Protech Systems KF-7270 Quick Reference Manual

KF-7270
Quick
Reference
Guide

Specifications

System
CPU Type Intel Core TM i5-6500 3.20GHz Processor
®
Chipset Intel H110 Chipset
®
Memory Support 2 x DDR4 SO-DIMM sockets (Default: 4GB)
HDD 1 x Intel 2.5" 128GB TLC SSD
Network 10/100/1000 Mbps Base-T Fast Ethernet (RJ45)
Power Supply AC 100-240V, 50-60Hz
System Weight About 83kg (with package)
Dimensions (WxHxD) 527 x 1788 x 412mm
O.S. Support Windows 10 IoT Enterprise LTSB 2016 32bits
Fan 2 x system fans
Material SPCC, SECC
Speaker 2 x 2W HD speaker
Painting Powder-paint coating
Operating Display
Touch 17" Bezel free P-CAP Touch (USB interface)
LCD 17" (4:3) LED backlight
Max. Resolution 1280 x 1024
Brightness 350 cd/m²
Touchscreen Projected Capacitive Touch
Viewing Angle Horizontal: (R) 85°/(L) 85° / Vertical: (U) 80°/(L) 80°
Estimated luminance lifetime 50,000h
Integrated Devices
Thermal Printer Epson TM-T70II
Barcode Reader FS5002J
IC讀卡機 SKH301-1000C
悠遊卡機 虹堡TS-2000
Environment
Operating Temp. 5°C~ 35°C (41°F ~ 95°F)
Storage Temp. 0°C~ 60°C (32°F~ 140°F)
Humidity 20%~ 85%
Ver. Q1
All Rights Reserved. Copyright 2018
KF-7270

Packing Checklist

If you discover any item below damaged or lost,
If you discover any item below are damaged
please contact your vendor.
or lost, please contact your vendor.
KF-7270 Kiosk Main Unit
AD Board
This Quick Reference Guide
AC Power Cord Cable
This Quick Reference Guide
2ND D Screw Cover
Panel Key
Door Key
System View
Speaker
Barcode Reader
Thermal Printer
KF-7270
X1
X1
x1
X1
x1
X1
X2
X2
KF-7270
AD Board
Speaker
17" Bezel free P-CAP
Touchscreen
IC Card Reader
RFID Sensor
DM Tray
Door
