- Page 1 Network Video Recorder Installation Manual DR-2504P DR-2504P-A DR-2504P-B DR-2504P-C DR-2508P DR-2508P-A DR-2516P DR-2516P-A Powered by...
- Page 2 Before reading this manual This manual contains basic instructions on installing and using DirectIP Network Video Recorder, an IDIS product. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual Important Safeguards 1. Read Instructions All the safety and operating instructions should be 15. Replacement Parts When replacement parts are required, be sure the read before the appliance is operated. service technician has used replacement parts specified by the manufacturer 2.
- Page 4 Before reading this manual In-Text Symbol Type Description Caution Important information concerning a specific function. Note Useful information concerning a specific function. User’s Caution Statement Caution: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
- Page 5 IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice.
-
Page 6: Table Of Contents
Table of Contents Part 1 – Introduction ......... 7 Product Features . -
Page 7: Part 1 - Introduction
Part 1 – Introduction Product Features This is a DirectIP-enabled video recorder that supports surveillance, recording, and playback of video from network cameras (or video encoders). This NVR (Network Video Recorder) unit offers the following features: • Real-time 4/8/16-channel DirectIP network surveillance •... -
Page 8: Accessories
Part 1 – Introduction Accessories Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included. Power Cable / DC Adapter(12V, 48V or 54V ) Network Video Recorder Quick Guide *Above image may differ slightly from the actual product. -
Page 9: Overview
Part 1 – Introduction Overview Front Panel USB Ports LEDs • Remote control sensor is located on the bottom center of the front panel. Ensure that the sensor remains unobstructed at all times. If obstructed, the sensor might not be able to receive remote control signals. •... - Page 10 Part 1 – Introduction Connections on the Front Panel Flash Memory Mouse USB HDD IR Remote Control...
-
Page 11: Dimensions
Part 1 – Introduction Dimensions (Unit - mm) -
Page 12: Rear Panel
Part 1 – Introduction Rear Panel DR-2504P[-A/B/C/] Audio Out Port VGA Out Port HDMI Out Port eSATA Port Power In Port (48V) Video In / PoE Ports Network Port Alarm Connection Ports RS-232 Port Power In Port (12V) DR-2508P/DR-2516P CAUTION ALARM IN ALARM OUT Audio Out Port... - Page 13 Part 1 – Introduction DR-2508P-A/DR-2516P-A Audio Out Port VGA Out Port HDMI Out Port eSATA Port Video In / PoE Ports Network Port Video In / Ext. Port Alarm Connection Ports RS-232 Port Power In Port (12V) Power In Port (54V)
-
Page 14: Rear Panel Connections
Part 1 – Introduction Rear Panel Connections • For the external hub, we recommend using an Ext. port to enable functions such as camera alignment. • Green LED on the right will turn on when PoE comes on line. Orange LED on the left will then flash once a For simplicity, the illustrations and descriptions in the link has been established. - Page 15 Part 1 – Introduction operate and upgrade the NVR remotely over a network. • NO (Relay Alarm Outputs) Fore more information on ethernet connection setup, This NVR is capable of activating/deactivating buzzers, refer to Network Setup in the operation manual. lights, and other external devices.
- Page 16 Part 1 – Introduction Connections on the Rear Panel (DR-2508P/DR-2516P) eSATA Storage Device Speaker VGA Monitor Camera DirectIP Gigabit PoE Switch HDMI Monitor Camera Alarm Network Sensor IDIS Center Power (48V) Remote Monitoring Power (12V) Keyboard...
-
Page 17: Remote Control (Optional)
Part 1 – Introduction Remote Control (Optional) ID Button PANIC Button Camera Buttons STATUS Button LAYOUT Button PTZ Control Buttons REGISTER MODE Button THUMBNAIL Button CALENDAR Button KEYLOCK Button SETUP Button FREEZE Button LOG Button Enter Button Arrow Buttons ALARM Button SEQUENCE Button &... - Page 18 Part 1 – Introduction 1 ID Button 8 THUMBNAIL Button Used to assign remote control ID values. Used in Playback mode to access Thumbnail Search mode. Thumbnail Search mode displays thumbnails No additional remote control assignment is of video recordings and allows you to search necessary if the system's ID is 0.
- Page 19 Part 1 – Introduction * ZOOM Button d BOOKMARK Button Used to zoom in on a specific part of the screen. Once Adds a bookmark to the current playback position in zoomed in, use the arrow buttons to pan around. search mode.
-
Page 20: Part 2 - Appendix
Part 2 - Appendix System Log Types Boot Up Panic On System Shutdown Panic Off Restart Clear All Data Upgrade Success Clear Disk Upgrade Error Format Disk Power Failure Disk Full Time Changed Auto Deletion Time Zone Change Search Begin Time Sync. -
Page 21: Error Code Types
Part 2 - Appendix Error Code Types Upgrade Error Codes Type Type Unknown Error Remote Network Error Incorrect File Version No Remote Upgrade Permission Incorrect OS Version Remote Upgrade File Save Failure Incorrect Software Version Remote Upgrade Cancelled by User Incorrect Kernel Version USB Storage Device Mount Failure Storage Device Mount Failure... - Page 22 Part 2 - Appendix Clip Copy Error Codes Type Type Unknown Error Disk Error Device Error Clip Player Execution File Not Found Device Connection Failure Clip Player Execution File Access Failure CD Media Not Found Clip Player Execution File Save Failure Incorrect Media Image Generation Failure File Name Taken...
- Page 23 Part 2 - Appendix Network Error Codes Type Type Cause of Failure Unknown Connection Cancelled by User Normal Logout No Response from Network Device Host All Channels in Use - Connection Denied High Network Noise Level Incorrect Product Version Info Transmission Queue Full Incorrect User Name or Password Incorrect OEM Info...
-
Page 24: Troubleshooting
Part 2 - Appendix Troubleshooting Problem Solution • Check the power cable connection status. The main unit won't turn on. • Check the power outlet. • Check the camera's video cable connection status. • Check the monitor's video cable connection status. Unable to display Live video. -
Page 25: Specifications
PoE(IEEE 802.3at class 4) supported 8 ports, 100W Camera Power DR-2504P/DR-2504P-A PoE(IEEE 802.3at class 4) supported 4 ports, 30W DR-2504P-B/DR-2504P-C PoE(IEEE 802.3at class 4) supported 4 ports, 50W Email (attach clip (.cbf ) .MP4), Callback to Remote S/W, Push notification (IDIS Event Notification Mobile) - Page 26 NVR Adaptor (Input : 100-240V~, 50/60Hz, 1.5A, Output : 12V , 5A) PSE Adaptor (Input : 100-240V~, 50/60Hz, 1.2A, Output : 48V , 1A) DR-2504P-B/DR-2504P-C NVR Adaptor (Input : 100-240V~, 50/60Hz, 1.5A, Output : 12V , 5A) PSE Adaptor (Input : 100-240V~, 50/60Hz, 1.5A, Output : 48V , 1.35A)
- Page 27 NVR: 12V , 2.2A, 26.4W PSE: 54V , 1.85A, 100W MAX Power Consumption DR-2504P/DR-2504P-A NVR: 12V , 2.2A, 26.4W PSE: 48V , 0.64A, 30.72W MAX DR-2504P-B/DR-2504P-C NVR: 12V , 2.2A, 26.4W PSE: 48V , 1.04A, 50W MAX Approvals FCC, CE V8.5...
- Page 28 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
