- Page 1 INSTRUCTION MANUAL DM-810A • DM-820A DM-830A • DML-430A Digital Multimeters 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com 52047799 REV 4 © 2016 Greenlee Textron Inc. 6/16...
-
Page 2: Purpose Of This Manual
Description The Greenlee DM-810A, DM-820A, DM-830A, and DML-430A Digital Multimeters are hand-held testing devices with the following measurement capabilities: AC and DC voltage, AC and DC current, frequency, resistance, capacitance, and duty cycle of logic level signals. They also check diodes and verify continuity. -
Page 3: Important Safety Information
Electric shock hazard: Contact with live circuits could result in severe injury or death. All specifications are nominal and may change as design improvements occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. - Page 4 Important Safety Information Electric shock and fire hazard: • Do not expose this unit to rain or moisture. • Do not use the unit if it is wet or damaged. • Only use the test leads provided with the equipment or UL Listed Probe Assembly with same rating or better.
- Page 5 DM-810A • DM-820A • DM-830A • DML-430A Important Safety Information Electric shock hazard: • Unless measuring voltage, current, or frequency, shut off and lock out power. Make sure that all capacitors are discharged. Voltage must not be present. • Set the selector and connect the test leads so that they correspond to the intended measurement. Incorrect settings or connections can result in a blown fuse.
-
Page 6: Symbols On The Unit
Identification 1. Display LCD and bar graph 2. Feature Buttons Refer to explanations under “Using the Features” 3. Selector Selects a function or turns power OFF 4. A Positive input terminal for high current measurements 5. mA µA Positive input terminal for low current measurements 6. -
Page 7: Display Icons
DM-810A • DM-820A • DM-830A • DML-430A Display Icons Primary Display 33. µ Micro (10 34. S Siemen Bar graph element 35. F 9. – Farad Polarity indicator for bar graph 36. D% Duty cycle function is enabled. Bar graph scale 37. -
Page 8: Using The Features
Using the Features All Models • Dual Digital Display: These meters can display two measurements, such as AC voltage and frequency, at the same time. Display combinations are shown using large symbols to indicate the measurement on the primary display and small, raised symbols to indicate the measurement on the secondary display. - Page 9 DM-810A • DM-820A • DM-830A • DML-430A Using the Features (cont’d) Note: When using the REC function, pressing RANGE will cause the meter to exit this mode. DM-820A and DM-830A Only • EF: Set the meter to any current or voltage function. Press and hold until the meter displays “EF” to detect the electric field that surrounds current-carrying conductors.
- Page 10 AC Measurement AC measurements are usually displayed as RMS (root mean square) values. The RMS value is equal to the value of a DC waveform, which would deliver the same power if it replaced the time-varying wave- form. Two AC measurement methods are average-responding RMS calibrated and true RMS-reading. The average-responding RMS calibrated method takes the average value of the input signal after full wave rectification, multiplies it by 1.11, and displays the result.
- Page 11 DM-810A • DM-820A • DM-830A • DML-430A Data Storage Function (DML-430A only) The DML-430A has data storage and retrieval capability. It can store up to 87,000 measurements in single display mode or 43,000 measurements in dual display mode. The data can later be reviewed on the multimeter’s display, or downloaded the data to a computer using the optional interface DMSC-9U.
- Page 12 Data Storage Function (DML-430A only) (cont’d) To stop recording data: While the meter is logging data, press the button for more than 1 second. To review stored data: Press p and q momentarily to enter Recall mode. The last session number displays for 0.5 seconds and then displays the last logged data item as well the annunciators.
- Page 13 DM-810A • DM-820A • DM-830A • DML-430A Using the Optional Software These meters are compatible with Greenlee DMSC-9U, an optically isolated computer interface cable ® and software. It allows measurements to be logged to a personal computer using the Microsoft ®...
-
Page 14: Operation
Operation Electric shock hazard: Contact with live circuits could result in severe injury or death. 1. Refer to the Settings Table. Set the selector to the proper setting, press SELECT (when instructed to do so), and connect the test leads to the meter. 2. - Page 15 DM-810A • DM-820A • DM-830A • DML-430A Operation (cont’d) Settings Table (cont’d) Press SELECT until Connect Connect the To measure this Set the selector to these icons appear on the red black lead characteristic … this symbol … the display … lead to …...
- Page 16 Operation (cont’d) Settings Table (cont’d) Press SELECT until Connect Connect the To measure this Set the selector to these icons appear the red black lead characteristic … this symbol … on the display … lead to … to … DM-830A and DML-430A Only Voltage—AC + DC ΩV True RMS (1000 V max)
-
Page 17: Typical Measurements
DM-810A • DM-820A • DM-830A • DML-430A Typical Measurements Voltage Measurement Current Measurement... - Page 18 Typical Measurements Resistance Measurement Continuity Check Capacitance Measurement Diode Measurement Reverse Bias Forward Bias...
- Page 19 DM-810A • DM-820A • DM-830A • DML-430A Typical Measurements Temperature Electric Field Detection (EF) Refer to “Using the Features” for complete instructions. A–Non-contact B–Contact...
- Page 20 Accuracy Refer to the “Specifications” section for operating conditions and temperature coefficient. Accuracy is specified as follows: ± (a percentage of the reading + a fixed amount) at 23 °C ± 5 °C (73.4 °F ± 9 °F), 0% to 75% relative humidity. True RMS Readings: Voltage and current accuracies are specified from 10% to 100% of the range unless otherwise specified.
- Page 21 DM-810A • DM-820A • DM-830A • DML-430A Accuracy (cont’d) Resistance and Conductance (Conductance on DM-820A, DM-830A, and DML-430A Only) Range Accuracy Typical Open Circuit Voltage 600.0 Ω ± (0.1% + 0.3 Ω) 6.000 kΩ ± (0.1% + 0.003 kΩ) 60.00 kΩ ±...
- Page 22 Accuracy (cont’d) AC Current (AC + DC Current on DM-830A and DML-430A Only) Accuracy at Accuracy at Burden Voltage (typical) Range 50 to 60 Hz 40 to 1 kHz (all frequency ranges) 600.0 µA ± (0.6% + 0.3 µA) ± (0.8% + 0.4 µA) 0.08 mV/µA 6000 µA ±...
- Page 23 DM-810A • DM-820A • DM-830A • DML-430A Accuracy (cont’d) Accuracy for Frequency Ranges Display Range Accuracy 99.99 Hz ± (0.04% + 0.04 Hz) 999.9 Hz ± ( 0.04% + 0.4 Hz) 9.999 kHz ± ( 0.04% + 0.004 kHz) Frequency—Logic Level % Duty Cycle Range: 5.00 Hz to 1.000 MHz Range: 0.00% to 100.0 %...
- Page 24 Accuracy (cont’d) DM-830A and DML-430A Only DC Voltage AutoCheck™ Mode Range Accuracy 9.999 V ± (0.5% + 0.003 V) 99.99 V ± (0.5% + 0.03 V) 999.9 V ± (0.5% + 0.3 V) Input Impedance: Initial 3.0 kΩ // 165 pF typical at voltages up to 50 V; increases with voltage to approximately 500 kΩ...
-
Page 25: Specifications
DM-810A • DM-820A • DM-830A • DML-430A Specifications Display: 9999 counts: ACV, DCV, Hz, and nS 6000 counts: mV, µA, mA, A, ohm, and capacitance Polarity: Automatic Sampling Rate: Numeric Display: 5 per second 41-Segment Bar Graph Display: 60 per second Temperature Coefficient: Nominal 0.15 x (specified accuracy) per °C below 18 °C or above 28 °C Automatic Power Off: After 30 minutes of inactivity. -
Page 26: Measurement Categories
Statement of Conformity Greenlee Textron Inc. is certified in accordance with ISO 9001:2008 for our Quality Management Systems. The instrument enclosed has been checked and/or calibrated using equipment that is traceable to the... -
Page 27: Maintenance
DM-810A • DM-820A • DM-830A • DML-430A Maintenance Electric shock hazard: Before opening the case, remove the test leads from the circuit and shut off the unit. Failure to observe these warnings could result in severe injury or death. Electric shock hazard: The fuses are an integral part of the overvoltage protection.
