBILITY TO ASSURE
The realistic yellow flame produces carbon monoxide and soot. Under normal conditions these
products are exhausted up the chimney. If fumes or soot from the gas burning are evidenced in the
room when the damper is fully open, it indicates that the fireplace draft is defective. Do not operate
your gas log set until the fireplace draft is corrected. ADEQUATE VENTILATION IS REQUIRED.
WARNING:
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EX-
PLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY
IF YOU SMELL GAS:
1. OPEN WINDOWS
2. DON'T TOUCH ELECTRICAL SWITCHES
3. EXTINGUISH ANY OPEN FLAMES
4. IMMEDIATELY CALL YOUR GAS SUPPLIER
FLAMMABLE VAPORS MAY BE
DRAWN BY AIR CURRENTS
FROM OTHER AREAS OF YOUR
HOUSE TO THIS APPLIANCE.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR
OTHER FLAMMABLE VAPORS AND LIQ-
UIDS IN THE VICINITY OF THIS OR ANY
OTHER APPLIANCE.
HARGROVE
NATURAL GAS
THEIR FIREPLACE HAS ADEQUATE DRAFT.
GAS LOGS
THE SIZE CHART BELOW INDICATES
THE MINIMUM SIZE FIREPLACE OPEN-
INGS IN WHICH DIFFERENT SIZE GAS
LOG SETS CAN BE INSTALLED.
FIREPLACE SIZES
GAS LOG
SET SIZE
18
24
DEPTH
FRONT
WIDTH
13"
22"
14"
28"
Advertisement
Table of Contents
Related Manuals for Hargrove GAS LOGS
Summary of Contents for Hargrove GAS LOGS
-
Page 1: Natural Gas
READ INSTRUCTIONS FULLY BEFORE INSTALLING OR OPERATING. INSTALLERS LEAVE THESE INSTRUCTIONS WITH CONSUMER! Hargrove Manufacturing Corporation uses refractory material to create ceramic logs. Each log is hand finished to assure the most realistic, detailed log available. The gas log burner system is designed to burn like wood with a yellow smoky flame. - Page 2 Birch logs. Rubbing will remove soot but will also remove the white pigments. 9. Do not burn wood with this set NOTE : GAS LOGS MUST BE INSTALLED BY PERSONNEL QUALIFIED TO INSTALL GAS APPLIANCES. HARGROVE INSTALLING YOUR GAS LOGS Remove all the parts from the shipping container.
- Page 3 3". * CAUTION * THE DAMPER MUST BE FULLY OPEN WHEN OPERATING THE GAS LOGS! Figure 1 EMBER BURNER POSITIONING Turn gas off. Remove old log lighter, ashes, and other material from the firebox.
- Page 4 BURNER PAN MEDIA 1. Fill the burner pan with silica sand. Sand level should be sloped evenly with the sides of ember burner. Place 2/3 of the Part A Embers on top of the sand. Burner should be completely full and level. 2.
- Page 5 HARGROVE GAS LOGS CONCENTRIC VALVE (CPE-PO) PILOT CONTROL SYSTEM INSTALLATION INSTRUCTIONS This gas pilot safety valve provides 100% shut-off of both pilot and main burner gas supply in the event of FOR YOUR SAFETY pilot flame failure. This valve is equipped with a manual gas control knob to provide for pilot lighting.
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS ! WARNING ! Fire hazard. Do not disassemble or attempt repair of this unit. Disassembly, reassembly or internal adjustment could cause valve to malfunction, resulting in personal injury, death or property damage. If the control valve does not operate properly following installation or service, replace the unit. DO NOT INSTALL CPC-C BEHIND THE Fig.1 Valves may not shut off if flow is... - Page 7 INSTALLATION INSTRUCTIONS This gas valve should be installed according to the CPC INSTALLATION following instructions. Check for gas leaks with a See Fig. 3 soap solution after completing installation. 1) Attach the Brass 50-6-8 (in accessory kit parts packet) to the pipe extending out of the Ember Burner MAIN PIPING CONNECTIONS pan.
-
Page 8: Lighting Instructions
LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot, which must be lit by PILOT LIGHTING PROCEDURE hand. - Page 9 ARGROVE ANUFACTURING ORPORATION AFETY ILOT ONTROL ROUBLE HOOTING UIDE POSSIBLE CAUSES: CORRECTIVE ACTIONS 1) Nature of Trouble: Pilot light won't light. Gas supply off. Turn gas supply on. Air in line. Bleed gas through ember burner until all the air is out of the line.
- Page 10 5) Nature of Trouble: Pilot light goes out when ember burner is turned on. Ember burner robs gas from Turn gas to ember burner on slower. line feeding the pilot light. Replace orifice adapter to ember burner with an orifice adapter with a smaller opening.
-
Page 11: Limited Warranty
8. Purchaser or user agrees to hold Hargrove Mfg Corp. harmless from any and all claims by the buyer as a result of injury or damage to an ultimate user or other person caused by the product sold herein by the seller to the buyer, whether the injury or damage results from the assembly, installation, operation, shipment, storage, or manufacture of this product.
