Evaluation Using the MUX36D04EVM-PDK
3
Evaluation Using the MUX36D04EVM-PDK
All parameters listed in the specifications table of the MUX36D04 data sheet can be tested on the
MUX36D04EVM-PDK.
3.1
Channel Selection Logic
Table 4
provides the truth table for the selection logic for the MUX36D04. This behavior of the device can
be evaluated by driving the digital selection signal listed in
EN
0
1
1
1
1
(1)
X denotes don't care..
3.2
Key Specifications
The MUX36D04 datasheet contains detailed information of the test setups for each of the mux
parameters. The MUX36D04EVM-PDK can be used to validate these parameters as per the test
procedures described in the data sheet.
6
MUX36D04EVM-PDK
Table 4. Channel Selection Truth Table
A1
A0
(1)
(1)
X
X
0
0
0
1
1
0
1
1
Copyright © 2016, Texas Instruments Incorporated
Section 2.2
to the appropriate levels.
On channel
All channels are off
Channel 1
Channel 2
Channel 3
Channel 4
SBAU255A – January 2016 – Revised March 2016
