Related Manuals for Hisense RF793N4SASE
Summary of Contents for Hisense RF793N4SASE
- Page 1 USER’S OPERATION MANUAL Before operating this unit, please read this manual thoroughly, and retain for future reference English...
-
Page 2: Table Of Contents
Thank you for choosing Hisense. We are sure you will find your new refrigerator a pleasure to use. However, before you use the appliance, we recommend that you carefully read the instructions, which provide details about installing and using the product. - Page 4 Safety for children and others who are vulnerable people ► According to EN standard This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 5 WARNING Connect to potable water supply only.
- Page 6 — ► WARNING Do not locate multiple portable socketoutlets or portable power supplies at the rear of the appliance. Replacing the LED — ► WARNING The LED light must not be replaced by the user! If the LED light is damaged, contact the customer helpline for assistance.
- Page 7 Elect ical safety 『 ► The power cord must not be lengthened. ► Make sure that the power plug is not crushed or damaged. A crushed or damaged power plug may overheat and cause a fire. ► Make sure that you can access the main plug of the appliance.
- Page 8 ► Do not place food products directly against the air outlet on the rear wall. ► Store pre-packed frozen food in accordance with the frozen food manufacture's instructions. ► The appliances manufactures storage recommendations should be strictly adhered to.Refer to relevant instructions for storage. ►...
- Page 9 ► WARNING- Food needs to be packed into bags before it is put into the refrigerator. Liquids need to be stored in bo廿les or capped containers in order to avoid a spill, as the design structure of the product is not easy to clean.
- Page 10 Warning! To avoid a hazard due to instability of the appliance, it must be installed in accordance with the instructions.The incorporated ice-maker can only be installed by the manufacturer and can not be changed by the user.The appliance is intended to be permanently connected to the water mains and not connected by a detachable hose-set.
-
Page 11: Parts And Features
Proper Disposal of Your Old Refrigerator Before You Throw Away Your Old Refrigerator or Freezer: Take off the doors. Leave the shelves in place so that children may not easily climb inside. Suffocation Hazard Remove doors from your old refrigerator. Important information to know about disposal Failure to do so can result in death or brain damage. -
Page 12: Location Requirements
Recommender Clearances Location Requirements Risk of fire/ flammable materials Keep flammable materials and vapors,such as gasoline,away from appliance. Failure to do so can result in death,explosion or fire. Temperature Exterior and Dimensions Electrical Shock Hazard Plug into a grounder 3 prong outlet. Do not remove the ground prong from the power cord plug. -
Page 13: Unpack The Refrigerator
Unpack the Refrigerator Door Removal (only if needed) - Page 14 Remove the Doors 5. Use your both hands to open the door more IMPORTANT: Keep the refrigerator doors closed than 90'. Lift it up and take it off. until you are ready to lift them from the cabinet. 1. Unplug refrigerator or disconnect power. 2.
-
Page 15: Installing The Water Lines
Installing the water lines A water dispenser with a filter is one of the helpful features on your new appliance. To help promote better health, the water filter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms. -
Page 16: Level Refrigerator
Level Refrigerator if needed 2mm to 5mm coming out from the appliance when you Adjustable foot Roller Roller small gasket 2 pcs big gasket 2 pcs... - Page 17 908mm 1471.4mm...
- Page 18 turn When the Child Lock is off, you can touch the " °F/ °C " button to switch between Celsius and Fahrenheit units. When it is switched to Fahrenheit, the icon " " will be on. More detail about"Wi-Fi Hold 3 sec",please read page 20.
- Page 19 If you have set the temperature type to Fahrenheit, the temperature settings cycle from 46°F to 36°F. "Eco" button,"Eco" function will be activated,and 46°F 44°F 45°F "Super Freezer" mode will be off. 38°F 36°F 37°F When the Child Lock is on,the dispenser will not work.When the Child Lock is off,you can press the displays 2°C(or 36°F).Super Cool automatically “Cubed”or “Crushed”...
- Page 20 Wi-Fi function CONNECT APPLIANCE TO Wi-Fi This appliance may be controlled remotely with After activating the Wi-Fi function, connect your a smart phone or a tablet computer. If the device to your home router in order to appliance is not connected to the home connect your appliance with the ConnectLife network, it will function like a regular appliance.
- Page 21 UNBIND ALL PAIR APPLIANCE By activating this function, the appliance will be removed from all paired app user accounts. Step 1: Set the appliance to normal operation. Touch the Wi-Fi icon for approximately 3 seconds. You entered network connection menu when ' -- ' appears in the display.
- Page 22 shelf is ① ② 1. Pull out the freezer door and the upper freezer drawer to the final position. 2. Unscrew the drawer before taking it out. 3. Take out the upper freezer drawer by lifting it up from the rail system. The refrigerator compartment is also provided with a foldable shelf.
- Page 23 When the user wants to disconnect the switch, please take out the ice from the ice nox first. First, open the door at the maximum Angle...
- Page 24 5.Using your fridge compartment To remove the door baskets(A ),simply lift the To relocate the door baskets(A ),slide it in above To remove the door baskets(A ),take the right side To relocate the door baskets(A ),slide it into the...
- Page 25 6.Changing the water filter 3. Insert the new filter into the filter holder. To drink the freshest and cleanest water from your refrigerator, change the filter on time. To change the water filter, follow these steps: 1.Shut off the water supply. Pull out the cover (B) about 1.5 cm and open.
- Page 26 Be sure to flush the dispenser thoroughly, otherwise water may drip from the dispenser. This means that there is still air in the line. Do not dispense the entire 2.5 gallon amount continuously. Depress and release the dispenser pad for cycles of 30 seconds ON and 60 seconds OFF.
- Page 27 This product contains a light source of energy efficiency class G on the top and side of the refrigerating chamber.
- Page 29 Problem Possible Cause & Solution Check whether the power cord is plugged into the power outlet properly. Check the fuse or circuit of your power supply, replace if necessary. Appliance is not working The room temperature may be too low. Try setting the refrigerator or correctly freezer temperature to a colder level to solve this problem.
-
Page 30: Cleaning
Is the water tank frozen because the refrigerator temperature is too low? Try selecting a warmer setting on the display panel. • Check if the filter is properly installed. If it is not properly installed, the water dispenser may not work. Hisense Service Help Line:0191 387 0804... - Page 31 Hisense life reimogined Hisense UK Ltd Ground floor Munroe Court White Rose Office Park Millshaw Park Lane Leeds LS11 0EA...
Need help?
Do you have a question about the RF793N4SASE and is the answer not in the manual?
Questions and answers
Where is the water filter situated? Do I need to access rear of fridge to replace?
The user manual does not specify the exact location of the water filter on the Hisense RF793N4SASE refrigerator. However, it mentions accessing the water filter from the front by opening the refrigerator door. There is no indication that accessing the rear of the unit is required for replacement.
This answer is automatically generated
