Installation and Operation Manual
HT-2000
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED
WOOD STOVE
Safety tested according to ULC S627,
and UL 1482 Standards
by Intertek Testing Services
www.drolet.ca
Stove Builder International Inc.
250, rue de Copenhague, St-Augustin-de-Desmaures
(Quebec) Canada G3A 2H3
Tel: (418) 878-3040
Fax: (418) 878-3001
This manual is available for free download on the manufacturer's web site. It is a
copyrighted document. Re-sale is strictly prohibited. The manufacturer may update this
manual from time to time and cannot be responsible for problems, injuries, or damages
arising out of the use of information contained in any manual obtained from unauthorized
sources.
READ AND KEEP THIS MANUAL FOR REFERENCE
45060A
Printed in Canada
18-08-2014

Advertisement

Table of Contents
loading

Related Manuals for Drolet HT-2000

Summary of Contents for Drolet HT-2000

  • Page 1 Installation and Operation Manual HT-2000 US ENVIRONMENTAL PROTECTION AGENCY PHASE II CERTIFIED WOOD STOVE Safety tested according to ULC S627, and UL 1482 Standards by Intertek Testing Services www.drolet.ca Stove Builder International Inc. 250, rue de Copenhague, St-Augustin-de-Desmaures (Quebec) Canada G3A 2H3...
  • Page 2 HT-2000 Installation and Operation Manual THANK YOU FOR CHOOSING THIS DROLET WOOD STOVE As one of North America’s largest and most respected wood stove and fireplace manufacturers, Stove Builder International takes pride in the quality and performance of all its products. We want to help you get maximum satisfaction as you use this product.

  • Page 3: Table Of Contents

    HT-2000 Installation and Operation Manual Table of content PART A - OPERATION AND MAINTENANCE ....... 6   Safety Information ..............6     Summary of Operation and Maintenance Cautions and Warnings ......6     HT-2000 Specifications ..................7  ...
  • Page 4 HT-2000 Installation and Operation Manual Maintaining Your Wood Heating System ....... 23     Stove Maintenance ....................23     5.1.1 Plated Finish Maintenance ................23     5.1.2 Cleaning Door Glass ..................23     5.1.3 Door adjustment ....................24  ...
  • Page 5 HT-2000 Installation and Operation Manual Installing the Chimney Connector ................. 41     8.6.1 Installation of Single Wall Chimney Connector ..........42     Appendix 1: Installing the Pedestal ..........44   Appendix 2: Installing Trims ............45   Appendix 3: Installation and Use of Optional Air Circulation Fan (AC02050), and Thermodiscs (AC02055 and AC05530) ..............

  • Page 6: Part A - Operation And Maintenance

    HT-2000 Installation and Operation Manual PART A - OPERATION AND MAINTENANCE Please see Part B for installation instructions. 2 Safety Information 2.2 Summary of Operation and Maintenance Cautions and Warnings • HOT WHILE IN OPERATION, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY.

  • Page 7: Ht-2000 Specifications

    HT-2000 Installation and Operation Manual 2 General Information HT-2000 Specifications Fuel Type Cordwood Test Standards (safety) ULC S627 and UL 1482 Test Standard (emissions) EPA Method 28 (40 CFR Part 60) Heating capacity range* 1,000 to 2,400 sq. ft. (93 to 223 m Maximum heat output** 60, 175 BTU/h (17.64 kW/h)
  • Page 8 HT-2000 Installation and Operation Manual...
  • Page 9 HT-2000 Installation and Operation Manual...

  • Page 10: Zone Heating And How To Make It Work For You

    2.2 Zone Heating and How to Make it Work for You Your new HT-2000 wood stove is a space heater, which means it is intended to heat the area it is installed in, as well as spaces that connect to that area, although to a lower temperature.

  • Page 11: The Sbi Commitment To You And The Environment

    HT-2000 Installation and Operation Manual 2.4 The SBI Commitment to You and the Environment The SBI team is committed to protecting the environment, so we do everything we can to use only materials in our products that will have no lasting negative impact on the environment.

  • Page 12: Fuel

    HT-2000 Installation and Operation Manual 3 Fuel 3.1 Materials That Should Not be Burned  GARBAGE OF ANY KIND,  COAL OR CHARCOAL,  TREATED, PAINTED OR COATED WOOD,  PLYWOOD OR PARTICLE BOARD,  FINE PAPER, COLORED PAPER OR CARDBOARD, ...

  • Page 13: Log Length

    HT-2000 Installation and Operation Manual wouldn’t hold a fire overnight unless they were fed large pieces of hardwood. That is no longer true. You can successfully heat your home by using the less desirable tree species and give the forest a break at the same time.

  • Page 14: How To Dry Firewood

    HT-2000 Installation and Operation Manual Wood should be split to a range of sizes, from about 3” to 6” (75 mm to 150 mm) in cross section. Having a range of sizes makes starting and rekindling fires much easier. Often, the firewood purchased from commercial suppliers is not split finely enough for convenient stoking.

  • Page 15: Judging Firewood Moisture Content

    HT-2000 Installation and Operation Manual 3.2.6 Judging Firewood Moisture Content You can find out if some firewood is dry enough to burn by using these guidelines: cracks form at the ends of logs as they dry • as it dries in the sun, the wood turns from white or cream coloured to grey or yellow, •...

  • Page 16: Operating Your Stove

    HT-2000 Installation and Operation Manual Operating Your Stove 4.1 Your First Fires Two things will happen as you burn your first few fires; the paint cures and the internal components of the stove are conditioned. As the paint cures, some of the chemicals vaporize. The vapors are not poisonous, but they do smell bad.

  • Page 17: The Top Down Fire

    HT-2000 Installation and Operation Manual DO NOT LEAVE THE STOVE UNATTENDED WHEN THE DOOR IS SLIGHTLY OPENED DURING IGNITION. ALWAYS CLOSE THE DOOR AFTER IGNITION. After the kindling fire has mostly burned, you can add standard firewood pieces until you have a fire of the right size for the conditions.

  • Page 18: Ash Removal

    HT-2000 Installation and Operation Manual in temperature throughout the day and night. This is normal, and for experienced wood burners these are advantages of zone heating with wood. Do not expect steady heat output from your stove. It is normal for its surface temperature to rise after a new load of wood is ignited and for its temperature to gradually decline as the fire progresses.

  • Page 19: Raking Charcoal

    HT-2000 Installation and Operation Manual 4.3.3 Raking Charcoal Rekindle the fire when you notice that the room temperature has fallen. You will find most of the remaining charcoal at the back of the firebox, furthest from the door. Rake these coals towards the door before loading.

  • Page 20: Turning Down The Air Supply

    HT-2000 Installation and Operation Manual 4.3.5 Turning Down the Air Supply Once the firewood, firebox and chimney are hot, you can begin to reduce the air supply for a steady burn. As you reduce the air supply to the fire, two important things happen. First, the firing rate slows down to spread the heat energy in the fuel over a longer period of time.

  • Page 21: Building Different Fires For Different Needs

    HT-2000 Installation and Operation Manual 4.3.6 Building Different Fires for Different Needs Using the air control is not the only way to match the stove’s heat output to the heat demand. Your house will need far less heat in October than in January to be kept at a comfortable temperature.
  • Page 22 HT-2000 Installation and Operation Manual 4.3.6.4 Maximum Burn Cycle Times The burn cycle time is the period between loading wood on a coal bed and the consumption of that wood back to a coal bed of the same size. The flaming phase of the fire lasts for roughly the first half of the burn cycle and the second half is the coal bed phase during which there is little or no flame.

  • Page 23: Maintaining Your Wood Heating System

    HT-2000 Installation and Operation Manual 5 Maintaining Your Wood Heating System 5.1 Stove Maintenance Your new stove will give many years of reliable service if you use and maintain it correctly. Some of the internal components of the firebox, such as firebricks, baffles and air tubes, will wear over time under intense heat.

  • Page 24: Door Adjustment

    HT-2000 Installation and Operation Manual 5.1.3 Door adjustment In order for your stove to burn at its best efficiency, the door must provide a perfect seal with the firebox. Therefore, the gasket should be inspected periodically making sure to obtain an air tight fit. Air tightness can be improved with a simple latch mechanism adjustment.

  • Page 25: Replacing The Door Gasket

    HT-2000 Installation and Operation Manual 5.1.4 Replacing the Door Gasket It is important to maintain the gasket in good condition. After a year or more of use, the door gasket will compress and become hard, which may allow air to leak past it. You can test the condition of the door gasket by closing and latching the door on a strip of paper.

  • Page 26: Cleaning And Painting The Stove

    HT-2000 Installation and Operation Manual The gasket must be centred on the edge of the glass. To do this easily, peel back a section of the paper covering the adhesive and place the gasket on a table with the adhesive side up. Stick the end of the gasket to the middle of one edge, then press the edge of the glass down onto the gasket, taking care that it is perfectly centred on the gasket.

  • Page 27: How Often Should You Clean The Chimney

    HT-2000 Installation and Operation Manual more slowly. Your new stove has the right characteristics to help you to burn clean fires with little or no smoke, resulting in less creosote in the chimney. 5.2.2 How Often Should You Clean the Chimney? It is not possible to predict how much or how quickly creosote will form in your chimney.

  • Page 28: Part B - Installation

    HT-2000 Installation and Operation Manual PART B - INSTALLATION 6 Safety Information 6.1 Summary of Installation Cautions and Warnings • THE INFORMATION GIVEN ON THE CERTIFICATION LABEL AFFIXED TO THE APPLIANCE ALWAYS OVERRIDES THE INFORMATION PUBLISHED, IN ANY OTHER MEDIA (OWNER’S MANUAL, CATALOGUES, FLYERS, MAGAZINES AND/OR WEB SITES).

  • Page 29: Regulations Covering Stove Installation

    6.2 Regulations Covering Stove Installation When installed and operated as described in these instructions, the HT-2000 wood stove is suitable for use as a freestanding heater in residential installations. The HT-2000 wood stove is not intended for installation in a sleeping room.

  • Page 30: Clearances To Combustible Material

    HT-2000 Installation and Operation Manual 7 Clearances to Combustible Material The clearances shown in this section have been determined by test according to procedures set out in safety standards ULC S627 (Canada) and UL1482 (U.S.A.). When the stove is installed so that its surfaces are at or beyond the minimum clearances specified, combustible surfaces will not overheat under normal and even abnormal operating conditions.
  • Page 31 HT-2000 Installation and Operation Manual       Clearances to combustible materials and floor protection...

  • Page 32: Floor Protector

    HT-2000 Installation and Operation Manual 7.3 Floor protector Your stove has been conceived to prevent the floor from overheating. However, it must be placed on a noncombustible surface to protect the floor from hot embers that could fall from the stove while loading or cleaning. There are differences between floor protections in Canada and in the United States, as it is illustrated in the table below and on the figure Clearances to combustible materials and floor protection.

  • Page 33: Reducing Wall And Ceiling Clearances Safely

    HT-2000 Installation and Operation Manual 7.4 Reducing Wall and Ceiling Clearances Safely It is often desirable to reduce minimum installation clearances by placing the stove closer to walls so the installation takes up less floor space. You can safely reduce the minimum...
  • Page 34 HT-2000 Installation and Operation Manual Clearances for shield construction...

  • Page 35: Table Of Clearance Reduction Percentages

    HT-2000 Installation and Operation Manual 7.4.2 Table of Clearance Reduction Percentages Clearances may be reduced by these percentages Sides Top % Type of shield and rear % (ceiling) Can/US Can/US min. min. Sheet metal, a minimum of 24 gauge (0.61 mm) in thickness ,...

  • Page 36: The Venting System

    HT-2000 Installation and Operation Manual 8 The Venting System 8.1 General The venting system, made up of the chimney and the connecting pipe between the stove and the chimney, acts as the engine that drives your wood heating system. Even the best stove will not function safely and efficiently as intended if it is not connected to a suitable chimney.

  • Page 37: Factory-Built Metal Chimneys

    HT-2000 Installation and Operation Manual To be suitable, a factory-built metal chimney must comply with UL 103 HT (U.S.A.) or ULC S629 (Canada). 8.2.1 Factory-built Metal Chimneys These are sometimes referred to as ‘high temp’ chimneys because they have the special characteristics to...

  • Page 38: Masonry Chimneys

    HT-2000 Installation and Operation Manual 8.2.2 Masonry Chimneys The stove may also be connected to a masonry chimney, provided chimney complies with the construction rules found in the building code enforced locally. The chimney must have either a clay liner or a suitably listed stainless steel liner.

  • Page 39: The Relationship Between The Chimney And The House

    HT-2000 Installation and Operation Manual 8.4 The Relationship Between the Chimney and the House Because the venting system is the engine that drives the wood heating system, it must have the right characteristics. The signs of bad system design are cold backdrafting when there is no fire in the stove, slow kindling of new fires, and smoke roll-out when the door is opened for loading.

  • Page 40: Why The Chimney Should Penetrate The Highest Heated Space

    HT-2000 Installation and Operation Manual 8.4.2 Why the chimney should penetrate the highest heated space When it is cold outside, the warm air in the house is buoyant so it tends to rise. This tendency of warm air to rise creates a slight pressure difference in the house. Called ‘stack effect’, it produces a slightly negative pressure low in the house (relative to outside) and a...

  • Page 41: Installing The Chimney Connector

    HT-2000 Installation and Operation Manual Some jurisdictions in the United States require that wood stoves have a supply of combustion air from outdoors. If you do install an air supply through the wall of the house, be aware that its pressure can be affected during windy weather. If you notice changes in wood stove performance in windy weather, and in particular if smoke puffs from the stove, you should disconnect the outdoor air duct from the stove and remove the duct.

  • Page 42: Installation Of Single Wall Chimney Connector

    HT-2000 Installation and Operation Manual 8.6.1 Installation of Single Wall Chimney Connector The chimney connector assembly has been called ‘the weak link’ in the safety of wood heating systems because failure to install the connector properly (which has been common in the past) can result in house fires.
  • Page 43 HT-2000 Installation and Operation Manual The rules below are based on those found in the CSA B365 installation code. Please carefully follow these installation instruction rules, or those enforced where you live. Maximum overall length of straight pipe: 3 m (10 ft.) including elbows.

  • Page 44: Appendix 1: Installing The Pedestal

    HT-2000 Installation and Operation Manual Appendix 1: Installing the Pedestal The pedestal kit must be assembled to the firebox before positioning the stove. See installation instructions below: 1- Slide the pedestal surrounding (A) toward the back of the stove base and join it to the pedestal back surrounding (B).

  • Page 45: Appendix 2: Installing Trims

    HT-2000 Installation and Operation Manual Appendix 2: Installing Trims Your freestanding Drolet wood stove is equipped with decorative u-shaped trims. See installation instructions below: 1- Using a Phillips screwdriver, install decorative upper trims (A) & (B) by fastening screws (C) on both side of each trim.
  • Page 46 HT-2000 Installation and Operation Manual 3- Press the ashtray trim (F) on the upper edge of ashtray lip.

  • Page 47: Appendix 3: Installation And Use Of Optional Air Circulation Fan (Ac02050), And Thermodiscs (Ac02055 And Ac05530)

    You can purchase this option through your DROLET dealer. Make sure to specify this part number: # AC02050.
  • Page 48 HT-2000 Installation and Operation Manual When using the optional fan, allow the stove to reach operating temperature (approximately one hour), before turning it on. The increased airflow from the fan cools the firebox and could affect the start-up combustion efficiency if the fan is turned on too early.

  • Page 49: Appendix 4: Installation Of Secondary Air Tubes

    HT-2000 Installation and Operation Manual Appendix 4: Installation of Secondary Air Tubes 1-Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the rear left channel.

  • Page 50: Appendix 5: Baffle Installation

    HT-2000 Installation and Operation Manual Appendix 5: Baffle Installation 1- Remove the front secondary air tube (A) and its cotter pin (B) and the three first bricks (C) on the right side of the combustion chamber. 2- Pile up one insulation blanket (E) and an insulation weight (F) upon one baffle board (D).
  • Page 51 HT-2000 Installation and Operation Manual Note that secondary air tubes can be replaced without removing the baffle board. Important Notes: The air tubes are identified for placement as follows: Model Type of tube HT-2000 Front ► 28 holes of 0.203"...

  • Page 52: Appendix 6: Exploded Diagram And Parts List

    HT-2000 Installation and Operation Manual Appendix 6: Exploded Diagram and Parts List...
  • Page 53 HT-2000 Installation and Operation Manual IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your stove, please provide the model number and the serial number. We reserve the right to change parts due to technology upgrade or availability. Contact an authorized dealer to obtain any of these parts.
  • Page 54 HT-2000 Installation and Operation Manual Item Description 30075 BRASS METAL SCREW #6 X 1/2" QUADREX 30142 NICKEL METAL SCREW #6 X 1/2" QUADREX PL07727-01 GOLD PLATED AIR OUTLET DECORATIVE GRILL PL07729 AIR OUTLET DECORATIVE GRILL BRUSHED NICKEL SE02000-02 ASH DUMP COVER PL36049 4 1/2"...

  • Page 55: Drolet Limited Lifetime Warranty

    Firebrick *Pictures required Shall your unit or a components be defective, contact immediately your DROLET dealer. Prior to your call make sure you have the following information necessary to your warranty claim treatment: ...
