  • Page 1 Network Video Recorder Installation Manual DR-2304P(-A) DR-2404P(-A) DR-2308P(-A) DR-2316P(-A) Powered by...
  • Page 2 Before reading this manual This manual contains basic instructions on installing and using DirectIP™ Network Video Recorder, an IDIS product. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Before reading this manual Important Safeguards 1. Read Instructions A. When the power-supply cord or the plug has been damaged. All the safety and operating instructions should be read before the appliance B. If liquid is spilled, or objects have fallen into the equipment. is operated.
  • Page 4 Before reading this manual In-Text Symbol Type Description Caution Important information concerning a specific function. Note Useful information concerning a specific function. User’s Caution Statement Caution: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
  • Page 5 IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice.
  • Page 6: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 7 Product Features .
  • Page 7: Part 1 - Introduction

    Part 1 – Introduction Product Features This is a DirectIP-enabled video recorder that supports surveillance, recording, and playback of video from network cameras (or video encoders). This NVR (Network Video Recorder) unit offers the following features: • Real-time 4/8/16-channel DirectIP network surveillance •...
  • Page 8: Accessories

    Part 1 – Introduction Accessories Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included. Network Video Recorder Power Cable / DC Adapter(12V, 48V) Quick Guide SATA2 cables Optical USB Mouse IR Remote Control (Optional) Assembly Screws for Adding Hard Disk Drives...
  • Page 9: Overview

    Part 1 – Introduction Overview Front Panel USB Ports LEDs • Remote control sensor is located on the bottom center of the front panel. Ensure that the sensor remains unobstructed at all times. If obstructed, the sensor might not be able to receive remote control signals. •...
  • Page 10 Part 1 – Introduction Connections on the Front Panel Flash Memory Mouse USB HDD IR Remote Control...
  • Page 11: Dimensions

    Part 1 – Introduction Dimensions (Unit - mm)
  • Page 12: Rear Panel

    Part 1 – Introduction Rear Panel DR-2304P/DR-2404P Audio Ports VGA Out Port HDMI Out Port eSATA Port Power In Port (48V) Video In / PoE Ports Network Port Alarm Connection Ports RS-232 Port Power In Port (12V) DR-2308P/DR-2316P CAUTION ALARM IN ALARM OUT FAudio Ports VGA Out Port...
  • Page 13: Rear Panel Connections

    Part 1 – Introduction Rear Panel Connections • For the external hub, we recommend using an Ext. port to enable functions such as camera alignment. • Green LED on the right will turn on when PoE comes For simplicity, the illustrations and descriptions in on line.
  • Page 14 Part 1 – Introduction operate and upgrade the NVR remotely over a network. • NO (Relay Alarm Outputs) Fore more information on ethernet connection setup, This NVR is capable of activating/deactivating buzzers, refer to Network Setup in the operation manual. lights, and other external devices.
  • Page 15 Part 1 – Introduction Connections on the Rear Panel eSATA Storage Device Speaker VGA Monitor Camera DirectIP™ Gigabit PoE Switch HDMI Monitor Camera Alarm Network Sensor IDIS Center Power (48V) Remote Monitoring Power (12V) Keyboard...
  • Page 16: Remote Control

    Part 1 – Introduction Remote Control (Optional) ID Button PANIC Button Camera Buttons STATUS Button LAYOUT Button PTZ Control Buttons REGISTER MODE Button THUMBNAIL Button CALENDAR Button KEYLOCK Button SETUP Button FREEZE Button LOG Button Enter Button Arrow Buttons ALARM Button SEQUENCE Button &...
  • Page 17 Part 1 – Introduction 1 ID Button 7 REGISTER MODE Button Used to assign remote control ID values. Used in Live mode to access Camera Registration mode. No additional remote control assignment is necessary if the system's ID is 0. If the system's ID is 8 THUMBNAIL Button a number between 1 and 9, however, you will need Used in Playback mode to access Thumbnail Search...
  • Page 18 Part 1 – Introduction $ Enter Button b MENU Button Pressing the MENU button while in Live mode Used to make menu option selections and register data entries. In addition, pressing this button while displays the Live menu. Alternatively, pressing the a camera screen is selected by pressing the Menu button while in Time-lapse Search mode displays the button in Live or Playback mode displays the Camera...
  • Page 19: Part 2 - Appendix

    Part 2 - Appendix System Log Types Boot Up Panic On System Shutdown Panic Off Restart Clear All Data Upgrade Success Clear Disk Upgrade Error Format Disk Power Failure Disk Full Time Changed Auto Deletion Time Zone Change Search Begin Time Sync.
  • Page 20: Error Code Types

    Part 2 - Appendix Error Code Types Upgrade Error Codes Type Type Unknown Error Remote Network Error Incorrect File Version No Remote Upgrade Permission Incorrect OS Version Remote Upgrade File Save Failure Incorrect Software Version Remote Upgrade Cancelled by User Incorrect Kernel Version USB Storage Device Mount Failure Storage Device Mount Failure...
  • Page 21 Part 2 - Appendix Clip Copy Error Codes Type Type Unknown Error Disk Error Device Error Clip Player Execution File Not Found Device Connection Failure Clip Player Execution File Access Failure CD Media Not Found Clip Player Execution File Save Failure Incorrect Media Image Generation Failure File Name Taken...
  • Page 22 Part 2 - Appendix Network Error Codes Type Type Cause of Failure Unknown Connection Cancelled by User Normal Logout No Response from Network Device Host All Channels in Use - Connection Denied High Network Noise Level Incorrect Product Version Info Transmission Queue Full Incorrect User Name or Password Incorrect OEM Info...
  • Page 23: Troubleshooting

    Part 2 - Appendix Troubleshooting Problem Solution • Check the power cable connection status. The main unit won't turn on. • Check the power outlet. • Check the camera's video cable connection status. • Check the monitor's video cable connection status. Unable to display Live video.
  • Page 24: Specifications

    50Mbps / 100Mbps(BRP Mode) PoE(IEEE 802.3at class 4) supported 8 ports, 50W (DR-2308/DR-2316P) Camera Power PoE(IEEE 802.3at class 4) supported 4 ports, 30W (DR-2304P/DR-2404P) Email (attach clip (.cbf ) .MP4), Callback to Remote S/W, Push notification (IDIS Event Notification Mobile)
  • Page 25 Part 2 - Appendix INTERFACE Local(NVR) : - / 1RCA + 1HDMI IP Camera : 16 / 16 (Depending on IP Camera) (DR-2316P) Local(NVR) : - / 1RCA + 1HDMI Audio In / Out IP Camera : 8 / 8 (Depending on IP Camera) (DR-2308P) Local(NVR) : - / 1RCA + 1HDMI IP Camera : 4 / 4 (Depending on IP Camera) (DR-2304P/DR-2404P) NVR Alarm Spec- In...
  • Page 26 Part 2 - Appendix Some hard disks may not function properly when mounted on to this product. Refer to the compatibility chart below before mounting any additional hard disk on to the product. Hard disk compatibility chart is subject to change without notice. Contact your retailer for the latest compatibility chart.
  • Page 27 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
