Installation and Operation Manual
BISTRO WOOD BURNING
This manual is available for free download on the distributor's web site. It is a copyrighted document. Re-sale is strictly
prohibited. The distributor may update this manual from time to time and cannot be responsible for problems, injuries,
or damages arising out of the use of information contained in any manual obtained from unauthorized sources.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN LOCAL AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD BURNING COOKSTOVE. FAILURE TO FOLLOW
THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
COOKSTOVE
(DB04816 model)
Distributed by
My Fireplace Australia PTY Ltd
www.myfireplaceaustralia.com.au
20 Auto Way
Pakenham, Victoria 3810 AUSTRALIA
Phone: 03 59 415 008
Fax: 03 59 415 975
Email: info@myfireplaceaustralia.com.au
46332A
2022-12-05

Advertisement

Table of Contents
loading

Related Manuals for Drolet DB04816

Summary of Contents for Drolet DB04816

  • Page 1 Installation and Operation Manual BISTRO WOOD BURNING COOKSTOVE (DB04816 model) Distributed by My Fireplace Australia PTY Ltd www.myfireplaceaustralia.com.au 20 Auto Way Pakenham, Victoria 3810 AUSTRALIA Phone: 03 59 415 008 Fax: 03 59 415 975 Email: info@myfireplaceaustralia.com.au This manual is available for free download on the distributor’s web site. It is a copyrighted document. Re-sale is strictly prohibited.
