  • Page 1 Network Video Recorder Quick Guide DR-2204P DR-2208P DR-2216P Powered by...

  • Page 2: Safety Precautions

    Safety Precautions Important Safeguards 14. Damage requiring Service Unplug this equipment from the wall outlet and refer servicing to qualified 1. Read Instructions service personnel under the following conditions: All the safety and operating instructions should be read before the A.

  • Page 3: Fcc Compliance Statement

    IDIS Co., Ltd. reserves all rights concerning this document. Use or duplication of this document in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this document are subject to change without prior notice for reasons such as functionality enhancements.

  • Page 4: Front Panel

    Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included. Item DR-2100P Series Power Cable / DC Adapter (12V, 48V) Quick Guide Manual and IDIS Center Program CD Optical USB Mouse IR Remote Control Assembly Screws for Adding Hard Disk Drives SATA2 Cables...

  • Page 5: Connections On The Rear Panel

    Connections on the Rear Panel eSATA Storage Device Speaker VGA Monitor Camera DirectIP™ Gigabit PoE Switch HDMI Monitor Camera Alarm Network Sensor IDIS Center Power (48V) Remote Monitoring Keyboard Power (12V)

  • Page 6: Remote Control

    Remote Control ID Button Panic Button Camera Buttons Status Button Layout Button PTZ Control Buttons Register Mode Button Thumbnail Button Calendar Button Keylock Button Setup Button Freeze Button Log Button Enter Button Arrow Buttons Alarm Button Sequence Button Zoom Button &...

  • Page 7: Camera Registration

    Camera Registration ● Record Video Quality Setup Once Network Setup Wizard is complete, the system will Higher recording quality automatically enter Camera Registration mode and scan for uses up more disk space. cameras connected to the NVR. ● Finish the Quick Setup Wizard Network Setup Wizard After exiting from Quick Wizard, the network with Network Wizard will start automatically.

  • Page 8: Apply/Cancel Buttons

    – Mode: Select the scan mode. Video Display Area – Advanced Setup: If the camera is networked but not scanned, use this setup. This setup allows you Left-click on the video display area to toggle between split to change the network setting of the NVR’s VIDEO screen and single screen modes.

  • Page 9: Basic Feature

    Basic Feature Login Configuring the NVR's settings and accessing its searching and other functions require an authorized user login. Live Mode Bring up the Live menu and either press the Setup button on the remote control or click on (Log in) Once Camera Registration is complete, the system will enter using the mouse.

  • Page 10: Audio Recording

    FEN server upon login) remote control. Contact your network administrator for the IP address of the NVR you wish to connect to and the IDIS Web All Channel Playback port number. Press the Menu button while in Live mode.

  • Page 11: System Requirements

    Intel CoreTM i5-2550 3.30GHz Intel CoreTM 2 Duo E7200 or better 2.53GHz or better When IDIS Center software is installed, IDIS Center and IDIS 2GB or more 1.5GB or more Center Run as administrator shortcut icons will be created ATI RadeonTM HD 3650 or ATI RadeonTM HD 2400 or on the desktop.

  • Page 12: Device Registration

    OK for remote access. menu. Device Registration To use the functions provided by IDIS Center, you must first register a device and add the device to a device group. Select System > IDIS Center Setup > Device in the menu at the top of the screen.

  • Page 13: Live Video Mode

    Sites panel. Modify Device Group window will appear. You can modify the selected device group In Play Store (Google Play), enter IDIS Mobile in the from this window. search field. Install IDIS Mobile program and open it.

  • Page 14: Specifications

    Operating Humidity 0% – 90% NVR Adaptor : INPUT Open the App Store on your device. (100-240V~,50/60Hz,1.5A), Enter IDIS Mobile in the search filed of the App Store. OUTPUT (12V , 5A) Power PSE Adaptor : INPUT Install IDIS Mobile program and open it.
  • Page 15 Network Audio In Audio Out 1 line Audio Out, RCA Text In POS Interface, ATM Interface Connector Ethernet: 4/9/9 ports Video In (DR-2204P/2208P/2216P) Ethernet: 4/8/8 ports Camera Power Out (DR-2204P/2208P/2216P) HDMI: 1 HDMI Monitor Out VGA: 1 DB15 Audio Out...
  • Page 16 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
