PACKAGE CONTENTS
PART
DESCRIPTION
A
Fixture Body
B
Cage
C
Glass Panel
(Pre-assembled to Cage)
Crossbar Assembly
AA
Wire Connector
BB
CC
Outlet Box Screw
Mounting Screw
DD
EE
Lock Screw
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-800-645-3184,
Monday -
Friday
QUANTITY
1 pc
1 pc
4 pcs
1 pc
3 pcs
2 pcs
4 pcs
2 pcs
, 7:00 a.m. - 4:00 p.m., CST.
SKU NUMBER: 356-3411
MODEL NUMBER: MND2523C
AA
Stock Part#
N/A
BB
CC
G13564PA
DD
EE
913569KIT
1
WALL LANTERN
REVISED 2017-06-23
