V-TAC 80133970 Instruction Manual

Energy storage power supply
Hide thumbs Also See for 80133970:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
ENERGY STORAGE POWER SUPPLY
TECHNICAL DATA
Model
Battery capacity
Net Weight
Ac Rated Output
AC Input
Solar Charge
AC Output
Telescoping handle
Auxiliary Charge
Output
Dimension
USB Output Port
QC Output
USB-C Output
Wireless Charging
Output
Cycle Life
Thank you for selecting and buying V-TAC Product. V-TAC will serve you the best.
Please read these instructions carefully & keep this user manual handy for future
reference. If you have any another query, please contact our dealer or local vendor
from whom you have purchased the product. They are trained and ready to serve you
at the best.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
VT-2002
2016Wh
25Kg
2000W
1600W
DC: 12-60V Max
700W solar panel
230V, Pure Sine Wave
2000W, Peak 4000W
1.2m
13.5V 9A (Max 100W)
470x367x292mm
5v 2.4A
5V/9V/12V/18W
5V 3A/9V 3A/12V 3A
/15V 3A/ 20V3.25A
PD65W
15W
Cycled > 2000
LiFePO4 Battery
INTRODUCTION
Multi-Language Manual QR CODE
Please scan the QR code to access the manual
in multiple languages.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 80133970 and is the answer not in the manual?

Questions and answers

Related Manuals for V-TAC 80133970

Summary of Contents for V-TAC 80133970

  • Page 1 Please scan the QR code to access the manual in multiple languages. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B...

  • Page 2: Packaging List

    WARNING 1. Please make sure to turn off the power before starting 9. Please charge the product in a well ventilated place. the installation. Do not restrict the ventilation of the product in any 2. Installation must be performed by a qualified electrician. way.

  • Page 3: Precautions For Use

    LCD Screen Cooling outlet AC Switch Wire control interface 5V/2.4A Quick Charge DC charging It can be charged by solar energy Wireless charging Switch Safety Switch 15W - Wireless charging AC fast charging Rollable wheels 230V output Power Switch (click on start, Telescoping handle press 3 seconds to shut down) Portable Handle...

  • Page 4: Troubleshooting

    FAQS 1. Can the product be brought on the plane? larger than the peak value of rated power cannot be No, because this product is a lithium battery product. used; According to the 3. Why is there sound when using it? international air transport standard regulations, carrying The product adopts air cooling system, and the built-in fan is better to help product heat dissipation.
  • Page 5 Portable Power Station 2000W V-TAC.EU VTACEXPORTS.COM...
  • Page 6 Intelligent monitoring Real-time monitoring of product performance. Short-circuit protection Auto-cut circuit when LISTING DETAILS MASTER BOX PACKAGING short occurs. Model: VT-2002 Qty: 1pc/box SKU Code: 11445 Net Weight : 25KG Overcharge protection Prevent battery from overcharging EAN Code: 3800157692250 Product Size : 470*367*292 mm and auto-stop when fully charged.
  • Page 7 High efficient solar charger MPPT technology for efficient charging Enhanced battery life with Intelligent Advanced power management system - MPPT power efficient Solar energy Charging Maximum power point tracking...
  • Page 8 Power button DC on/o switch Wireless on/o switch AC on/o switch Display screen USB on/o switch TYPE-C output ports USB output ports Auxiliary Charge Output LED High-brightness Display Screen...
  • Page 9 Power a wide range of appliances with multiple AC output AC Output 230V x 3...
  • Page 10 WiFi Port Fuse Solar charge port Input: AC Quick Charge Power a wide range of appliances with multiple DC output...

  • Page 11: Wireless Charger

    Wireless charger Power Delivery...
  • Page 12 Trolley-style design Telescoping handle to prioritize ease of movement...
  • Page 13 Travel Leisure Bring the power right where you need it. Our portable power stations aim to help you power Stay powered and connected. Charge your New spot for your hobbies? Or just a new basic necessities wherever you are – whether devices anywhere –...

  • Page 14: Certificate Of Conformity

    CERTIFICATE OF CONFORMITY Certificate No.: TBC-C-202305-0154-1 Applicant : V-TAC EXPORTS LIMITED : Room 301 Kam ON Building 176A, Queen’s Road Central Address HongKong Manufacturer : Dongguan Zhiding Innovation Electronics Co., Ltd. Address : Floor 5, building 6, Wanjin hi tech Industrial Park, No. 10, Qiaoxi...
  • Page 15 CERTIFICATE OF CONFORMITY Certificate No.: TBC-C-202305-0154-1 Technical Description Frequency Range : Wireless Charging: 110KHz~205KHz Max Field Strength 55.24dBuA/m The EUT described above has been tested by us with the listed standards according to the Council Directive 2014/53/EU relating to radio equipment, and found in compliance with all essential requirements of the Directive.

  • Page 16: Declaration Of Conformity

    Declaration of Conformity Certificate No.：TBC-C-202305-0154-2 Applicant Company : V-TAC EXPORTS LIMITED Company Address : Room 301 Kam ON Building 176A ,Queen’s Road Central HongKong Sample Name : portable energy storage power supply Trade Mark Basic Model No. : VT-2002 Series Model No.
