Randell 3000 Series Operator's Manual

OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
888-994-7636, fax 888-864-7636
unifiedbrands.net
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE.
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED
IN THIS MANUAL.
FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Randell suggests
that if you are suspicious of damage to make a notation on the delivery
receipt. It will be the responsibility of the consignee to file a claim with the
carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
EQUIPMENT DESCRIPTION
3300 SERIES - COMMON WATERBATH
MODEL LENGTH DEPTH
3312 33" 30"
3313 48" 30"
3314 63" 30"
3315 78" 30"
NOTE: All 3300 series units require 1" to 2" of water be added PRIOR to heating of the elements. Hot water is recommended.
3500 SERIES – OPEN WELL (spillage pans required for wet operation)
MODEL LENGTH DEPTH HEIGHT
3512 33" 30"
3513 48" 30"
3514 63" 30"
3515 78" 30"
Information contained in this document is known to be current and accurate at the time of printing/creation. Reference our product line website for the most
updated product information and specifications. © 2023 Electrolux Professional, Inc. All Rights Reserved.
# #
HEIGHT
WELLS ELEMENTS
36" 2 1
36" 3 1
36" 4 2
36" 5 2
SS BOTTOM
# #
SHELF
WELLS ELEMENTS
SQ. FT.
36" 2 2
36" 3 3
36" 4 4
36" 5 5
This manual provides information for:
3000 SERIES ELECTRIC HOT FOOD HOLDING
UNIT MODELS 3300/3500/3600
3313 shown
READ,
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE: Due to a continuous program of product improvement, Randell reserves the
right to make changes in design and specifications without prior notice.
NOTICE: Please read the entire manual carefully before installation. If certain
recommended procedures are not followed, warranty claims will be denied.
MODEL NUMBER _________________________
SERIAL NUMBER _________________________
INSTALLATION DATE ______________________
The serial number is located on the control panel. An
example is shown here.
SS BOTTOM
SHELF SQ. FT.
KW AMPS
5.5 3
8.1 3
10.7 6
13.3 6
120V – 750 WATT
KW AMPS NEMA
5.5 1.5 12.5 5-20P
8.1 2.25 18.75 5-30P
10.7 3 25 5-50P
13.3 3.75 31.25 5-50P
PART NUMBER PP MNL0027, Rev D (08/23)
208V 240V
NEMA KW AMPS
14.4 6-20P 3 12.5
14.4 6-20P 3 12.5
28.8 6-50P 6
28.8 6-50P 6
208V – 865 WATT 240V – 1150 WATT
KW AMPS NEMA KW
1.73 8.32 6-15P 2.3
2.6 12.48 6-20P 3.45
3.46 16.64 6-30P 4.6
4.33 20.8 6-30P 5.75
3613 shown
SHIP WT
(LBS)
NEMA
6-20P 116
6-20P 174
25 6-50P 232
25 6-50P 290
SHIP WT
(LBS)
AMPS AMPS
9.58 6-15P 116
14.37 6-20P 174
19.16 6-30P 232
23.95 6-30P 290
