Table of Contents Brief introduction ........................1 Important safety instructions ....................2 Installing your new appliance ....................4 Description of the appliance ....................9 Display controls ........................10 Using your appliance ......................12 Cleaning and care ....................... 14 Helpful hints and tips ......................
Important Safety Instructions General safety and daily use Don’t place items on top of the appliance as this could cause injury should they fall off. It is important to use your appliance safely. We recommend that you follow the Never allow children to play with the guidelines below.
Page 4
If the fitted plug is not suitable for your To avoid eye injury, do not look directly socket outlets, it should be cut off and into the LED light located in the refrigerator carefully disposed of. To avoid a compartment. If it is not functioning possible shock hazard, do not insert the correctly, consult a qualified, registered discarded plug into a socket.
Installing Your New Appliance Before using the appliance for the first time, you should be informed of the following tips. WARNING For proper installation, this refrigerator must be placed on a level surface of hard material that is the same height as the rest of the flooring.
Page 6
Adjusting Door Height and Door Gap The height of a door can be adjusted using the provided Snap Rings. Tools you will need: Snap Ring (4pcs) Wrench(Not provided) To adjust the Height of Door 1. Check the height difference between the doors and then lift and hold the lowest door to be even with the other.
Page 7
Leveling of appliance Door Removal For sufficient leveling and air circulating In case your home access door is too in the lower rear section of the narrow for the refrigerator to pass appliance, the bottom feet may need through, remove the refrigerator doors to be adjusted.
Page 8
Installing the water lines Connecting to the water supply line First, shut off the main water supply. An automatic ice maker is a very useful feature in your new refrigerator. Please follow the below instructions carefully for correct installation. In order for the ice maker to operate properly, a water line is required.
Page 9
5. Connect the extension tubing line with Thread a 1/4 " compression nut and ferrule the line on the back of the fridge via (sleeve) onto the free end and of 1/4" the coupler. Fully insert the extension water line. tubing into the coupler, and then insert Insert the free and of the 1/4"...
Display Controls Your product has one control panel which is installed on the top of refrigerator inside. Use your appliance according to the following control guidelines. My Fresh Choice Compartment Temperature Setting Compartment Temperatures 1. Press “ZONE” button repeatedly until When you set a temperature, you are the My Fresh Choice icon appears.
Page 12
The Super Cool feature helps to keep food The ice maker is located inside the freezer stored in the refrigerator at the set compartment, near the top of the temperature during periods of high usage, compartment. When the ice maker makes large grocery loads, or temporarily warm ice, the ice is stored in freezer tray.
Door Open Alarm lf a door is open for longer than 2 minutes, an alarm will sound to alert you and the control panel will display "dr". The alarm will sound 3 times To switch off demo mode, press and hold every minute for 8 minutes.
Page 14
Door Bins Automatic Ice maker The refrigerator compartment is provided with six door bins, which are suitable for the storage of canned liquid, bottled drinks and packaged food. To remove the door, simply lift the racks up and pull straight out. To relocate the door , slide it in above the desired location and push down until it stops.
Cleaning and Care For hygienic reasons the appliance completely dry before replacing the (including exterior and interior shelves and baskets. Thoroughly dry all accessories) should be cleaned at least surfaces and removable parts before once every two months. putting them back into place. WARNING! To avoid electrical shock, the appliance must not be connected...
Door seal cleaning CAUTION! Take care to keep the door seals Only after the door seals are clean. Sticky food and drinks can completely dry should the cause seals to stick to the cabinet appliance be powered on. and tear when you open the door. Wash seal with a mild detergent and Replacing the LED light warm water.
Page 17
Hints for refrigeration For Meat: (all types) wrap in cling wrap It is recommended to label and date and place on the glass shelf above the each frozen package in order to keep vegetable drawer. Always follow food track of the storage time. storage times and use by dates suggested by manufacturers.
Troubleshooting If you experience a problem with your appliance or are concerned that the appliance is not functioning correctly, you can carry out some easy checks before calling for service, please see below. WARNING 1.Don’t try to repair the appliance yourself. If the problem persists after you have made the checks mentioned below, contact a qualified electrician, authorized service technician or the shop where you purchased the product.
Page 19
It is normal to frequently hear the sound of the motor. It will need to run more in the following circumstances: The temperature is set colder than necessary. A large quantity of warm food has recently been The motor runs stored within the appliance.
Disposal of the Appliance DANGER It is prohibited to dispose of this appliance as household waste. Packaging materials Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into a suitable waste collection container to recycle it. Before disposal of the appliance 1.
